Diagnostic Trouble Code (DTC) Chart

Note. Most powertrain (P-code) DTCs are diagnosed in the INTRODUCTION - GASOLINE MODELS . If the P-code retrieved is not listed below, refer to the INTRODUCTION - GASOLINE MODELS to continue diagnostics.

Note. The Smart Junction Box (SJB) is also known as the Generic Electronic Module (GEM).

Note. Some of these modules utilize a 5-character DTC followed by a 2-character failure-type code. The failure-type code provides information about specific fault conditions such as opens, or shorts to ground. Continuous memory DTCs have an additional 2-character DTC status code suffix to assist in determining DTC history.

DTC	Description	Source	Action
B0001:11	Driver Frontal Stage 1 Deployment Control: Circuit Short To Ground	Restraints Control Module (RCM)	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0001:12	Driver Frontal Stage 1 Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0001:13	Driver Frontal Stage 1 Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0001:1A	Driver Frontal Stage 1 Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0001:2B	Driver Frontal Stage 1 Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0001:4A	Driver Frontal Stage 1 Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:11	Driver Frontal Stage 2 Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:12	Driver Frontal Stage 2 Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:13	Driver Frontal Stage 2 Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:1A	Driver Frontal Stage 2 Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:2B	Driver Frontal Stage 2 Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0002:4A	Driver Frontal Stage 2 Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:11	Passenger Frontal Stage 1 Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:12	Passenger Frontal Stage 1 Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:13	Passenger Frontal Stage 1 Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:1A	Passenger Frontal Stage 1 Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:2B	Passenger Frontal Stage 1 Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0010:4A	Passenger Frontal Stage 1 Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0011:11	Passenger Frontal Stage 2 Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0011:12	Passenger Frontal Stage 2 Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0011:13	Passenger Frontal Stage 2 Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0011:1A	Passenger Frontal Stage 2 Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0011:2B	Passenger Frontal Stage 2 Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0011:4A	Passenger Frontal Stage 2 Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0020:11	Left Side Airbag Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0020:12	Left Side Airbag Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0020:13	Left Side Airbag Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0020:1A	Left Side Airbag Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0020:2B	Left Side Airbag Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0020:4A	Left Side Airbag Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0028:11	Right Side Airbag Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0028:12	Right Side Airbag Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0028:13	Right Side Airbag Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0028:1A	Right Side Airbag Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0028:2B	Right Side Airbag Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0028:4A	Right Side Airbag Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:11	Driver Seatbelt Sensor: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:12	Driver Seatbelt Sensor: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:13	Driver Seatbelt Sensor: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:1D	Driver Seatbelt Sensor: Circuit Current Out Of Range	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:2B	Driver Seatbelt Sensor: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0050:4A	Driver Seatbelt Sensor: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0052:11	Passenger Seatbelt Sensor: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0052:12	Passenger Seatbelt Sensor: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0052:13	Passenger Seatbelt Sensor: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0052:1D	Passenger Seatbelt Sensor: Circuit Current Out Of Range	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0052:2B	Passenger Seatbelt Sensor: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0052:4A	Passenger Seatbelt Sensor: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0090:11	Left Frontal Restraints Sensor: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0090:4A	Left Frontal Restraints Sensor: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0090:81	Left Frontal Restraints Sensor: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0090:93	Left Frontal Restraints Sensor: No Operation	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0090:96	Left Frontal Restraints Sensor: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0091:11	Left Side Restraints Sensor 1: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0091:4A	Left Side Restraints Sensor 1: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0091:81	Left Side Restraints Sensor 1: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0091:93	Left Side Restraints Sensor 1: No Operation	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0091:96	Left Side Restraints Sensor 1: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0095:11	Right Frontal Restraints Sensor: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0095:4A	Right Frontal Restraints Sensor: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0095:81	Right Frontal Restraints Sensor: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0095:93	Right Frontal Restraints Sensor: No Operation	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0095:96	Right Frontal Restraints Sensor: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0096:11	Right Side Restraints Sensor 1: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0096:4A	Right Side Restraints Sensor 1: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0096:81	