Multifunction Electronic Modules System: Diagnosis Ford Ranger II

Communication Devices 1 illustration ~683 words

Diagnostic Trouble Code (DTC) Chart

Note. Most powertrain (P-code) DTCs are diagnosed in the Powertrain Control/Emissions Diagnosis (PC/ED) manual. If the P-code retrieved is not listed below, refer to the INTRODUCTION - GASOLINE ENGINES article to continue diagnostics.

DTCDescriptionSourceAction
B106ATPMS Sensor Pressure Range Bit Incorrect StateSmart Junction Box (SJB)REFER to WHEELS AND TIRES article.
B106BTire Pressure Sensor Low BatterySJBREFER to WHEELS AND TIRES article.
B106ESolid State Driver Disabled Due to Short CircuitSJBREFER to Smart Junction Box (SJB) in this article.
B106FModule Disabled Due to External FaultSJBREFER to Smart Junction Box (SJB) in this article.
B1015CEI UnconfiguredInstrument ClusterREFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article.
B1118Passenger Front Crash Sensor Mount/Communication FaultRestraints Control Module (RCM)REFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
B1135Passenger Front Crash Sensor Internal FaultRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
B1139Invalid Transmitter Identification CodeSJBREFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article.
B1202Fuel Sender Circuit OpenInstrument ClusterREFER to INSTRUMENT CLUSTER article.
B1204Fuel Sender Circuit Short to GroundInstrument ClusterREFER to INSTRUMENT CLUSTER article.
B1213Anti-Theft Number of Programmed Keys is Below MinimumInstrument ClusterREFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article.
B1231Event Threshold ExceededOccupant Classification ModuleINSTALL a new occupant classification module. REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. TEST the system for normal operation.
B1231Event Threshold ExceededRCMINSTALL a new RCM. REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. TEST the system for normal operation.
B1302Accessory Delay Relay Coil Circuit FailureSJBREFER to GLASS, FRAMES AND MECHANISMS article.
B1304Accessory Delay Relay Coil Circuit Short to BatterySJBREFER to GLASS, FRAMES AND MECHANISMS article.
B1309Power Door Lock Circuit Short to GroundSJBREFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article.
B1317Battery Voltage HighAnti-Lock Brake System (ABS) ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
B1317Battery Voltage HighFour-Wheel Drive (4WD) Control ModuleREFER to CHARGING SYSTEM - GENERAL INFORMATION article.
B1317Battery Voltage HighInstrument ClusterREFER to CHARGING SYSTEM - GENERAL INFORMATION article.
B1317Battery Voltage HighOccupant Classification ModuleREFER to CHARGING SYSTEM - GENERAL INFORMATION article.
B1317Battery Voltage HighRCMREFER to CHARGING SYSTEM - GENERAL INFORMATION article.
B1317Battery Voltage HighSJBREFER to CHARGING SYSTEM - GENERAL INFORMATION article.
B1318Battery Voltage LowABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
B1318Battery Voltage LowInstrument ClusterREFER to CHARGING SYSTEM - GENERAL INFORMATION article.
B1318Battery Voltage LowOccupant Classification ModuleREFER to CHARGING SYSTEM - GENERAL INFORMATION article.
B1318Battery Voltage LowRCMREFER to CHARGING SYSTEM - GENERAL INFORMATION article.
B1318Battery Voltage LowSJBREFER to CHARGING SYSTEM - GENERAL INFORMATION article.
B1318Battery Voltage Low4WD Control ModuleREFER to CHARGING SYSTEM - GENERAL INFORMATION article.
B1319Driver Door Ajar Circuit Failure4WD Control ModuleREFER to INTERIOR LIGHTING article.
B1322Driver Door Ajar Circuit Short to GroundSJBREFER to INTERIOR LIGHTING article.
B1322Driver Door Ajar Circuit Short to Ground4WD Control ModuleREFER to INTERIOR LIGHTING article.
B1330Passenger Door Ajar Circuit Short to GroundSJBREFER to INTERIOR LIGHTING article.
B1338Door Ajar RR Circuit Short to GroundSJBREFER to INTERIOR LIGHTING article.
B1341Power Door Unlock Circuit Short to GroundSJBREFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article.
B1342ECU is FaultedABS ModuleCLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new ABS module. REFER to VEHICLE DYNAMIC SYSTEMS article. TEST the system for normal operation.
B1342ECU is FaultedInstrument ClusterCLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new instrument cluster. REFER to INSTRUMENT CLUSTER article. TEST the system for normal operation.
