Engine Mechanical - 4.0L SOHC: Component Locations Ford Ranger II рестайлинг

Mechanical 49 illustrations ~1713 words

Special Tool(s)

SPECIAL TOOL REFERENCE Adapter for 303-564 303-578 (T97T-6256-C) Adapter for 303-577 303-576 (T97T-6256-D) Extension, Torque Wrench 303-575 (T97T-6256-F) Holding Tool, Camshaft 303-577 (T97T-6303-C) Holding Tool, Camshaft Sprocket 303-564 (T97T-6256-B) Socket, Camshaft Sprocket Nut 303-565 (T97T-6256-G) or equivalent Tensioner, Timing Chain 303-571 (T97T-6K254-A) Timing Tool, Crankshaft TDC 303-573 (T97T-6303-A)

Scheme 341

Scheme 341: Special Tool(s)

Scheme 342

Scheme 342

Scheme 343

Scheme 343

Scheme 344

Scheme 344

Scheme 345

Scheme 345

Scheme 346

Scheme 346

Scheme 347

Scheme 347

Scheme 348

Scheme 348

Scheme 349

Scheme 349

Scheme 350

Scheme 350

Scheme 351

Scheme 351

Scheme 352

Scheme 352

Scheme 353

Scheme 353

Scheme 354

Scheme 354

Scheme 355

Scheme 355

Scheme 356

Scheme 356

Scheme 357

Scheme 357

Scheme 358

Scheme 358

Scheme 359

Scheme 359

Scheme 360

Scheme 360

Scheme 361

Scheme 361

Scheme 362

Scheme 362

Scheme 363

Scheme 363
  1. Remove the camshaft roller followers. For additional information, refer to «CAMSHAFT ROLLER FOLLOWER»(ref-365365-S01832068132010070700000).
  2. NOTE: The LH and RH camshafts must be retimed when either camshaft is disturbed. Turn the crankshaft clockwise to position the No. 1 cylinder at Top Dead Center (TDC).
  3. If equipped, remove the nut and position the A/C hose aside.
  4. NOTE: Do not rotate the engine counterclockwise. Rotating the engine counterclockwise will result in damage to the damper crankshaft sensor speed wheel and incorrect timing of the engine. NOTE: The Crankshaft TDC Timing Tool must be installed on the damper and should contact the engine block, this positions the engine at TDC. Install the Crankshaft TDC Timing Tool.
  5. Install the Camshaft Sprocket Holding Tool and the Adapter for 303-564 to the RH cylinder head and, if necessary, tighten the 2 top clamp bolts to 10 Nm (89 lb-in).
  6. NOTE: The RH camshaft sprocket is a LH-threaded bolt. Turning the bolt in the wrong direction can damage the bolt. If necessary, using the Torque Wrench Extension and the Camshaft Sprocket Nut Socket, loosen the RH camshaft sprocket bolt.
  7. If necessary, loosen the top 2 Camshaft Sprocket Holding Tool clamp bolts.
  8. NOTE: The camshaft timing slots are off center. Position the camshaft timing slots below the centerline of the camshaft to correctly fit the Camshaft Holding Tool and the Adapter for 303-577 and install the Camshaft Holding Tool and the Adapter for 303-577 on the front of the RH cylinder head.
  9. Remove the 6 pushpins and the RH lower splash shield.
  10. Remove the RH hydraulic timing chain tensioner. Discard the washer.
  11. Install the Timing Chain Tensioner.
  12. NOTE: The RH camshaft sprocket is a LH-threaded bolt. Turning the bolt in the wrong direction can damage the bolt. Using the Torque Wrench Extension and the Camshaft Sprocket Nut Socket, tighten the bolts. Tighten the Camshaft Sprocket Holding Tool top 2 clamp bolts to 10 Nm (89 lb-in). Using the Torque Wrench Extension and the Camshaft Sprocket Nut Socket, tighten the camshaft bolt to 85 Nm (63 lb-ft). Calculate the correct torque wrench setting for the above torque. (Scheme 351)
  13. Remove the Timing Chain Tensioner.
