SPECIFICATIONS

Application		Specification
Compressor Type		Ford FS-10 10-Cyl.
Compressor Belt Tension		(1)
System Oil Capacity (2)		6.6 ozs.
Refrigerant (R-134a) Capacity (3)		34 ozs.
System Operating Pressures (4)
High Side		125-230 psi (8.8-16.1 kg/cm 2 )
Low Side		22-45 psi (1.5-3.2 kg/cm 2 )
(1) Serpentine belt tension is automatically adjusted by tensioner pulley. (2) Use YN-12c PAG Oil (WSH-M1C231-B). (3) Refer to vehicle specification label for exact specification. (4) Operating pressures at ambient temperature of 80°F (27°C).

(1)	Serpentine belt tension is automatically adjusted by tensioner pulley.

(2)	Use YN-12c PAG Oil (WSH-M1C231-B).

(3)	Refer to vehicle specification label for exact specification.

(4)	Operating pressures at ambient temperature of 80°F (27°C).

SPECIFICATIONS

Application	Ft. Lbs. (N.m)
A/C Compressor Bracket Bolts	30-40 (41-54)
Hose Manifold-To-Compressor Bolt	13-17 (17-23)
Instrument Panel Side Mounting Bolts	14-18 (19-24)
INCH Lbs. (N.m)
Ambient Air Temp. Sensor Screw	68-92 (8-10)
A/C-Heater-To-Cowl Nut	37-84 (4-9)
Condenser-To-Evaporator Line Bolts	80 (9)
Evaporator Core Refrigerant Line Fittings	71 (8)
Heater Core & Evaporator Core Housing Mounting Bolt	44 (5)
Heater Core & Evaporator Core Housing Nuts	62 (7)
Instrument Panel Finish Screw	18-26 (2-3)
Instrument Panel Top Cowl Screws	62-79 (7-9)
PCM Mounting Bracket Nut	44 (5)

TORQUE SPECIFICATIONS

Scheme 1: VACUUM HOSE DIAGRAM(S)

Scheme 2: Automatic A/C-Heater System Wiring Diagram (2000 Sable & Taurus - 1 Of 2)

Scheme 3: Automatic A/C-Heater System Wiring Diagram (2000 Sable & Taurus - 2 Of 2)

Scheme 4: Automatic A/C-Heater System Wiring Diagram (2001 Sable & Taurus - 1 Of 2)

Scheme 5: Automatic A/C-Heater System Wiring Diagram (2001 Sable & Taurus - 2 Of 2)