B1342ECU is FaultedOccupant Classification ModuleCLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new occupant classification module. REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. TEST the system for normal operation.
B1342ECU is FaultedRCMCLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new RCM. REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. TEST the system for normal operation.
B1342ECU is FaultedSJBCLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new SJB. REFER to Smart Junction Box (SJB) in this article. TEST the system for normal operation.
B1342ECU is Faulted4WD Control ModuleCLEAR the DTCs. REPEAT the self-test. If DTC B1342 is retrieved again, INSTALL a new 4WD control module. REFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article. TEST the system for normal operation.
B1352Ignition Key-In Circuit FailureInstrument ClusterREFER to WARNING DEVICES article.
B1359Ignition Run/Acc Circuit FailureSJBREFER to STEERING COLUMN SWITCHES article.
B1363Ignition Start Circuit FailureInstrument ClusterREFER to INSTRUMENT CLUSTER article.
B1398Driver Power Window One Touch Window Relay Circuit FailureSJBREFER to GLASS, FRAMES AND MECHANISMS article.
B1400Driver Power Window One Touch Window Relay Circuit Short to BatterySJBREFER to GLASS, FRAMES AND MECHANISMS article.
B1405Driver Power Window Down Circuit Short to BatterySJBREFER to GLASS, FRAMES AND MECHANISMS article.
B1408Driver Power Window Up Circuit Short to BatterySJBREFER to GLASS, FRAMES AND MECHANISMS article.
B1410Driver Power Window Motor Circuit FailureSJBREFER to GLASS, FRAMES AND MECHANISMS article.
B1431Wiper Brake/Run Relay Circuit FailureSJBREFER to WIPERS AND WASHERS article.
B1432Wiper Brake/Run Relay Circuit Short to BatterySJBREFER to WIPERS AND WASHERS article.
B1434Wiper Hi/Low Speed Relay Coil Circuit FailureSJBREFER to WIPERS AND WASHERS article.
B1436Wiper Hi/Low Speed Relay Coil Circuit Short to BatterySJBREFER to WIPERS AND WASHERS article.
B1438Wiper Mode Select Switch Circuit FailureSJBREFER to WIPERS AND WASHERS article.
B1446Wiper Park Sense Circuit FailureSJBREFER to WIPERS AND WASHERS article.
B1458Wiper Washer Pump Motor Relay Circuit FailureSJBREFER to WIPERS AND WASHERS article.
B1460Wiper Washer Pump Motor Relay Coil Circuit Short to BatterySJBREFER to WIPERS AND WASHERS article.
B1466Wiper Hi/Low Speed Not SwitchingSJBREFER to WIPERS AND WASHERS article.
B1470Lamp Headlamp Input Circuit FailureSJBREFER to EXTERIOR LIGHTING article.
B1483Brake Pedal Input Circuit Failure4WD Control ModuleREFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article.
B1485Brake Pedal Input Short to Battery4WD Control ModuleREFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article.
B1485Brake Pedal Input Short to BatteryABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
B1522Hood Switch Circuit Short to GroundSJBDISREGARD the DTC. It is not applicable for North American market.
B1555Ignition Run/Start Circuit Failure4WD Control ModuleREFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article.
B1555Ignition Run/Start Circuit FailureSJBREFER to STEERING COLUMN SWITCHES article.
B1569Lamp Headlamp High-Beam Circuit Short to BatterySJBREFER to EXTERIOR LIGHTING article.
B1574Door Ajar LR Circuit Short to GroundSJBREFER to INTERIOR LIGHTING article.
B1600PATS Ignition Key Transponder Signal is Not ReceivedInstrument ClusterREFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article.
B1601PATS Received Incorrect Key-Code From Ignition Key TransponderInstrument ClusterREFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article.
B1602PATS Received Invalid Format of Key-Code From Ignition Key TransponderInstrument ClusterREFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article.
B1681PATS Transceiver Module Signal is Not ReceivedInstrument ClusterREFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article.
B1688Lamp Dome Input Circuit Short to GroundSJBREFER to INTERIOR LIGHTING article.
B1840Wiper Front Power Circuit FailureSJBREFER to WIPERS AND WASHERS article.
B1871Passenger Air Bag Disable Module FaultRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
B1884PAD Warning Lamp Circuit FailureRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
B1890PAD Warning Lamp Circuit Short to BatteryRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
B1897Horn Switch Circuit FailureSJBREFER to HORN article.
B2030Front Fog Lamp Relay CKT FailureSJBREFER to EXTERIOR LIGHTING article.
B2143NVM Memory FailureInstrument ClusterREFER to INSTRUMENT CLUSTER article.