Right Side Restraints Sensor 1: Invalid Serial Data Received	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0096:93	Right Side Restraints Sensor 1: No Operation	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B0096:96	Right Side Restraints Sensor 1: Component Internal Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:09	Occupant Classification System: Component Failures	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:4A	Occupant Classification System: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:63	Occupant Classification System: Circuit/Component Protection Time-Out	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:64	Occupant Classification System: Signal Plausibility Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00A0:68	Occupant Classification System: Event Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00B5:11	Driver Seat Track Position Restraints Sensor: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00B5:12	Driver Seat Track Position Restraints Sensor: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00B5:13	Driver Seat Track Position Restraints Sensor: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00B5:1D	Driver Seat Track Position Restraints Sensor: Circuit Current Out Of Range	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00B5:2B	Driver Seat Track Position Restraints Sensor: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00B5:4A	Driver Seat Track Position Restraints Sensor: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00D5:11	Restraint System Passenger Disable Indicator: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00D5:12	Restraint System Passenger Disable Indicator: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00D5:13	Restraint System Passenger Disable Indicator: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B00D5:4A	Restraint System Passenger Disable Indicator: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1015	CEI Unconfigured	Instrument Cluster (IC)	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B106A	TPMS Sensor Pressure Range Bit Incorrect State	Smart Junction Box (SJB)	REFER to WHEELS & TIRES .
B106B	Tire Pressure Sensor Low Battery	SJB	REFER to WHEELS & TIRES .
B106E	Solid State Driver Disabled Due to Short Circuit	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
B106E	Solid State Driver Disabled Due to Short Circuit	SJB	REFER to SMART JUNCTION BOX (SJB) .
B106F	Module Disabled Due to External Fault	SJB	REFER to SMART JUNCTION BOX (SJB) .
B1031	SDARS Satellite Antenna Open	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1032	SDARS Satellite Antenna Short	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1139	Invalid Transmitter Identification Code	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1193:00	Crash Event Storage Full and Locked: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1202	Fuel Sender Circuit Open	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
B1204	Fuel Sender Circuit Short to Ground	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
B1212:11	Driver Seatbelt Buckle Pretensioner Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1212:12	Driver Seatbelt Buckle Pretensioner Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1212:13	Driver Seatbelt Buckle Pretensioner Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1212:1A	Driver Seatbelt Buckle Pretensioner Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1212:2B	Driver Seatbelt Buckle Pretensioner Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1212:4A	Driver Seatbelt Buckle Pretensioner Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213	Anti-Theft Number of Programmed Keys is Below Minimum	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B1213:11	Passenger Seatbelt Buckle Pretensioner Deployment Control: Circuit Short To Ground	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213:12	Passenger Seatbelt Buckle Pretensioner Deployment Control: Circuit Short To Battery	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213:13	Passenger Seatbelt Buckle Pretensioner Deployment Control: Circuit Open	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213:1A	Passenger Seatbelt Buckle Pretensioner Deployment Control: Circuit Resistance Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213:2B	Passenger Seatbelt Buckle Pretensioner Deployment Control: Signal Cross Coupled	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1213:4A	Passenger Seatbelt Buckle Pretensioner Deployment Control: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1231	Event Threshold Exceeded	Occupant Classification System Module (OCSM)	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1302	Accessory Delay Relay Coil Circuit Failure	SJB	REFER to GLASS, FRAMES AND MECHANISMS .
B1304	Accessory Delay Relay Coil Circuit Short to Battery	SJB	REFER to GLASS, FRAMES AND MECHANISMS .
B1309	Power Door Lock Circuit Short to Ground	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1317	Battery Voltage High	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1317	Battery Voltage High	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
B1317	Battery Voltage High	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1317	Battery Voltage High	SJB	REFER to SMART JUNCTION BOX (SJB) .
B1318	Battery Voltage Low	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1318	Battery Voltage Low	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
B1318	Battery Voltage Low	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1318	Battery Voltage Low	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1318	Battery Voltage Low	SJB	REFER to SMART JUNCTION BOX (SJB) .
B1319	Driver Door Ajar Circuit Failure	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1322	Driver Door Ajar Circuit Short to Ground	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1322	Driver Door Ajar Circuit Short to Ground	SJB	REFER to INTERIOR LIGHTING .
B1330	Passenger Door Ajar Circuit Short to Ground	SJB	REFER to INTERIOR LIGHTING .
B1338	Door Ajar RR Circuit Short to Ground	SJB	REFER to INTERIOR LIGHTING .
B1341	Power Door Unlock Circuit Short to Ground	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B1342	ECU is Faulted	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1342	ECU is Faulted	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B1342	ECU is Faulted	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
