Special Tool(s)
SPECIAL TOOL SPECIFICATION Feeler Gauge Set 303-D027 (D81L-4201-A) or equivalent
Scheme 45
Scheme 46
- Remove the valve cover. For additional information, refer to «VALVE COVER»(ref-365364-S02729939852010070700000) .
- NOTE: Turn the engine clockwise only and use the crankshaft bolt only or the engine may be damaged. NOTE: Measure the clearance of each valve at base circle with the lobe pointed away from the tappet, before removing the camshafts. Failure to measure all clearances prior to removing the camshafts will necessitate repeated removal and installation and wasted labor time. Using the Feeler Gauge Set, measure the clearance of each valve and record the location.
- NOTE: The number on the valve tappet only reflects the digits that follow the decimal. For example, a tappet with the number 0.650 has the thickness of 3.650 mm. NOTE: The nominal desired mid-range clearance is: Intake: 0.25 mm (0.0095 in) Exhaust: 0.30 mm (0.0115 in) Select tappets using this formula: tappet thickness = measured clearance + the base tappet thickness - most desirable thickness. NOTE: The acceptable clearances after being fully installed are: Intake: 0.22-0.28 mm (0.008-0.011 in) Exhaust: 0.27-0.33 mm (0.010-0.013 in) Select the closest tappet size available and mark the installation location.
- If any tappets do not measure within specifications, install new tappets in those locations. For additional information, refer to «VALVE TAPPETS»(ref-365364-S42620820572010070700000) .
SPECIAL TOOL SPECIFICATION Alignment Plate, Camshaft 303-465 (T94P-6256-CH) Holding Tool, Crankshaft Damper 303-1416 Timing Peg, Crankshaft 303-507
Scheme 47
Scheme 48
SPECIAL TOOL SPECIFICATION Installer, Camshaft Front Oil Seal 303-096 (T74P-6150-A) Remover, Seal 303-409 (T92C-6700-CH)
Scheme 49
SPECIAL TOOL SPECIFICATION Aligner, Crankshaft Sensor 303-1417
Scheme 50
SPECIAL TOOL SPECIFICATION Alignment Plate, Camshaft 303-465 (T94P-6256-CH)
SPECIAL TOOL SPECIFICATION Compressor, Valve Spring 303-300 (T87C-6565-A) Compressor, Valve Spring 303-350 (T89P-6565-A) Compressor, Valve Spring 303-472 (T94P-6565-AH)
Scheme 51
Scheme 52
Scheme 53
SPECIAL TOOL SPECIFICATION Compressor, Valve Spring 303-300 (T87C-6565-A) Compressor, Valve Spring 303-350 (T89P-6565-A) Compressor, Valve Spring 303-472 (T94P-6565-AH) Installer, Valve Stem Oil Seal 303-470 (T94P-6510-CH) Remover, Valve Stem Oil Seal 303-468 (T94P-6510-AH) Slide Hammer 307-005 (T59L-100-B)
SPECIAL TOOL SPECIFICATION Alignment Plate, Camshaft 303-465 (T94P-6256-CH)
SPECIAL TOOL SPECIFICATION 3-Bar Engine Support Kit 303-F072 Lifting Eyes 303-D030 (D81L-6001-D) or equivalent
Scheme 54
Scheme 55
SPECIAL TOOL SPECIFICATION Locking Tool, Flywheel 303-103 (T74P-8375-A)
Scheme 56
- Remove the clutch disc and pressure plate. For additional information, refer to «CLUTCH»(ref-365423) .
- Using the Flywheel Locking Tool, remove the 6 bolts and the flywheel.
SPECIAL TOOL SPECIFICATION Locking Tool, Flywheel 303-103 (T74P-8375-A)
Scheme 57
- Remove the transmission. For additional information, refer to «AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E»(ref-365367) .
- Using the Flywheel Locking Tool, remove the 6 bolts and the flexplate.
Scheme 58
- NOTE: Engine balancing is not required. Balance weights should not be installed on the new flexplate. NOTE: Special bolts are used for installation. Do not use standard bolts. Position the flexplate.