B2143NVM Memory FailureSJBCLEAR the DTCs. REPEAT the self-test. If DTC B2143 is retrieved again, INSTALL a new SJB. REFER to Smart Junction Box (SJB) in this article. TEST the system for normal operation.
B2179Front Wiper Selector Switch "A" Short to GroundSJBREFER to WIPERS AND WASHERS article.
B2180Front Wiper Selector Switch "B" Short to GroundSJBREFER to WIPERS AND WASHERS article.
B2181Front Wiper Selector Switch "C" Short to GroundSJBREFER to WIPERS AND WASHERS article.
B2183Front Wiper Selector Switch "H" Short to GroundSJBREFER to WIPERS AND WASHERS article.
B2184Front Wiper Selector Switch "W" Short to GroundSJBREFER to WIPERS AND WASHERS article.
B2207ECU ROM Checksum ErrorInstrument ClusterCLEAR the DTCs. REPEAT the self-test. If DTC B2207 is retrieved again, INSTALL a new instrument cluster. REFER to INSTRUMENT CLUSTER article. TEST the system for normal operation.
B2261Park Lamp Switch FailureSJBREFER to EXTERIOR LIGHTING article.
B2276Less Than 2 Transmitters ProgrammedSJBREFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article.
B2290Occupant Classification System FaultOccupant Classification ModuleREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
B2290Occupant Classification System FaultRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
B2292Restraint System - Seatbelt Pretensioner FaultRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
B2293Restraint System - Airbag FaultRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
B2425Remote Keyless Entry Out of SynchronizationSJBREFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS article.
B2434Drivers Seat Belt Buckle Switch Circuit Short to GroundRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
B2435Drivers Seat Belt Buckle Switch Resistance Out of RangeRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
B2438Passengers Seat Belt Buckle Switch Circuit Short to GroundRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
B2439Passengers Seat Belt Buckle Switch Resistance Out of RangeRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
B2472Fog Lamp Switch FailureSJBREFER to INTERIOR LIGHTING article.
B2477Module Configuration FailureInstrument ClusterREFER to MODULE CONFIGURATION article.
B2477Module Configuration FailureSJBREFER to MODULE CONFIGURATION article.
B2477Module Configuration FailureRCMREFER to MODULE CONFIGURATION article.
B2512Front Fog Lamp Relay CKT Short to BatterySJBREFER to EXTERIOR LIGHTING article.
B2607Harness/Configuration MismatchRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
B2675Trip Reset Button StuckInstrument ClusterCLEAR the DTCs. REPEAT the self-test. If DTC B2675 is retrieved again, INSTALL a new instrument cluster. REFER to INSTRUMENT CLUSTER article. TEST the system for normal operation.
B2691Seat Belt Buckle Switch Circuit Fault, Front Driver's SideRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
B2692Front Passenger's Seat Belt Buckle Switch Circuit FaultRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
B2792Cross Link Between Firing LoopsRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
B2868Left Front Tire Pressure Sensor FaultSJBThis DTC is only present when a new SJB is installed, the SJB is flashed, or the SJB is reconfigured. REFER to WHEELS AND TIRES article to CARRY OUT the tire pressure monitoring system (TPMS) sensor training in order to CLEAR the DTC.
B2869Right Front Tire Pressure Sensor FaultSJBThis DTC is only present when a new SJB is installed, the SJB is flashed, or the SJB is reconfigured. REFER to WHEELS AND TIRES article to CARRY OUT the tire pressure monitoring system (TPMS) sensor training in order to CLEAR the DTC.
B2870Right Rear Tire Pressure Sensor FaultSJBThis DTC is only present when a new SJB is installed, the SJB is flashed, or the SJB is reconfigured. REFER to WHEELS AND TIRES article to CARRY OUT the tire pressure monitoring system (TPMS) sensor training in order to CLEAR the DTC.
B2871Left Rear Tire Pressure Sensor FaultSJBThis DTC is only present when a new SJB is installed, the SJB is flashed, or the SJB is reconfigured. REFER to WHEELS AND TIRES article to CARRY OUT the tire pressure monitoring system (TPMS) sensor training in order to CLEAR the DTC.
B2872Tire Pressure Sensor FaultSJBREFER to WHEELS AND TIRES article.
B2885Spare Tire Pressure Sensor FaultSJBREFER to WHEELS AND TIRES article.
B287ATire Pressure System FaultSJBREFER to WHEELS AND TIRES article.
