Scheme 12

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-365369) .
2. Remove the right front tire. For additional information, refer to «WHEELS & TIRES»(ref-365372) .
3. Remove the RH front splash shield.
4. NOTE: Spark plug wires must be connected correctly. For additional information, refer to the Coil Terminal-to-Cylinder Relationship illustration in the Description and Operation, «ENGINE IGNITION»(ref-365419-S35172656022010070700000) . Failure to follow this instruction may result in poor engine performance. NOTE: It is important to twist the spark plug wire boots while pulling upward, to avoid possible damage to the spark plug wire. With a twisting motion, use the Spark Plug Wire Remover to pull the spark plug wires from the right side of the engine.
5. NOTE: Spark plug wires must be connected correctly. For additional information, refer to the Coil Terminal-to-Cylinder Relationship illustration in the Description and Operation, «ENGINE IGNITION»(ref-365419-S35172656022010070700000) . NOTE: It is important to twist the spark plug wire boots while pulling upward, to avoid possible damage to the spark plug wire. With a twisting motion, use the Spark Plug Wire Remover to pull the spark plug wires from the left side of the engine.
6. Squeeze the locking tabs and twist while pulling upward, to remove the spark plug wires from the ignition coil.
7. Disconnect the spark plug wires from the separators and remove the spark plug wires.
8. NOTE: Be sure to orient the spark plug boots so the spark plug wires do not contact the exhaust manifold, or the spark plug wires may be damaged. NOTE: Apply silicone dielectric compound to the inside of the spark plug and ignition coil boots of the spark plug wire. To install, reverse the removal procedure.

MATERIAL SPECIFICATIONS

Scheme 13

1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-365369) .
2. Remove the right front tire and wheel. For additional information, refer to «WHEELS & TIRES»(ref-365372) .
3. Remove the RH front splash shield.
4. NOTE: Spark plug wires must be connected correctly. For additional information, refer to the Coil Terminal-to-Cylinder Relationship illustration in the Description and Operation, «ENGINE IGNITION»(ref-365419-S35172656022010070700000) . Failure to follow this instruction may result in poor engine performance. NOTE: It is important to twist the spark plug wire boots while pulling upward, to avoid possible damage to the spark plug wires. With a twisting motion, use the Spark Plug Wire Remover to pull the spark plug wires from the right side of the engine.
5. NOTE: Use compressed air to remove any foreign material in the spark plug wells before removing the spark plugs. NOTE: If an original spark plug is reused, make sure it is installed in the same cylinder from which it was removed. New spark plugs can be used in any cylinder. Remove the RH spark plugs. To install, tighten to 15 Nm (133 lb-in).
6. NOTE: Spark plug wires must be connected correctly. For additional information, refer to the Coil Terminal-to-Cylinder Relationship illustration in the Description and Operation, «ENGINE IGNITION»(ref-365419-S35172656022010070700000) . Failure to follow this instruction may result in poor engine performance. NOTE: It is important to twist the spark plug wire boots while pulling upward, to avoid possible damage to the spark plug wires. With a twisting motion, use the Spark Plug Wire Remover to pull the spark plug wires from the left side of the engine.
7. NOTE: Use compressed air to remove any foreign material in the spark plug wells before removing the spark plugs. NOTE: If an original spark plug is reused, make sure it is installed in the same cylinder from which it was removed. New spark plugs can be used in any cylinder. Remove the LH spark plugs. To install, tighten to 15 Nm (133 lb-in).
8. Inspect the spark plugs. For additional information, refer to «ENGINE SYSTEM - GENERAL INFORMATION»(ref-365375) .
9. Use a suitable spark plug gap tool to check and adjust the spark plug gap.
10. To install, reverse the removal procedure. Apply silicone dielectric compound to the inside of the spark plug wire boots prior to installation.