B1342	ECU is Faulted	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B1342	ECU is Faulted	PCM	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new PCM. REFER to ELECTRONIC ENGINE CONTROLS . TEST the system for normal operation.
B1342	ECU is Faulted	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
B1342	ECU is Faulted	SJB	REFER to SMART JUNCTION BOX (SJB) .
B1352	Ignition Key-In Circuit Failure	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
B1359	Ignition Run/Acc Circuit Failure	SJB	REFER to STEERING COLUMN SWITCHES .
B1363	Ignition Start Circuit Failure	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
B1470	Lamp Headlamp Input Circuit Failure	SJB	REFER to EXTERIOR LIGHTING .
B1483	Brake Pedal Input Circuit Failure	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1485	Brake Pedal Input Short to Battery	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1522	Hood Switch Circuit Short to Ground	SJB	DISREGARD the DTC. It is not applicable to this vehicle. The SJB may be incorrectly configured or the SJB may be at fault. CLEAR the DTCs. REPEAT the self-test.
B1555	Ignition Run/Start Circuit Failure	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
B1555	Ignition Run/Start Circuit Failure	SJB	REFER to STEERING COLUMN SWITCHES .
B1569	Lamp Headlamp High-Beam Circuit Short to Battery	SJB	REFER to EXTERIOR LIGHTING .
B1574	Door Ajar LR Circuit Short to Ground	SJB	REFER to INTERIOR LIGHTING .
B1596	Service Continuous Codes	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B1600	PATS Ignition Key Transponder Signal is Not Received	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B1601	PATS Received Incorrect Key-Code From Ignition Key Transponder	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B1602	PATS Received Invalid Format of Key-Code From Ignition Key Transponder	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B1676	Battery Pack Voltage Out Of Range	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B1681	PATS Transceiver Module Signal is Not Received	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B1688	Lamp Dome Input Circuit Short to Ground	SJB	REFER to INTERIOR LIGHTING .
B1868	Lamp Air Bag Warning Indicator Circuit Failure	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
B1897	Horn Switch Circuit Failure	SJB	REFER to HORN .
B2030	Front Fog Lamp Relay Ckt Failure	SJB	REFER to EXTERIOR LIGHTING .
B2103	Antenna Not Connected	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B2141	NVM Configuration Failure	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B2143	NVM Memory Failure	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
B2143	NVM Memory Failure	SJB	REFER to SMART JUNCTION BOX (SJB) .
B2207	ECU ROM Checksum Error	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
B2261	Park Lamp Switch Failure	SJB	REFER to EXTERIOR LIGHTING .
B2276	Less Than 2 Transmitters Programmed	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2290	Occupant Classification System Fault	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2425	Remote Keyless Entry Out of Synchronization	SJB	REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS .
B2431	Transponder Programming Failed	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
B2472	Fog Lamp Switch Failure	SJB	REFER to EXTERIOR LIGHTING .
B2477	Module Configuration Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B2477	Module Configuration Failure	IC	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	SDARS module	REFER to MODULE CONFIGURATION .
B2477	Module Configuration Failure	SJB	REFER to MODULE CONFIGURATION .
B2512	Front Fog Lamp Relay Ckt Short to Battery	SJB	REFER to EXTERIOR LIGHTING .
B2572	Brake Shift Interlock Output Circuit Failure	IC	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION EXTERNAL CONTROLS .
B2675	Trip Reset Button Stuck	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
B2844	Ignition Fault	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
B2868	Left Front Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B2869	Right Front Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B2870	Right Rear Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B2871	Left Rear Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B2872	Tire Pressure Sensor Fault	SJB	REFER to WHEELS & TIRES .
B287A	Tire Pressure System Fault	SJB	REFER to WHEELS & TIRES .
B2900	VIN Mismatch	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
B2909	Belt Tension Sensor Fault	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
B2973	Daytime Running Lamp Output Shorted to Ground	SJB	REFER to EXTERIOR LIGHTING .
C1125	Brake Fluid Level Sensor Input Circuit Failure	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
C1126		SJB	REFER to CRUISE CONTROL .
C1145	Speed Wheel Sensor RF Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1155	Speed Wheel Sensor LF Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1165	Speed Wheel Sensor RR Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C116A	ABS Pressure Transducer/Brake Switch Mismatch	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1175	Speed Wheel Sensor LR Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1222	Speed Wheel Mismatch	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1266	ABS Valve Power Relay Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1278	Steering Wheel Angle 1 and 2 Signal Faulted	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1280	Yaw Rate Sensor Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1282	Lateral Accelerometer Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1288	Pressure Transducer Main/Primary Input Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1296	Wheel Speed LF Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1297	Wheel Speed RF Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1298	Wheel Speed RR Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1299	Wheel Speed LR Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1300	ABS Pump Motor Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1440	Pressure Transducer Main/Primary Signal Faulted	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1446	Brake Switch Circuit Failure	SJB	REFER to WHEELS & TIRES .
C1516	Roll Rate Sensor Signal Fault	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1728	Transfer Case Unable to Transition Between 2H and 4H	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