B2973Daytime Running Lamp Output Shorted to GroundSJBREFER to EXTERIOR LIGHTING article.
C1095ABS Hydraulic Pump Motor Circuit FailureABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1096ABS Hydraulic Pump Motor Circuit OpenABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1126Cruise Control Command Switch Assembly Circuit FailureSJBREFER to SPEED CONTROL article.
C1145Speed Wheel Sensor RF Input Circuit FailureABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1148Speed Wheel Sensor RF Coherency FaultABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1155Speed Wheel Sensor LF Input Circuit FailureABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1158Speed Wheel Sensor LF Coherency FaultABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1186ABS Power Relay Output Open CircuitABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1187Brake Fluid Level Sensor Input Open CircuitABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1194ABS Outlet Valve Coil LF Circuit FailureABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1198ABS Inlet Valve Coil LF Circuit FailureABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1210ABS Outlet Valve Coil RF Circuit FailureABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1214ABS Inlet Valve Coil RF Circuit FailureABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1221Lamp ABS Warning Output Circuit Short to GroundInstrument ClusterREFER to INSTRUMENT CLUSTER article.
C1226Lamp Brake Warning Output Circuit Short to GroundInstrument ClusterREFER to INSTRUMENT CLUSTER article.
C1229Speed Wheel Sensor Rear Center Coherency FaultABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1230Speed Wheel Sensor Rear Center Input Circuit FailureABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1233Speed Wheel LF Input Signal MissingABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1234Speed Wheel RF Input Signal MissingABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1237Speed Wheel Rear Input Signal MissingABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1246ABS Outlet Valve Coil RR Circuit FailureABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1254ABS Inlet Valve Coil RR Circuit FailureABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1266ABS Valve Power Relay Circuit FailureABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1414Incorrect Module Design LevelABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1414Incorrect Module Design LevelRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
C1446Brake Switch Circuit FailureSJBREFER to EXTERIOR LIGHTING article.
C1728Transfer Case Unable to Transition Between 2H and 4H4WD Control ModuleREFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article.
C1729Transfer Case Unable to Transition Between 4H and 4L4WD Control ModuleREFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article.
C1941Zero Seat Weight Test FailureOccupant Classification ModuleREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
C1946Front Driver's Seat Track Position Switch Circuit OpenRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
C1947Front Driver's Seat Track Position Switch Circuit Short to GroundRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
C1948Front Driver's Seat Track Position Switch Circuit Resistance Out of RangeRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
C1949Accelerometer Sensor Circuit OpenABS ModuleCLEAR the DTCs. REPEAT the self-test. If DTC C1949 is retrieved again, INSTALL a new ABS module. REFER to VEHICLE DYNAMIC SYSTEMS article. TEST the system for normal operation.
C1950Accelerometer Sensor Circuit FailureABS ModuleREFER to VEHICLE DYNAMIC SYSTEMS article.
C1981Front Driver's Seat Track Position Switch Circuit FaultRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
C2780ECU in Manufacturer Sub-StateSJBThis DTC is only present when a new SJB is installed, the SJB is flashed, or the SJB is reconfigured. REFER to WHEELS AND TIRES article to CARRY OUT the tire pressure monitoring system (TPMS) sensor training in order to CLEAR the DTC.
C2784RAM Checksum FailureInstrument ClusterCLEAR the DTCs. REPEAT the self-test. If DTC C2784 is retrieved again, INSTALL a new instrument cluster. REFER to INSTRUMENT CLUSTER article. TEST the system for normal operation.
P1260Theft Detected, Vehicle ImmobilizedPowertrain Control Module (PCM)REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article.