  14. NOTE: Install a new washer on the tensioner. Install the RH hydraulic timing chain tensioner. Tighten to 44 Nm (32 lb-ft).
  15. Install the RH lower splash shield and the 5 pushpins.
  16. Remove the Camshaft Sprocket Holding Tool, the Adapter for 303-564, the Camshaft Holding Tool and the Adapter for 303-577 from the RH cylinder head.
  17. Install the Camshaft Sprocket Holding Tool and the Adapter for 303-564 on the front of the LH cylinder head and, if necessary, tighten the top 2 clamp bolts to 10 Nm (89 lb-in).
  18. If necessary, loosen the LH camshaft sprocket bolt.
  19. If necessary, loosen the top 2 clamp bolts on the Camshaft Sprocket Holding Tool to allow the camshaft sprocket to rotate freely.
  20. NOTE: The camshaft timing slots are off center. Position the camshaft timing slots below the centerline of the camshaft to correctly fit the Camshaft Holding Tool and the Adapter for 303-577 and install the Camshaft Holding Tool and the Adapter for 303-577 on the rear of the LH cylinder head.
  21. Remove the LH hydraulic timing chain tensioner. Discard the washer.
  22. Install the Timing Chain Tensioner.
  23. Tighten the bolts. Tighten the Camshaft Sprocket Holding Tool top 2 clamp bolts to 10 Nm (89 lb-in). Tighten the LH camshaft bolt to 85 Nm (63 lb-ft).
  24. Remove the Timing Chain Tensioner.
  25. NOTE: Install a new washer on the tensioner. Install the LH hydraulic timing chain tensioner. Tighten to 44 Nm (32 lb-ft).
  26. Remove the Camshaft Sprocket Holding Tool, the Adapter for 303-564, the Camshaft Holding Tool and the Adapter for 303-577 from the LH cylinder head.
  27. Remove the Crankshaft TDC Timing Tool.
  28. If equipped, position the A/C hose and install the nut. Tighten to 20 Nm (177 lb-in).
  29. Install the camshaft roller followers. For additional information, refer to «CAMSHAFT ROLLER FOLLOWER»(ref-365365-S01832068132010070700000).

Scheme 364

Scheme 364: Throttle Cables and Electrical Connectors
ItemPart NumberDescription
19A758Accelerator cable
29A825Speed control actuator cable (speed control equipped vehicles only)
314A464Throttle Position (TP) sensor electrical connector (part of 12B637)
413A506Wiring harness retainer (part of 12B637)
514A464Idle Air Control (IAC) motor electrical connector (part of 12B637)

ITEM DESCRIPTION

Scheme 365

Scheme 365: Vacuum Hoses and Electrical Connectors
ItemPart NumberDescription
69E499EGR valve vacuum hose connector (part of 9E498)
79E469Exhaust manifold-to-EGR valve tube
89Y476Evaporative Emission (EVAP) purge valve-to-intake manifold hose
914A464EGR vacuum regulator solenoid electrical connector (part of 12B637)
109E499EGR vacuum regulator solenoid vacuum connector (part of 9E498)
119E499Main vacuum hose connector (part of 9E498)
12160200Brake booster vacuum hose

ITEM DESCRIPTION

Scheme 366

Scheme 366: Spark Plug Wires and Ignition Coil
ItemPart NumberDescription
13RH spark plug wires (part of 12280)
14RH spark plug wire retainer (part of 12280)
1514A464Ignition coil electrical connector (part of 12B637)
1613A506Wiring harness retainer (part of 12B637)
17Ignition coil bracket upper bolt (2 required)
1814489Radio interference capacitor electrical connector (part of 12B637)
19N802768Accelerator cable retainer
20W500041Ignition coil bracket lower rear bolt
21W500023Ignition coil bracket lower front bolt
2212257Ignition coil bracket