C1729	Transfer Case Unable to Transition Between 4H and 4L	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
C1805	Mismatched PCM and/or ABS-TC Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1941	Zero Seat Weight Test Failure	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
C1956	Steering Angle Sensor Circuit Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1963	Stability Control Inhibit Warning	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C1975	IVD Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C2770	Longitudinal Acceleration Sensor Plausibility Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C2775	TC/AYC ON/OFF Switch Stuck Failure	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
C2780	ECU in Manufacturer Sub-State	SJB	REFER to WHEELS & TIRES .
C2784	RAM Checksum Failure	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
P0645	Air Conditioning Clutch Relay (A/CCR) Control Circuit	PCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
P0705	Transmission Range Sensor A Circuit (PRNDL Input)	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0708	Transmission Range Sensor A Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0711	Transmission Fluid Temperature Sensor A Circuit Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0712	Transmission Fluid Temperature Sensor A Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0713	Transmission Fluid Temperature Sensor A Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0715	Turbine/Input Shaft Speed Sensor A Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0717	Turbine/Input Shaft Speed Sensor A Circuit No Signal	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0718	Turbine/Input Shaft Speed Sensor A Circuit Intermittent	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0720	Output Shaft Speed Sensor Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0721	Output Shaft Speed Sensor Circuit Range/Performance	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0722	Output Shaft Speed Sensor Circuit No Signal	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0731	Gear 1 Incorrect Ratio	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0732	Gear 2 Incorrect Ratio	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0733	Gear 3 Incorrect Ratio	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0734	Gear 4 Incorrect Ratio	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0735	Gear 5 Incorrect Ratio	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0740	Torque Converter Clutch Solenoid Circuit/Open	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0741	Torque Converter Clutch Solenoid Circuit Performance Or Stuck Off	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0743	Torque Converter Clutch Solenoid Circuit Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0748	Pressure Control Solenoid A Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0750	Shift Solenoid A	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0753	Shift Solenoid A Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0755	Shift Solenoid B	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0758	Shift Solenoid B Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0760	Shift Solenoid C	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0763	Shift Solenoid C Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0765	Shift Solenoid D	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0768	Shift Solenoid D Electrical	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0791	Intermediate Shaft Speed Sensor A Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0794	Intermediate Shaft Speed Sensor A Circuit Intermittent	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0960	Pressure Control Solenoid A Control Circuit/Open	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0962	Pressure Control Solenoid A Control Circuit Low	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P0963	Pressure Control Solenoid A Control Circuit High	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1116	Engine Coolant Temperature Sensor Out Of Self Test Range	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1124	Throttle Position Sensor A Out Of Self Test Range	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1260	Theft Detected, Vehicle Immobilized	PCM	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
P1460	Wide Open Throttle A/C Cutout Circuit	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1464	A/C Demand Out Of Self Test Range	PCM	REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS .
P1636	Inductive Signature Chip Communication Error	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1702	Transmission Range Sensor Circuit Intermittent	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1703	Brake Switch Out Of Self Test Range	PCM	REFER to CRUISE CONTROL .
P1704	Transmission Range Circuit Not Indicating Park/Neutral During Self Test	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1705	Transmission Range Circuit Not Indicating Park/Neutral During Self Test	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1707	Transfer Case Neutral or Park/Neutral Indication Circuit	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1711	Transmission Fluid Temperature Sensor Out Of Self Test Range	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1713	Transmission Fluid Temperature Sensor In Range Failure (	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1714	Shift Solenoid A Inductive Signature	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1715	Shift Solenoid B Inductive Signature	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1716	Shift Solenoid C Inductive Signature	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1717	Shift Solenoid D Inductive Signature	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1729	Shift 4x4L Switch	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1740	Torque Converter Clutch Solenoid Inductive Signature	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1780	Transmission Control Switch (O/D Cancel) Circuit Out Of Self Test Range	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1781	4x4L Circuit Out Of Self Test Range	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1783	Transmission Overtemperature Condition	PCM	REFER to AUTOMATIC TRANSAXLE/TRANSMISSION - 5R44E AND 5R55E .
