Ignition Switch

The ignition switch is controlled by the ignition lock cylinder with a key. When the ignition lock cylinder is turned using the key, a mechanical connection positions the ignition switch to the selected position and allows the ignition switch to send voltage to specific components.

Multifunction Switch

The multifunction switch (high beam/low beam, flash-to-pass, turn signal and windshield wiper) controls the various components electrically. The headlamp switch sends constant voltage to the headlamps when placed in the ON position, while the flash-to-pass is a momentary switch used to send voltage to the headlamp high beams only. The headlamp high beam/low beam switch sends voltage to the low or high beam headlamps while the headlamps are on. The turn signal switch portion of the multifunction switch operates the left and right turn signals. The windshield wiper switch function uses a ground signal to activate the various wiper modes and the wiper/washer.

Ignition Switch - Mechanical

The following conditions can cause difficulty in operating the ignition switch and lock cylinder

1. Burrs on the lock cylinder key
2. Insufficient lube on the lock cylinder
3. Binding lock cylinder
4. Burrs or foreign material around the rack-and-pinion actuator in the lock cylinder housing
5. Insufficient lube on the actuator (Do not apply lubricant to the inside of the ignition switch.)
6. Binding ignition switch

If the steering wheel lock is engaged with the wheels loaded against a curb, high effort will be necessary to turn the key from LOCK. Turn the steering wheel to either side of the lock to unload the system.

Carry out the following test to determine if the ignition switch and lock cylinder are operating correctly.

1. Inspect the ignition key for any burrs, damage or incorrect cut. Have a new ignition key made as necessary.
2. NOTE: The steering wheel may be locked full left or full right. If the steering wheel is locked, it will be necessary to apply turning effort to the steering wheel in the direction of the lock while turning the key. Turn the key to the ACC position and then the RUN position. If the ignition key turns to the ACC and RUN position, continue with Step 3. If the ignition key will not turn to the ACC and RUN position, continue with Step 4.
3. NOTE: The ignition switch and lock cylinder should return from the START position back to the RUN position without assistance. Turn the ignition key to the START position and release the key. If the ignition switch and lock cylinder return from the START position back to the RUN position without assistance, the ignition switch is operating correctly at this time. If the ignition switch and lock cylinder do not return from the START position back to the RUN position without assistance, continue with Step 4.
4. Remove the ignition lock cylinder. Refer to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(ref-365414) .
5. Rotate the ignition lock cylinder through all of the switch positions. If the lock cylinder operates correctly, continue with Step 6. If the lock cylinder does not operate correctly, install a new ignition lock cylinder. Refer to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(ref-365414) .
6. Check for binding or sticking ignition switch actuating rod, burrs around the rack-and-pinion actuator in the ignition lock cylinder housing or insufficient lubrication. If there is sufficient lubrication and there are no burrs, binding or sticking conditions; install a new ignition switch. Refer to «IGNITION SWITCH»(ref-365391-S09253765402010070700000) . If there is insufficient lubrication, burrs, binding or sticking conditions; repair or lubricate as necessary.

Ignition Switch - Electrical

Refer to COMPONENT TESTING for component testing.

Multifunction Switch - Electrical

Refer to COMPONENT TESTING for component testing.

Scheme 9

ITEM DESCRIPTION CHART
