Engine Ignition System - 4.0L SOHC: Specifications Ford Ranger II рестайлинг

Ignition System 3 illustrations ~214 words

MATERIAL SPECIFICATIONS

ItemSpecificationFill Capacity
Silicone Brake Caliper Grease and Dielectric Compound XG-3-AESE-M1C171-A

MATERIAL SPECIFICATIONS

GENERAL SPECIFICATIONS

ItemSpecification
Base ignition timing10 degrees Before Top Dead Center (BTDC) Non-adjustable
Firing order1-4-2-5-3-6
Spark plug gap1.32-1.37 mm (0.052-0.054 in)
Spark plug typeAGSF24N

GENERAL SPECIFICATIONS

TORQUE SPECIFICATIONS

DescriptionNm
Ignition coil bolts6
Spark plugs15

TORQUE SPECIFICATIONS

The ignition system contains the

  1. Crankshaft Position (CKP) sensor.
  2. ignition coil.
  3. spark plug wire.
  4. spark plug.

The ignition system is

  1. an electronic distributorless ignition system and is controlled by an electronic engine control integrated into the PCM.
  2. set at 10 degrees Before Top Dead Center (BTDC) for base timing and is not adjustable.

The CKP sensor

  1. is a variable reluctance sensor.
  2. senses a missing tooth on the crankshaft damper pulse ring.
  3. generates a crankshaft position signal which is sent to the PCM. The PCM counts this signal for engine RPM.

For information on the CKP sensor, refer to ELECTRONIC ENGINE CONTROLS .

The ignition coil

  1. changes low-voltage pulses from the PCM to high-voltage pulses.
  2. has 3 transformers.
  3. fires 2 spark plugs simultaneously.

Spark plug wires carry high-voltage pulses from the ignition coil to the spark plugs.

The spark plugs

  1. change high-voltage pulses to spark at the gap, which ignites the fuel and air mixture.

The firing order is: 1-4-2-5-3-6.

Scheme 8

Scheme 8: Coil Terminal-to-Cylinder Relationship

Refer to the INTRODUCTION - GASOLINE MODELS .

Scheme 9

Scheme 9: Ignition System Components
ItemPart NumberDescription
112286Spark plug wire (6 required)
212405Spark plug (6 required)
314A464Ignition coil electrical connector (part of 12B637)
4W706216Ignition coil bolt (4 required)
518801Radio ignition interference capacitor
612029Ignition coil

ITEM DESCRIPTION CHART

Scheme 10

Scheme 10: RH Splash Shield
ItemPart NumberDescription
1RH splash shield pushpin (5 required)
216034RH splash shield

ITEM DESCRIPTION CHART

  1. For additional information, refer to the procedures in this article.