P1812	4-Wheel Drive Mode Select Circuit Failure	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1815	4-Wheel Drive Mode Select Short Circuit to Ground	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1816	Transmission Neutral Safety Switch Circuit Failure	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1819	Transmission Neutral Safety Switch Short Circuit to Ground	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1849	Transfer Case Contact Plate A Short Circuit to Ground	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1853	Transfer Case Contact Plate B Short Circuit to Ground	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1857	Transfer Case Contact Plate C Short Circuit to Ground	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1861	Transfer Case Contact Plate D Short Circuit to Ground	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1867	Transfer Case Contact Plate General Circuit Failure	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
P1891	Transfer Case Contact Plate Ground Return Open Circuit	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
PXXXX	All other DTCs	PCM	REFER to the INTRODUCTION - GASOLINE MODELS .
U0002	High Speed CAN Communication Bus Performance	IC	REFER to MODULE COMMUNICATIONS NETWORK .
U0028:08	Vehicle Communication Bus A: Bus Signal/Message Failures	RCM	REFER to MODULE COMMUNICATIONS NETWORK .
U0028:88	Vehicle Communication Bus A: Bus Off	RCM	REFER to MODULE COMMUNICATIONS NETWORK .
U0073	Control Module Communication Bus A Off	ABS module	REFER to MODULE COMMUNICATIONS NETWORK .
U0100	Lost Communication With ECM /PCM	4X4 control module	REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS .
U0100	Lost Communication With ECM /PCM	ABS module	REFER to MODULE COMMUNICATIONS NETWORK .
U0100	Lost Communication With ECM /PCM	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
U0100	Lost Communication With ECM /PCM	SJB	REFER to SMART JUNCTION BOX (SJB) .
U0100:00	Lost Communication With ECM /PCM "A": No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0101	Lost Communication with TCM	ABS module	REFER to MODULE COMMUNICATIONS NETWORK .
U0102	Lost Communication with Transfer Case Control Module (4x4CM)	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
U0114	Lost Communication With Four-Wheel Drive Clutch Control Module	ABS module	REFER to MODULE COMMUNICATIONS NETWORK .
U0121	Lost Communication With Anti-Lock Brake System (ABS) Control Module	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
U0140	Lost Communication With Body Control Module ( GEM )	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
U0151	Lost Communication With Restraints Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0151	Lost Communication With Restraints Control Module	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
U0151	Lost Communication With Restraints Control Module	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0154:00	Lost Communication With Restraints Occupant Classification System Module: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	ABS module	REFER to MODULE COMMUNICATIONS NETWORK .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	SJB	REFER to SMART JUNCTION BOX (SJB) .
U0155:00	Lost Communication With Instrument Panel Cluster ( IPC ) Control Module: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0184	Lost Communication With Radio ( ACM )	SDARS module	REFER to INFORMATION AND ENTERTAINMENT SYSTEMS .
U0253:00	Lost Communication With Accessory Protocol Interface Module: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0300:00	Internal Control Module Software Incompatibility: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0401	Invalid Data Received from ECM /PCM A	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0401:00	Invalid Data Received from ECM /PCM A: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U0402	Invalid Data Received from TCM	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0414	Invalid Data Received from Four-Wheel Drive Clutch Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0423	Invalid Data Received From Instrument Panel Cluster Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0452	Invalid Data Received From Restraints Control Module	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U0554:00	Invalid Data Received From Accessory Protocol Interface Module: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U2023	Fault Received From External Node	IC	RETRIEVE and FOLLOW non-network DTCs from other modules.
U2023	Fault Received From External Node	SJB	RETRIEVE and FOLLOW non-network DTCs from other modules.
U2050	No Application Present	4X4 control module	REFER to MODULE CONFIGURATION .
U2050	No Application Present	ABS module	REFER to VEHICLE DYNAMIC SYSTEMS .
U2050	No Application Present	IC	REFER to MODULE CONFIGURATION .
U2050	No Application Present	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U2050	No Application Present	SDARS module	REFER to MODULE CONFIGURATION .
U2050	No Application Present	SJB	REFER to MODULE CONFIGURATION .
U2051	One or More Calibration Files Missing/Corrupt	OCSM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U2100:00	Initial Configuration Not Complete: No Sub Type Information	RCM	REFER to MODULE CONFIGURATION .
U2200:00	Control Module Configuration Memory Corrupt: No Sub Type Information	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U2472	Unexpected Ignition State	IC	REFER to INSTRUMENTATION AND WARNING CHIMES .
U2510	CAN - Invalid Data for Vehicle Security	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
U2511	CAN - Data Mis-Match (Receive Data Does Not Match Expected)	IC	REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .
U3000:46	Control Module: Calibration/Parameter Memory Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3000:49	Control Module: Internal Electronic Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3000:4A	Control Module: Incorrect Component Installed	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3002:62	Vehicle Identification Number: Signal Compare Failure	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3003:16	Battery Voltage: Circuit Voltage Below Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .
U3003:17	Battery Voltage: Circuit Voltage Above Threshold	RCM	REFER to SUPPLEMENTAL RESTRAINT SYSTEM .

