SPECIFICATIONS
| Item | Specification |
|---|---|
| Sealant | |
| Threadlock and Sealer E0AZ-19554-AA | WSK-M2G351-A5 |
| Ultra Silicone Sealant F7TZ-19554-AA | Dana 5-17 |
| Lubricant | |
| MERCON® Multi-Purpose (ATF) Transmission Fluid | XT-2-QDX |
| Capacity | |
| Transfer Case L (Pint) | 1.2 (2.5) |
General Specifications
| Description | Nm |
|---|---|
| Nut retaining the flange to the rear output shaft | 355 |
| Bolt retaining the rear driveshaft to the flange | 111 |
| Shift cam set screw | 9 |
| Shift shaft set screw | 9 |
| Four-wheel drive switch | 42 |
| Bolt retaining the skid plate to the frame | 24 |
| Drain plug | 24 |
| Bolt retaining the driveshaft CV joint to the front output shaft assembly | 30 |
| Bolt retaining the transfer case to the extension housing | 54 |
| Bolt retaining the front adapter to the transfer case | 34 |
| Bolt retaining the transfer case to the transfer case cover | 34 |
| Bolt retaining the transfer case cover to the transfer case | 34 |
| Fill plug | 24 |
TORQUE SPECIFICATIONS