P1707Transfer Case Neutral or Park/Neutral Indication Circuit4WD Control ModuleREFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article.
P18124-Wheel Drive Mode Select Circuit Failure4WD Control ModuleREFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article.
P18154-Wheel Drive Mode Select Short Circuit to Ground4WD Control ModuleREFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article.
P1816Transmission Neutral Safety Switch Circuit Failure4WD Control ModuleREFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article.
P1819Transmission Neutral Safety Switch Short Circuit to Ground4WD Control ModuleREFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article.
P1849Transfer Case Contact Plate A Short Circuit to Ground4WD Control ModuleREFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article.
P1853Transfer Case Contact Plate B Short Circuit to Ground4WD Control ModuleREFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article.
P1857Transfer Case Contact Plate C Short Circuit to Ground4WD Control ModuleREFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article.
P1861Transfer Case Contact Plate D Short Circuit to Ground4WD Control ModuleREFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article.
P1867Transfer Case Contact Plate General Circuit Failure4WD Control ModuleREFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article.
P1891Transfer Case Contact Plate Ground Return Open Circuit4WD Control ModuleREFER to FOUR WHEEL DRIVE (4WD) SYSTEMS article.
PXXXXAll other DTCsPCMREFER to the INTRODUCTION - GASOLINE ENGINES article.
U0002High Speed CAN Communication Bus PerformanceInstrument ClusterREFER to MODULE COMMUNICATIONS NETWORK article.
U0100Lost Communication With ECM/PCM4WD Control ModuleREFER to MODULE COMMUNICATIONS NETWORK article.
U0100Lost Communication With ECM/PCMInstrument ClusterREFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article.
U0100Lost Communication With ECM/PCMSJBREFER to MODULE COMMUNICATIONS NETWORK article.
U0102Lost Communication with Transfer Case Control Module (4x4CM)Instrument ClusterREFER to INSTRUMENT CLUSTER article.
U0140Lost Communication With Body Control Module (GEM)Instrument ClusterREFER to INSTRUMENT CLUSTER article.
U0151Lost Communication With Restraints Control ModuleInstrument ClusterREFER to INSTRUMENT CLUSTER article.
U0155Lost Communication With Instrument Panel Cluster (IC) Control ModuleSJBREFER to INSTRUMENT CLUSTER article.
U0300Internal Control Module Software IncompatibilityRCMREFER to SUPPLEMENTAL RESTRAINT SYSTEM article.
U1900CAN Communication Bus Fault - Receive ErrorRCMREFER to MODULE COMMUNICATIONS NETWORK article.
U2023Fault Received From External NodeInstrument ClusterREFER to MODULE COMMUNICATIONS NETWORK article.
U2023Fault Received From External Node4WD Control ModuleREFER to MODULE COMMUNICATIONS NETWORK article.
U2023Fault Received From External NodeSJBRETRIEVE and FOLLOW non-network DTCs from other modules.
U2050No Application Present4WD Control ModuleREFER to MODULE CONFIGURATION article.
U2050No Application PresentInstrument ClusterREFER to MODULE CONFIGURATION article.
U2050No Application PresentOccupant Classification ModuleREFER to MODULE CONFIGURATION article.
U2050No Application PresentRCMREFER to MODULE CONFIGURATION article.
U2050No Application PresentSJBREFER to MODULE CONFIGURATION article.
U2051One or More Calibration Files Missing/CorruptOccupant Classification ModuleCONFIGURE the occupant classification module. REFER to MODULE CONFIGURATION article. CLEAR the DTCs. REPEAT the self-test. If DTC U2051 is retrieved again, INSTALL a new occupant classification module. REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. TEST the system for normal operation.
U2051One or More Calibration Files Missing/CorruptRCMCONFIGURE the RCM. REFER to MODULE CONFIGURATION article. CLEAR the DTCs. REPEAT the self-test. If DTC U2050 is retrieved again, INSTALL a new RCM. REFER to SUPPLEMENTAL RESTRAINT SYSTEM article. TEST the system for normal operation.
U2472Unexpected Ignition StateInstrument ClusterREFER to INSTRUMENT CLUSTER article.
U2510CAN - Invalid Data for Vehicle SecurityInstrument ClusterREFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article.
U2511CAN - Data Mis-Match (Receive Data Does Not Match Expected)Instrument ClusterREFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) article.