ITEM DESCRIPTION

Scheme 367

Scheme 367: PCM Electrical Connectors
ItemPart NumberDescription
23N621906Wiring harness retainer nut
24Wiring harness retainer (part of 12B637)
2514A464PCM electrical connector (part of 12B637)
26N806925Wiring harness ground wire stud bolt
2714463Wiring harness ground terminal (part of 12B637)

ITEM DESCRIPTION

Scheme 368

Scheme 368: Intake Manifold
ItemPart NumberDescription
28Knock Sensor (KS) electrical connector (part of 12A699)
2995479Intake manifold bolt and grommet assembly (part of 9424) (8 required)
309424Intake manifold
31W704310Heated PCV fitting bolt (2 required)
329A474Heated PCV fitting
339461Intake manifold gasket (6 required)

ITEM DESCRIPTION

SPECIAL TOOL REFERENCE Remover, Spark Plug Wire 303-106 (T74P-6666-A)

Scheme 369

Scheme 369: Special Tool(s)

SPECIAL TOOL REFERENCE Installer, Crankshaft Vibration Damper 303-102 (T74P-6316-B) Remover, Crankshaft Vibration Damper 303-101 (T74P-3616-A) Remover, Crankshaft Vibration Damper 303-773 Strap Wrench 303-D055 (D85L-6000-A) or equivalent

Scheme 370

Scheme 370: Special Tool(s)

SPECIAL TOOL REFERENCE Aligner, Front Cover 303-093 (T74P-6019-A) Installer, Crankshaft Vibration Damper 303-102 (T74P-6316-B) Remover, Crankshaft Front Oil Seal 303-107 (T74P-6700-A)

Scheme 371

Scheme 371: Special Tool(s)

Scheme 372

Scheme 372

SPECIAL TOOL REFERENCE Adapter for 303-564 303-578 (T97T-6256-A) Holding Tool, Camshaft Sprocket 303-564 (T97T-6256-B) Remover, Spark Plug Wire 303-106 (T74P-6666-A) Socket, Camshaft Sprocket Nut 303-565 (T97T-6256-G) Timing Tool, Crankshaft TDC 303-573 (T97T-6303-A) Torque Wrench Extension 303-575 (T97T-6256-F)

SPECIAL TOOL REFERENCE Adapter for 303-564 303-578 (T97T-6256-A) Holding Tool, Camshaft Sprocket 303-564 (T97T-6256) Holding Tool, Crankshaft 303-674

Scheme 373

Scheme 373
ItemPart NumberDescription
16K254Hydraulic chain tensioner
26M276Camshaft sprocket bolt
36M276Jackshaft sprocket bolt
4W500011Jackshaft chain tensioner bolts (2 required)
56M271Jackshaft chain tensioner
6Jackshaft chain and sprocket assembly
76U001LH cassette upper bolt
8W500110LH cassette lower bolt
96M289LH cassette