DIAGNOSTIC TROUBLE CODE CHART

Inspection and Verification

Verify the customer concern.
Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Battery Junction Box (BJB) fuse 5 (50A) Smart Junction Box (SJB) fuse 11 (10A) Wiring, terminals or connectors
If an obvious cause of an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
NOTE: Make sure to use the latest scan tool software release. If the cause is not visually evident, connect the scan tool to the Data Link Connector (DLC).
NOTE: The Vehicle Communication Module (VCM) prove-out confirms power and ground from the DLC are provided to the VCM . If the scan tool does not communicate with the VCM : Check the VCM connection to the vehicle. Check the scan tool connection to the VCM . Refer to «MODULE COMMUNICATIONS NETWORK»(ref-365388) , No Power To The Scan Tool, to diagnose no power to the scan tool.
If the scan tool does not communicate with the vehicle: Verify the ignition key is in the ON position. Verify the scan tool operation with a known good vehicle. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-365388) to diagnose no response from the PCM.
Carry out the network test. If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(ref-365388) . If the network test passes, retrieve and record the continuous memory DTCs.
Clear the continuous DTCs and carry out the self-test diagnostics for the SJB .
If the DTCs retrieved are related to the concern, go to «DTC CHARTS»(ref-365389-S41317676432010070700000) . For all other DTCs, refer to «DIAGNOSTIC TROUBLE CODE (DTC) CHART»(ref-365389-S21247533702010070700000) .
If no DTCs related to the concern are retrieved, GO to «SYMPTOM CHART»(ref-365389-S24901554322010070700000) .

DTC Charts

Smart Junction Box (SJB) DTC Chart

DTC	Description	Action
B106E	Solid State Driver Disabled Due to Short Circuit	GO to PINPOINT TEST A .
B106F	Module Disabled Due to External Fault	GO to PINPOINT TEST A .
B1317	Battery Voltage High	GO to PINPOINT TEST B .
B1318	Battery Voltage Low	GO to PINPOINT TEST C .
B1342	ECU is Faulted	CLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new Smart Junction Box (SJB). REFER to SMART JUNCTION BOX (SJB) . TEST the system for normal operation.
B2143	NVM Memory Failure	CLEAR the DTCs. REPEAT the self-test. If DTC B2143 is retrieved again, INSTALL a new SJB . REFER to SMART JUNCTION BOX (SJB) . TEST the system for normal operation.
U0100	Lost Communication With ECM /PCM	GO to PINPOINT TEST D .
U0155	Lost Communication With Instrument Panel Cluster ( IC ) Control Module	GO to PINPOINT TEST E .
All other DTCs		REFER to DIAGNOSTIC TROUBLE CODE (DTC) CHART .