- Using the Flywheel Locking Tool, install the 6 bolts in the sequence shown in illustration, in 3 stages. Stage 1: Tighten to 50 Nm (37 lb-ft). Stage 2: Tighten to 80 Nm (59 lb-ft). Stage 3: Tighten to 112 Nm (83 lb-ft).
- Install the transmission. For additional information, refer to «AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E»(ref-365367) .
SPECIAL TOOL SPECIFICATION Installer, Crankshaft Rear Seal 303-328 (T88P-6701-B1)
Scheme 59
SPECIAL TOOL SPECIFICATION 3-Bar Engine Support Kit 303-F072 Lifting Eyes 303-D030 (D81L-6001-D) or equivalent
Scheme 60
SPECIAL TOOL SPECIFICATION Heavy Duty Floor Crane 014-00071 or equivalent Lifting Bracket, Engine 303-050 (T70P-6000) Spreader Bar 303-D089 (D93P-6001-A3) or equivalent
Scheme 61
All vehicles
Scheme 62
Scheme 63
Scheme 64
Scheme 65
Scheme 66
Scheme 67
Scheme 68
Scheme 69
Scheme 70
Scheme 71
Scheme 72
Scheme 73
Scheme 74
Scheme 75
Scheme 76
Scheme 77
Scheme 78
Scheme 79
Scheme 80
Scheme 81
Scheme 82
Scheme 83
Scheme 84
Scheme 85
Scheme 86
Scheme 87
Scheme 88
Scheme 89
Scheme 90
Scheme 91
Scheme 92
Scheme 93
Scheme 94
Scheme 95
Scheme 96
Scheme 97
Scheme 98
Scheme 99
Scheme 100
Scheme 101
Scheme 102
Scheme 103
Scheme 104
Scheme 105
Scheme 106
- With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-365369) .
- Relieve the fuel pressure. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-365420) .
- Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-365408) .
- Recover the A/C system. For additional information, refer to «CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS»(ref-365378) .
- Drain the engine cooling system. For additional information, refer to «ENGINE COOLING»(ref-365412) .
- Drain the engine oil.
- Remove the hood.
- Remove the Air Cleaner (ACL) outlet tube. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(ref-365413) .
- Remove the upper radiator hose.
- Remove the lower radiator hose.
- Remove the fan and shroud. For additional information, refer to «ENGINE COOLING»(ref-365412) .
- Disconnect the 3 PCM electrical connectors. Remove the retaining nut on the harness clamp. Position the harness on the engine.
- Remove the stud bolt and the ground cable.
- Remove the heater hose assembly. Disconnect the heater hoses at the bulkhead. Disconnect the vacuum hose. Disconnect the heater hoses at the engine and remove the assembly.
- Disconnect the vacuum reservoir tube connection.
- Disconnect the engine-to-degas bottle coolant bypass hose.
- Disconnect the degas bottle-to-engine coolant supply hose.
- Disconnect the A/C compressor electrical connector.
- Disconnect the Mass Air Flow (MAF) electrical connector.
- Disconnect the A/C compressor manifold. Plug the lines and the compressor ports.
- Disconnect the accelerator cable and, if equipped, the speed control cable from the Throttle Body (TB) and the cable mounting bracket and position aside.
- Disconnect and position aside the Power Steering Pressure (PSP) switch electrical connector and the high-pressure power steering tube.
- Disconnect the fuel supply tube spring lock coupling. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-365420) .
- Detach the fuel supply tube, disconnect the electrical connectors and disconnect the evaporative purge tube quick connect coupling. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-365420) .
- Disconnect the brake booster vacuum hose and the engine ground strap.
- Remove the 3 nuts and disconnect the positive battery cable, the negative battery cable and the solenoid control wire at the starter.
- Remove the starter wiring harness support bracket bolt and position the wiring harness aside.
- Remove the 3 rear pushpins and position the RH splash shield aside.
- Disconnect the generator electrical connections.
- Detach generator wiring pin-type retainer.
- If equipped, disconnect the block heater electrical connector.
- Disconnect the front Heated Oxygen Sensor (HO2S) electrical connector at the transmission bell housing. Vehicles with an automatic transmission
- Remove the bolt and the transmission cooling tubes retaining bracket. All vehicles
- Remove the bolt and the transmission dust shield.
