Starting System: Other Ford Ranger II

Starter Motor

The starter motor

1. is a permanent-magnet, gear reduction, 12V DC motor.
2. has an integral starter solenoid.

Starter Relay

The starter relay

1. is a mini ISO relay. switches power to the starter solenoid to engage the starter motor when it is provided a ground through the powertrain control module (PCM).

Clutch Pedal Position (CPP) Switch

The CPP switch (manual transmission only)

1. provides a signal to the PCM when the clutch pedal is depressed.

Component Tests

Always make the Rotunda 73 Digital Multimeter connections at the component terminal rather than at the wiring end connector. Making a connection at the wiring end connector could result in false readings because the meter will not pick up a high resistance between the wiring connector and the component.

Scheme 26

Scheme 27

1. Make sure the battery is fully charged. Refer to «CHARGING SYSTEM - GENERAL INFORMATION»(ref-268768) article.
2. Disconnect the inertia fuel shutoff (IFS) switch.
3. Connect a remote starter switch between the starter solenoid S terminal and the battery positive (+) terminal.
4. Connect the Digital Multimeter positive lead to the battery positive (+) post. Connect negative lead to the starter solenoid M-terminal. Item Part Number Description 1 - S terminal 2 - Remote starter switch 3 10653 Battery 4 - Rotunda 73 Digital Multimeter 5 - B terminal 6 - M terminal
5. Engage the remote starter switch. Read and record the voltage. The voltage reading should be 0.5 volt or less.
6. If the voltage reading is 0.5 volt or less, go to the Starter Motor-Ground Circuit Component Test.
7. If the voltage reading is greater than 0.5 volt, indicating excessive resistance, move the Rotunda 73 Digital Multimeter negative lead to the starter solenoid B terminal and repeat the test. If the voltage reading at the B terminal is lower than 0.5 volt, the concern is either in the connections at the starter solenoid or in the solenoid contacts. Item Part Number Description 1 - S terminal 2 - Remote starter switch 3 10653 Battery 4 - Rotunda 73 Digital Multimeter 5 - B terminal 6 - M terminal
8. Remove the cables from solenoid B and S terminals. Clean the cables and connections and reinstall the cables to the correct terminals. Repeat Steps 3 through 6. If the voltage drop reading is still greater than 0.5 volt when checked at the M terminal and less than 0.5 volt when checked at the B terminal, the concern is in the solenoid contacts. Install a new starter motor.
9. If the voltage reading taken at the solenoid B terminal is still greater than 0.5 volt after cleaning the cables and connections at the solenoid, the concern is either in the positive (+) battery cable connection or in the positive battery cable itself.
10. By moving the Rotunda 73 Digital Multimeter toward the battery and checking each mechanical connection point, the excessive voltage drop can be located. When the high reading disappears, the last mechanical point that was checked is the concern. Repair or install a new connection as required.

Starter Motor - Ground Circuit

A slow cranking condition can be caused by resistance in the ground or return portion of the cranking circuit. Check the voltage drop in the ground circuit as follows

1. Disconnect the idle adjusting screw.
2. Connect a remote starter switch between the starter solenoid S-terminal and the battery positive (+) terminal.
3. Connect the Rotunda 73 Digital Multimeter positive lead to the starter motor housing (the connection must be clean and free of rust or grease). Connect the negative lead to the negative (-) battery terminal.
4. Engage the remote starter switch and crank the engine. Read and record the voltage reading. The reading should be 0.2 volt or less.
5. If the voltage drop is more than 0.2 volt, clean the negative cable connections at the battery and body connections, and retest.
6. If the voltage drop is greater than 0.2 volt, determine which way the current is flowing in the cable. Connect the Rotunda 73 Digital Multimeter positive lead to the end of the cable nearest battery positive.
7. Connect the multimeter negative lead to the terminal at the other end of the cable.
8. Crank the engine and observe the voltage reading. The voltage reading should be 0.2 volt or lower. If the voltage drop is too high, clean the terminal ends. Retest, and if the voltage is still high, install a new cable. If the voltage reading is less than 0.2 volt and the engine still cranks slowly, install a new starter motor.

Scheme 28

Scheme 29

1. Remove the starter motor. For additional information, refer to «Starter Motor - 2.3L»(ref-268731-S13102722962007102600000) , «Starter Motor - 3.0L»(ref-268731-S17747180462007102600000) or «Starter Motor - 4.0L»(ref-268731-S41430859792007102600000) in this article.
2. Check the wear patterns on the starter drive gear and the flywheel ring gear. If the wear pattern is normal, install the starter motor. For additional information, refer to «Starter Motor - 2.3L»(ref-268731-S13102722962007102600000) , «Starter Motor - 3.0L»(ref-268731-S17747180462007102600000) or «Starter Motor - 4.0L»(ref-268731-S41430859792007102600000) in this article.
3. If the starter drive gear and the flywheel ring gear are not fully meshing and both of the gears are scored or damaged, install a new starter motor. For additional information, refer to «Starter Motor - 2.3L»(ref-268731-S13102722962007102600000) , «Starter Motor - 3.0L»(ref-268731-S17747180462007102600000) or «Starter Motor - 4.0L»(ref-268731-S41430859792007102600000) in this article. If necessary, install a new flywheel. Refer to the appropriate Engine article for the procedure.

Scheme 30