ITEM DESCRIPTION

Scheme 374

Scheme 374: Removal

Scheme 375

Scheme 375

Scheme 376

Scheme 376
  1. Remove the valve covers. For additional information, refer to «VALVE COVER - RH»(ref-365365-S20321358132010070700000) and «VALVE COVER - LH»(ref-365365-S29060672082010070700000) .
  2. Remove the fuel rail. For additional information, refer to «FUEL CHARGING AND CONTROLS - 4.0L SOHC»(ref-365424) .
  3. Remove the engine front cover. For additional information, refer to «ENGINE FRONT COVER»(ref-365365-S42857481252010070700000) .
  4. Remove the thermostat housing. For additional information, refer to «ENGINE COOLING»(ref-365412) .
  5. Remove all of the roller followers. For additional information, refer to «CAMSHAFT ROLLER FOLLOWER»(ref-365365-S01832068132010070700000) .
  6. NOTE: The LH and RH camshafts must be retimed when either camshaft is disturbed. Turn the crankshaft clockwise to position the No. 1 cylinder at Top Dead Center (TDC).
  7. Remove the LH hydraulic chain tensioner. Discard the washer.
  8. Remove the LH camshaft sprocket bolt. Install the Camshaft Sprocket Holding Tool and the Adapter for 303-564 and tighten the bolts to 10 Nm (89 lb-in). Remove the LH camshaft sprocket bolt.
  9. Using the Crankshaft Holding Tool to prevent the crankshaft from turning, remove the jackshaft sprocket bolt.
  10. Remove the 2 bolts and the primary chain tensioner.
  11. Remove the primary chain and sprockets as an assembly.
  12. Remove the LH cassette upper bolt.
  13. Remove the LH cassette lower bolt and the LH cassette.

Scheme 377

Scheme 377

Scheme 378

Scheme 378: Installation

Scheme 379

Scheme 379
  1. NOTE: The camshaft chain sprockets must be oriented correctly. Position the LH cassette.
  2. Install the LH cassette lower bolt. Tighten to 19 Nm (168 lb-in).
  3. Install the LH cassette upper bolt. Tighten to 12 Nm (106 lb-in).
  4. Install the jackshaft chain and sprockets as an assembly.
  5. Install the jackshaft chain tensioner and the bolts. Tighten to 9 Nm (80 lb-in).
  6. Using the Crankshaft Holding Tool to prevent the crankshaft from turning, tighten the jackshaft sprocket bolt in 2 stages. Stage 1: Tighten to 45 Nm (33 lb-ft). Stage 2: Tighten an additional 90 degrees.
  7. Loosely install the camshaft sprocket bolt.
  8. Install the engine front cover. For additional information, refer to «ENGINE FRONT COVER»(ref-365365-S42857481252010070700000) .
  9. NOTE: The LH and RH camshafts must be retimed when either camshaft is disturbed. NOTE: Install the LH hydraulic chain tensioner during camshaft timing. Time the LH and RH camshafts. For additional information, refer to «CAMSHAFT TIMING»(ref-365365-S23613813062010070700000) .
  10. Install the camshaft roller followers. For additional information, refer to «CAMSHAFT ROLLER FOLLOWER»(ref-365365-S01832068132010070700000) .
  11. Install the thermostat housing. For additional information, refer to «ENGINE COOLING»(ref-365412) .
  12. Install the fuel rail. For additional information, refer to «FUEL CHARGING AND CONTROLS - 4.0L SOHC»(ref-365424) .
  13. Install the valve covers. For additional information, refer to «VALVE COVER - RH»(ref-365365-S20321358132010070700000) and «VALVE COVER - LH»(ref-365365-S29060672082010070700000) .
  14. Fill and bleed the cooling system. For additional information, refer to «ENGINE COOLING»(ref-365412) .

SPECIAL TOOL REFERENCE Adapter for 303-564 303-578 (T97T-6256-A) Extension, Torque Wrench 303-575 (T97T-6256-F) Holding Tool, Camshaft Sprocket 303-564 (T97T-6256-B) Socket, Camshaft Sprocket Nut 303-565 (T97T-6256-G)

SPECIAL TOOL REFERENCE Compressor, Valve Spring 303-581 (T97T-6565-A)

Scheme 380

Scheme 380: Special Tool(s)

SPECIAL TOOL REFERENCE Compressor, Valve Spring 303-581 (T97T-6565-A)

SPECIAL TOOL REFERENCE Installer, Valve Stem Seal 303-370 (T90T-6571-A)

SPECIAL TOOL REFERENCE Adapter for 303-290A 303-290-01 Adapter for 303-290A 303-290A-03A Lifting Bracket, Engine 303-050 (T70P-6000) Support Bar, Engine 303-290A

Scheme 381

Scheme 381: Special Tool(s)