SMART JUNCTION BOX DTC CHART

Symptom Chart

Condition	Possible Sources	Action
No communication with the Smart Junction Box	Fuse Wiring, terminals (SJB) or connectors SJB	REFER to MODULE COMMUNICATIONS NETWORK , The SJB Does Not Respond To The Scan Tool.

SYMPTOM CHART

PINPOINT TEST A: DTCs B106E, B106F

Note. If DTC B106F is present and the Smart Junction Box (SJB) is being replaced, the fault condition must be corrected first. Failure to correct the fault condition first causes damage to the new SJB , resulting in a repeat repair.

A1 REVIEW THE DTCs Review the DTCs from the SJB self-test. Are only DTC B106E and DTC B106F present? Yes: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-365389-S19136733192010070700000) . TEST the system for normal operation. No: CORRECT any DTCs present other than DTC B106E and DTC B106F. REFER to «DIAGNOSTIC TROUBLE CODE (DTC) CHART»(ref-365389-S21247533702010070700000) . After the repair, GO to A2 .
A2 CARRY OUT THE SJB SELF-TEST Carry out the SJB self-test. Is DTC B106F present? Yes: INSTALL a new SJB . Refer to «SMART JUNCTION BOX (SJB)»(ref-365389-S19136733192010070700000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern was caused by a fault in one of the output circuits.

Pinpoint Test B: DTC B1317

Refer to SYSTEM WIRING DIAGRAMS , Remote Keyless Entry and Alarm for schematic and connector information.

Note. DTC B1317 may be stored in the module memory due to previous battery charging or vehicle jump starting events.

B1 CHECK FOR DTC B1317, B1676 OR P0563 SET IN OTHER MODULES Ignition ON. Enter the following diagnostic mode on the scan tool: (All Modules) Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC B1317, B1676 or P0563 (PCM) set in more than one module? Yes: REFER to «CHARGING SYSTEM»(ref-365377) to diagnose an overcharging condition. No: GO to B2 .
B2 CHECK THE BATTERY VOLTAGE Turn off all interior/exterior lights and accessories. Start and run the engine at approximately 2,000 RPM for 3 minutes while monitoring the battery voltage. Does the battery voltage rise to 15 volts or higher? Yes: REFER to «CHARGING SYSTEM»(ref-365377) to diagnose an overcharging condition. No: GO to B3 .
B3 RECHECK FOR DTC B1317 Turn the engine off. Ignition ON. Enter the following diagnostic mode on the scan tool: SJB Self-Test. Clear the continuous memory DTCs. Carry out the SJB self-test. Is DTC B1317 present? Yes: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-365389-S19136733192010070700000) . TEST the system for normal operation. No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.

Pinpoint Test C: DTC B1318

Refer to SYSTEM WIRING DIAGRAMS , Remote Keyless Entry and Alarm for schematic and connector information.

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Note. Failure to disconnect the battery when instructed will result in false resistance readings. Refer to BATTERY, MOUNTING AND CABLES .

