Charging System - Generators & Regulators: Component Locations Ford Taurus IV рестайлинг

Special Tool(s)

SPECIAL TOOL SPECIFICATIONS Flywheel Holding Tool 303-544 (T96P-6375-A)

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. Disconnect the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-233724) .
2. Rotate the accessory drive belt tensioner clockwise and position the accessory drive belt aside.
3. Remove the power steering hose bracket nut from the generator mounting bolt.
4. Remove the upper generator bolts.
5. Remove the RH front wheel and tire assembly. For additional information, refer to «WHEELS & TIRES»(ref-233696) .
6. Remove the RH front fender splash shield. Remove the 4 pin-type retainers. Remove the 3 fender screws. Remove the lower screw.
7. Remove the screws and the generator splash shield.
8. Remove the torque converter inspection cover.
9. Install the flywheel holding tool.
10. Remove the bolt and the crankshaft pulley.
11. Lower the generator to allow access to the electrical connectors. Disconnect the crankshaft sensor. Release the oxygen sensor connector locator from the bracket. Remove the lower generator bolt.
12. Disconnect the regulator electrical connector.
13. Remove the generator from the vehicle. Remove the B+ connector nut. Disconnect the B+ connector and remove the generator.
14. To install, reverse the removal procedure.