- Remove the 2 exhaust manifold-to-front pipe nuts.
- Disconnect the engine wiring harness anchor and the pin-type retainer and position the wiring harness aside.
- Disconnect the Engine Oil Pressure (EOP) sensor electrical connector.
- Remove and discard the engine oil filter.
- Detach the wiring harness from the crossmember and disconnect the electrical connector. Route the wiring harness to the transmission. Vehicles with an automatic transmission
- Disconnect the rear HO2S electrical connector.
- Disconnect the Catalyst Monitor Sensor (CMS) electrical connector. Remove the nut and route the wiring harness over the transmission.
- Disconnect the transmission electrical connectors and detach the wiring harness retainers.
- Detach the wiring harness retainers. Vehicles with a manual transmission
- Disconnect the HO2S electrical connector.
- Disconnect the CMS electrical connector. Remove the nut and route the wiring harness over the transmission.
- Disconnect the transmission electrical connectors and detach the wiring harness retainers. All vehicles
- Route the transmission portion of the wiring harness to the engine.
- Remove the 4 bolts and the oil filter adapter.
- Remove the bolt, the 2 stud bolts and the starter.
- Remove the starter dust shield. Vehicles with an automatic transmission
- NOTE: Mark one stud and the flexplate for assembly reference. Remove the 4 torque converter nuts. All vehicles
- NOTE: Leave the 2 side bolts in until the engine is ready to be removed. Remove 9 of the transmission-to-engine bolts. Vehicles with an automatic transmission
- Remove the transmission fluid indicator and tube assembly. All vehicles
- Install the 2 Engine Lifting Brackets.
- Support the transmission with a floor jack.
- Support the engine with the Floor Crane, using the Spreader Bar.
- Remove the 2 side transmission-to-engine bolts.
- NOTE: Left side shown in illustration, right side similar. Remove the 4 engine support insulator nuts.
- Remove the engine from the vehicle.
SPECIAL TOOL SPECIFICATION Alignment Plate, Camshaft 303-465 (T94P-6256-CH) Engine Stand 014-00232 or equivalent Holding Tool, Crankshaft Damper 303-1416 Holding Tool, Flywheel 303-103 (T74P-8375-A) Installer, Connecting Rod 303-462 (T94P-6136-AH) Remover, Oil Seal 303-409 (T92C-6700-CH)
Scheme 107
Scheme 108
Scheme 109
SPECIAL TOOL SPECIFICATION Compressor, Valve Spring 303-300 (T87C-6565-A) Compressor, Valve Spring 303-350 (T89P-6565-A) Compressor, Valve Spring 303-472 (T94P-6565-AH) Remover, Valve Stem Seal 303-468 (T94P-6510-AH) Replacer, Valve Stem Seal 303-470 (T94P-6510-CH) Slide Hammer 307-005 (T59L-100-B)
Scheme 110
SPECIAL TOOL SPECIFICATION Aligner, Clutch Disc 308-006 (T71P-7137-H) Aligner, Crankshaft Sensor 303-1417 Alignment Plate, Camshaft 303-465 (T94P-6256-CH) Compressor, Piston Ring 303-D032 (D81L-6002-C) or equivalent Dial Indicator Gauge with Holding Fixture 100-002 (TOOL-4201-C) Engine Stand 014-0232 or equivalent Heavy-Duty Floor Crane 014-00071 or equivalent Holding Tool, Crankshaft Damper 303-1416 Installer, Camshaft Front Oil Seal 303-096 (T74P-6150-A) Installer, Connecting Rod 303-462 (T94P-6136-AH) Installer, Crankshaft Rear Main Oil Seal 303-328 (T88P-6701-B1) Locking Tool, Flywheel 303-103 (T74P-8375-A Spreader Bar 303-D089 (D93P-6001-A3) or equivalent Timing Peg, Crankshaft 303-507
Scheme 111
Scheme 112
Scheme 113
Scheme 114
SPECIAL TOOL SPECIFICATION Heavy Duty Floor Crane 014-00071 or equivalent Lifting Bracket, Engine 303-050 (T70P-6000) Spreader Bar 303-D089 (D93P-6001-A3) or equivalent