Scheme 56

Scheme 56: PINPOINT TEST C: DTC B1318

Scheme 57

C1 RECHECK THE SJB DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: SJB Self-Test. Clear the DTCs. Repeat the SJB self-test. Is DTC B1318 still present? Yes: GO to C2 . No: The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.
C2 CHECK FOR CHARGING SYSTEM DTCs IN THE PCM Enter the following diagnostic mode on the scan tool: PCM Self-Test. Retrieve the continuous memory DTCs from the PCM. Is DTC P0620, P0625, P0626 or P065B set in the PCM? Yes: REFER to «CHARGING SYSTEM»(ref-365377) . No: GO to C3 .
C3 CHECK THE BATTERY CONDITION AND STATE OF CHARGE Ignition OFF. Check the battery condition and verify the battery is fully charged. Refer to «BATTERY, MOUNTING AND CABLES»(ref-365408) . Is the battery OK and fully charged? Yes: GO to C4 . No: REFER to «CHARGING SYSTEM»(ref-365377) .
C4 CHECK THE SJB VOLTAGE SUPPLY Measure and record the voltage at the battery. Disconnect: SJB C2280A. Ignition ON. Measure the voltage between the SJB C2280A-1, circuit SBB01 (RD), harness side and ground. Is the voltage within 0.2 volt of the recorded battery voltage? Yes: GO to C5 . No: REPAIR the circuit for high resistance. CLEAR the DTC. REPEAT the self-test.
C5 CHECK THE SJB GROUND CIRCUIT Ignition OFF. Disconnect: Negative Battery Cable. Disconnect: SJB C2280C. Measure the resistance between the SJB C2280C-1, circuit GD174 (BK/WH), harness side and ground. Is the resistance less than 5 ohms? Yes: CONNECT the negative battery cable. GO to C6 . No: REPAIR the circuit for high resistance. CONNECT the negative battery cable. TEST the system for normal operation.
C6 CHECK FOR CORRECT SJB OPERATION Disconnect all the SJB connectors. Check for: corrosion damaged pins pushed-out pins Connect all the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-365389-S19136733192010070700000) . TEST the system for normal operation. No: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.

Pinpoint Test D: DTC U0100

Refer to SYSTEM WIRING DIAGRAMS , Module Communications Network for schematic and connector information.

D1 VERIFY CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: GO to D2 . No: The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
D2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the PCM pass the network test? Yes: GO to D3 . No: REFER to «MODULE COMMUNICATIONS NETWORK»(ref-365388) .
D3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded SJB DTCs from the self-test. Is DTC B1317 or DTC B1318 recorded? Yes: For DTC B1317, GO to «PINPOINT TEST B»(ref-365389-S24168559712010070700000) . For DTC B1318, GO to «PINPOINT TEST C»(ref-365389-S14258204742010070700000) . No: GO to D4 .
D4 RECHECK THE SJB DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or PMI may not have been carried out. Clear the DTCs. Repeat the SJB self-test. Is DTC U0100 still present? Yes: GO to D5 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
D5 CHECK FOR DTC U0100/U0100:00 SET IN OTHER MODULES Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0100/U0100:00 set in the 4X4 control module, ABS module, IC, SJB or RCM? Yes: INSTALL a new PCM. REFER to «ELECTRONIC ENGINE CONTROLS»(ref-365395) . No: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-365389-S19136733192010070700000) .

Pinpoint Test E: DTC U0155

Refer to SYSTEM WIRING DIAGRAMS , Module Communications Network for schematic and connector information.

E1 VERIFY CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes: GO to E2 . No: The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
E2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the IC pass the network test? Yes: GO to E3 . No: REFER to «MODULE COMMUNICATIONS NETWORK»(ref-365388) .
E3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded SJB DTCs from the self-test. Is DTC B1317 or DTC B1318 recorded? Yes: For DTC B1317, GO to «PINPOINT TEST B»(ref-365389-S24168559712010070700000) . For DTC B1318, GO to «PINPOINT TEST C»(ref-365389-S14258204742010070700000) . No: GO to E4 .
E4 RECHECK THE SJB DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the SJB self-test. Is DTC U0155 still present? Yes: GO to E5 . No: The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
E5 CHECK FOR DTC U0155/U0155:00 SET IN OTHER MODULES Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0155/U0155:00 set in the ABS module, SJB or RCM? Yes: INSTALL a new IC . REFER to «INSTRUMENTATION AND WARNING CHIMES»(ref-365392) . No: INSTALL a new SJB . REFER to «SMART JUNCTION BOX (SJB)»(ref-365389-S19136733192010070700000) .

Scheme 58

Scheme 58: Smart Junction Box (SJB)

Item	Part Number	Description
1		Smart Junction Box (SJB) electrical connectors (part of 14401)
2		SJB screws (3 required)
3	15604	SJB

PART NUMBER REFERENCE

Multifunction Electronic Modules: Diagnosis Ford Ranger II рестайлинг
