Engine Cooling System: Component Locations Ford Ranger II рестайлинг

Cooling System (Mechanical) 11 illustrations ~307 words

Special Tool(s)

SPECIAL TOOL SPECIFICATIONS Coolant/Battery Refractometer 023-00164 or equivalent Fluke 77-IV Digital Multimeter FLU77-4 or equivalent Pressure Test Kit 014-R1072 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 19

Scheme 19: Special Tool(s)

Scheme 20

Scheme 20

Scheme 21

Scheme 21

SPECIAL TOOL SPECIFICATIONS RADIATOR REFILLER 078-00592 or equivalent

Scheme 22

Scheme 22: Special Tool(s)

SPECIAL TOOL SPECIFICATIONS RADIATOR REFILLER 078-00592 or equivalent

SPECIAL TOOL SPECIFICATIONS Strap Wrench 303-D055 (D85L-6000-A) or equivalent

Scheme 23

Scheme 23: Special Tool(s)
  1. Remove the Air Cleaner (ACL) outlet pipe. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(ref-365413) .
  2. Remove the accessory drive belt. For additional information, refer to «ACCESSORY DRIVE»(ref-365381) .
  3. Using the Strap Wrench to hold the fan pulley, loosen the cooling fan clutch nut. To install, tighten to 55 Nm (41 lb-ft).
  4. Remove the fan and clutch assembly.
  5. If necessary, remove the 4 fan-to-fan clutch bolts and separate the fan from the fan clutch. To install, tighten to 9 Nm (80 lb-in).
  6. To install, reverse the removal procedure.

SPECIAL TOOL SPECIFICATIONS Holding Wrench, Fan Pulley 303-239 (T84T-6312-C) Wrench, Fan Clutch Nut 303-240 (T84T-6312-D)

Scheme 24

Scheme 24: Special Tool(s)

Scheme 25

Scheme 25

Scheme 26

Scheme 26: Removal and Installation
  1. Remove the Air Cleaner (ACL) outlet tube. For additional information, refer to «INTAKE AIR DISTRIBUTION & FILTERING»(ref-365413) .
  2. Remove the accessory drive belt. For additional information, refer to «ACCESSORY DRIVE»(ref-365381) .
  3. Using the Fan Pulley Holding Wrench and the Fan Clutch Nut Wrench, remove the fan and fan clutch assembly and position it inside the shroud. To install, tighten to 55 Nm (41 lb-ft).
  4. Remove the 2 fan shroud bolts. Lift the fan and fan clutch assembly and the fan shroud together and remove from the vehicle. To install, tighten to 6 Nm (53 lb-in).
  5. To install, reverse the removal procedure.

Scheme 27

Scheme 27: Transmission Crossmember
ItemPart NumberDescription
114A163Electrical connector retainer (part of 14405)
213A506Wiring harness retainer (part of 14A464)
3N802594Transmission crossmember bolt (6 required)
4N621945Transmission mount nut (2 required)
51132Transmission crossmember

ITEM DESCRIPTION CHART

Scheme 28

Scheme 28: EGR Valve Heater Hose RH Connections
ItemPart NumberDescription
18C633EGR valve heater hose
218472Heater hose (part of 18C266)
3W708176EGR valve heater hose bracket nut

ITEM DESCRIPTION CHART

Scheme 29

Scheme 29: EGR Valve Heater Hose LH Connections
ItemPart NumberDescription
18C633EGR valve heater hose

ITEM DESCRIPTION CHART
