Evaporative Emissions: Component Locations Ford Taurus IV рестайлинг

Special Tool(s)

SPECIAL TOOL CHART Evaporative Emission System Leak Tester 310-F007 (134-00056) or equivalent Worldwide Diagnostic System (WDS) 418-F224, New Generation STAR (NGS) Tester 418-F052 or equivalent scan tool

Scheme 32

Scheme 33

Scheme 34

SPECIAL TOOL CHART Worldwide Diagnostic System (WDS) 418-F224, New Generation STAR (NGS) Tester 418-F052, or equivalent scan tool

1. Connect the scan tool and select the output test mode.
2. If PID monitors are not active, select PIDs.
3. Select the fuel tank pressure (FTP) and the volts (V) parameter identification (PID) for monitoring.
4. Select the ALL OFF mode.
5. Close the canister vent solenoid by pushing the START button on the scan tool.

SPECIAL TOOL CHART Worldwide Diagnostic System (WDS) 418-F224, New Generation STAR (NGS) Tester 418-F052, or equivalent scan tool

Note. The following procedure is designed to execute and complete the evaporative emission repair verification drive cycle and to clear the Ford P1000, inspection and maintenance (I/M) readiness code. When the ambient air temperature is below 4.4°C (40°F) or above 37.8°C (100°F), or the altitude is above 2,438 meters (8,000 feet), the EVAP monitor will not run. If the P1000 must be cleared in these conditions, the powertrain control module (PCM) must detect them once (twice on some applications) before the EVAP monitor can be bypassed and the P1000 cleared. The EVAP bypassing procedure is described in the following drive cycle.

1. Most OBD II monitors will complete more readily using a steady foot driving style during cruise or acceleration modes. Operating the throttle in a smooth fashion will minimize the time necessary for monitor completion.
2. Fuel tank level should be between one-half and three-quarters full with three-quarters full being the most desirable.
3. The evaporative monitor can only operate during the first 30 minutes of engine operation. When executing the procedure for this monitor, stay in part throttle mode and drive in a smooth fashion to minimize fuel slosh. NOTE: For best results, follow each of the following steps as accurately as possible.
4. Install the scan tool. Turn the key ON with the engine OFF. Cycle the key off, then on. Select the appropriate vehicle and engine qualifier. Clear all diagnostic trouble codes (DTCs) and carry out a PCM reset.
5. Begin to monitor the following PIDs: ECT, EVAPDC, FLI (if available) and TP MODE. Press Diagnostic Data Link, PCM, PID/Data monitor and record, press trigger to select each PID, then start.
6. Start the engine without returning the key to the OFF position. WARNING: Strict observance of posted speed limits and attention to driving conditions are mandatory when proceeding through the following drive cycle.
7. Idle the vehicle for 15 seconds. Drive at 64 km/h (40 mph) until the ECT is at least 76.7°C (170°F).
8. Is IAT above 4.4°C (40°F) and below 37.8°C (100°F)? If not, continue with the following steps but note that the EVAP Monitor Bypass portion of the drive cycle (Step 13) will be required to bypass the EVAP monitor and clear the P1000.
9. Cruise at 64 km/h (40 mph) for 60 seconds.
10. Cruise at 72 to 104 km/h (45 to 65 mph) for 10 minutes.
11. Bring the vehicle to a stop. Idle with the transmission in DRIVE (for automatic transmission) or NEUTRAL (for manual transmission) for two minutes.
12. Using the scan tool, check for pending codes. Conduct normal repair procedures for any pending code concerns. Rerun any incomplete monitor.
13. Park the vehicle for a minimum of eight hours. Repeat Steps 5 through 12.

Scheme 35

Scheme 36

Scheme 37

Scheme 38

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-233684) .
2. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-233724) .
3. Disconnect the evaporative emission (EVAP) canister assembly electrical connector.
4. Disconnect the dust box separator tube and the EVAP canister tube quick-connect fitting.
5. Remove the four retainers from the EVAP canister assembly.
6. Remove the EVAP canister assembly.
7. To install, reverse the removal procedure. Carry out a leak text. For additional information, refer to «EVAPORATIVE EMISSION SYSTEM LEAK TEST»(ref-233734-S09617570802006052600000) . Carry out the evaporative emission repair verification drive cycle. For additional information, refer to «EVAPORATIVE EMISSION REPAIR VERIFICATION DRIVE CYCLE»(ref-233734-S04126973502006052600000) .