Inspection and Verification

  1. Verify the customer concern.
  2. Visually inspect the following for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Battery junction box (BJB) fuse 1 (40A) Smart junction box (SJB) fuse 11 (10A) Circuitry
  3. If an obvious cause of an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
  4. If the cause is not visually evident, connect the scan tool to the data link connector (DLC).
  5. If the scan tool does not communicate with the VCM: Check the VCM connection to the vehicle. Check the scan tool connection to the VCM. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-268766) article, No Power To The Scan Tool, to diagnose no communication with the scan tool.
  6. If the scan tool does not communicate with the vehicle: Verify the ignition key is in the ON position. Verify the scan tool operation with a known good vehicle. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-268766) article to diagnose no response from the powertrain control module (PCM).
  7. Carry out the network test: If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(ref-268766) article. If the network test passes, retrieve and record the continuous memory diagnostic trouble codes (DTCs).
  8. Clear the continuous DTCs and carry out the self-test diagnostics for the SJB.
  9. If the DTCs retrieved are related to the concern, go to the Smart Junction Box (SJB) Diagnostic Trouble Code (DTC) Index. For all other DTCs, refer to «Diagnostic Trouble Code (DTC) Chart»(ref-268767-S09410068082007102600000) in this article.
  10. If no DTCs related to the concern are retrieved, go to «Symptom Chart»(ref-268767-S10748859652007102600000) . SMART JUNCTION BOX (SJB) DIAGNOSTIC TROUBLE CODE (DTC) INDEX DTC Description Action B106E Solid State Driver Disabled Due to Short Circuit Go to «Pinpoint Test A»(ref-268767-S27949831112007102600000) . B106F Module Disabled Due to External Fault Go to «Pinpoint Test A»(ref-268767-S27949831112007102600000) . B2477 Module Configuration Failure CONFIGURE the SJB. REFER to «MODULE CONFIGURATION»(ref-268778) article. CLEAR the DTCs. REPEAT self-test. If DTC B2477 is retrieved again, INSTALL a new SJB. REFER to «Smart Junction Box (SJB)»(ref-268767-S26433317572007102600000) in this article. TEST the system for normal operation. U0100 Lost Communication With ECM/PCM CLEAR the DTCs. CYCLE the key and wait for 10 seconds. REPEAT the self-test. If DTC U0100 is retrieved again, INSTALL a new PCM. REFER to «ELECTRONIC ENGINE CONTROLS»(ref-268735) article. TEST the system for normal operation. U0155 Lost Communication With Instrument Panel Cluster (IC) Control Module CLEAR the DTCs. CYCLE the key and wait for 10 seconds. REPEAT self-test. If DTC U0155 is retrieved again, INSTALL a new instrument cluster. REFER to «INSTRUMENT CLUSTER»(ref-268777) article. TEST the system for normal operation. U2050 No Application Present CONFIGURE the SJB. REFER to «MODULE CONFIGURATION»(ref-268778) article. CLEAR the DTCs. REPEAT self-test. If DTC U2050 is retrieved again, INSTALL a new SJB. REFER to «Smart Junction Box (SJB)»(ref-268767-S26433317572007102600000) in this article. TEST the system for normal operation. All other DTCs - REFER to «Diagnostic Trouble Code (DTC) Chart»(ref-268767-S09410068082007102600000) in this article.

Symptom Chart

ConditionPossible SourcesAction
The smart junction box (SJB) does not respond to the scan toolFuse Circuitry SJBREFER to MODULE COMMUNICATIONS NETWORK article.

Symptom Chart

PINPOINT TEST A: DTC B106E - SOLID STATE DRIVER DISABLED DUE TO SHORT CIRCUIT

CAUTIONIf DTC B106F is present and the SJB is to be replaced, the fault condition must be corrected first. Failure to correct the fault condition first may cause damage to the new SJB, resulting in a repeat repair.
  1. A1 REVIEW THE DTCs Review the DTCs from the SJB self-test. Are only DTC B106E and DTC B106F present? YES : INSTALL a new SJB. REFER to «Smart Junction Box (SJB)»(ref-268767-S26433317572007102600000) in this article. TEST the system for normal operation. NO : CORRECT any DTCs present other than DTC B106E and DTC B106F. REFER to «Diagnostic Trouble Code (DTC) Chart»(ref-268767-S09410068082007102600000) in this article. After the repair, go to A2 .
  2. A2 CARRY OUT THE SJB SELF-TEST Carry out the SJB self-test. Is DTC B106F present? YES : INSTALL a new SJB. Refer to «Smart Junction Box (SJB)»(ref-268767-S26433317572007102600000) in this article. TEST the system for normal operation. NO : The system is operating correctly at this time. The concern was caused by a fault in one of the output circuits.

Scheme 22

Scheme 22: Smart Junction Box (SJB)
ItemPart NumberDescription
1SJB main electrical connectors (part of 14401)
2Electrical connector (part of 14401)
3SJB screws (3 required)
414B476/15604SJB