Scheme 382

Scheme 382

SPECIAL TOOL REFERENCE Adapter for 303-579 303-527 (T95T-6701-A3) Installer, Crankshaft Rear Oil Seal 303-579 (T97T-6701-A) Remover, Oil Seal 303-409 (T92C-6700-CH) Screws, Crankshaft Rear Oil Seal 303-528 (T95T-6701-A4)

Scheme 383

Scheme 383: Special Tool(s)

Scheme 384

Scheme 384

SPECIAL TOOL REFERENCE Adapter for 303-290A 303-290-01 Adapter for 303-290A 303-290A-03A Lifting Bracket, Engine 303-050 (T70P-6000) Support Bar, Engine 303-290A

SPECIAL TOOL REFERENCE Heavy Duty Floor Crane 014-00071 or equivalent Lifting Bracket, Engine 303-050 (T70P-6000) Spark Plug Wire Remover 303-106 (T74P-6666-A) Spreader Bar 303-D089 (D93P-6001-A3) or equivalent

Scheme 385

Scheme 385

SPECIAL TOOL REFERENCE Adapter for 303-564 303-578 (T97T-6256-C) Compressor, Valve Spring 303-581 (T97T-6565-A) Heavy Duty Floor Crane 014-00071 or equivalent Holding Tool, Camshaft 303-564 (T97T-6256-B) Lifting Bracket, Engine 303-050 (T70P-6000) Rear Jackshaft Socket 303-634 Remover, Crankshaft Front Oil Seal 303-107 (T74P-6700-A) Remover, Crankshaft Vibration Damper 303-101 (T74P-6316-A) Remover, Crankshaft Vibration Damper 303-773 Remover, Oil Seal 303-409 (T92C-6700-CH) Spreader Bar 303-106 (T74P-6666-A) Strap Wrench 303-D055 (D85L-6000-A) or equivalent

SPECIAL TOOL REFERENCE Compressor, Valve Spring 303-581 (T97T-6565-A) Installer, Valve Stem Oil Seal 303-370 (T90T-6571-A)

SPECIAL TOOL REFERENCE Service Set, Piston Pin 303-S024 (T68P-6135-A)

SPECIAL TOOL REFERENCE Adapter for 303-564 303-578 (T97T-6256-A) Adapter for 303-577 303-576 (T97T-6256-D) Adapter for 303-579 303-527 (T95T-6701-A3 Aligner, Front Cover 303-093 (T74P-6019-A) Compressor, Piston Ring 303-D032 (D81L-6002-C) or equivalent Compressor, Valve Spring 303-581 (T97T-6565-A) Heavy Duty Floor Crane 014-00071 or equivalent Holding Tool, Camshaft 303-577 (T97T-6256-C) Holding Tool, Camshaft Sprocket 303-564 (T97T-6256-B) Installer, Crankshaft Rear Oil Seal 303-579 (T97T-6701-A) Installer, Crankshaft Vibration Damper 303-102 (T74P-6316-B) Lifting Brackets, Engine 303-050 (T70P-6000) Screws, Crankshaft Rear Oil Seal 303-528 (T95T-6701-A4) Socket, Rear Jackshaft 303-634 Spreader Bar 303-D089 (D93P-6001-A3) or equivalent Strap Wrench 303-D055 (85L-6000-A) or equivalent Tensioner, Timing Chain 303-571 (T97T-6K254-A) Timing Tool, Crankshaft TDC 303-573 (T97T-6303-A)

Scheme 386

Scheme 386: Special Tool(s)

Scheme 387

Scheme 387

Scheme 388

Scheme 388

Scheme 389

Scheme 389

SPECIAL TOOL REFERENCE Heavy Duty Lifting Crane 014-00071 or equivalent Lifting Bracket, Engine 303-050 (T70P-6000) Spreader Bar 303-D089 (D93P-6001-A3) or equivalent
