Cooling System (Mechanical) 54 illustrations ~1953 words

Cap

  1. Inspect the radiator cap or degas bottle cap and seals for damage or deterioration. Install a new radiator cap (8100) or degas bottle cap (8101) if necessary.
  2. Fit the radiator cap to the Radiator/Heater Core Pressure Tester Kit using the aftermarket adapter.
  3. Slowly pump the pressure tester until the pressure gauge stops increasing and note the highest pressure reading. Release the pressure and repeat the test. Install a new radiator cap if the pressure is not 99.3-121.4 kPa (14.4-17.6 psi).

THERMOSTAT - WATER

A new water thermostat should be installed only after the following electrical and mechanical tests have been carried out.

Material

ItemSpecification
Motorcraft Premium Engine Coolant VC-4-A (VC-5 In Oregon, CXC-10 In Canada) (Green Color)ESE-M97B44-A
Motorcraft Premium Gold Engine Coolant VC-7-A (Yellow Color)WSS-M97B51-A1

MATERIAL SPECIFICATION

Filling & Bleeding With RADKITPLUS

  1. Using the special tool, install the RADKITPLUS and follow the RADKITPLUS manufacturer's instructions to fill and bleed the cooling system.

Filling & Bleeding Without RADKITPLUS

CAUTIONEngine coolant provides freeze protection, boil protection, cooling efficiency and corrosion protection to the engine and cooling components. In order to obtain these protections, the engine coolant must be maintained at the correct concentration and fluid level. When adding engine coolant, use a 50/50 mixture of engine coolant and clean drinkable water. To maintain the integrity of the coolant and the cooling system: Add Motorcraft Premium Engine Coolant VC-4-A (VC-5 in Oregon, CXC-10 in Canada) or an equivalent meeting specification ESE-M97B44-A (Green color), or Motorcraft Premium Gold Engine Coolant VC-7-A or equivalent meeting Ford specification WSS-M97B51-A1 (Yellow color). Use the same coolant that was drained from the system. Do not mix coolant types. Do not add Motorcraft Specialty Orange Engine Coolant VC-2 or equivalent meeting Ford specification WSS-M97B44-D. Mixing coolants may degrade the coolant's corrosion protection. Do not add alcohol, methanol, brine or any engine coolants mixed with alcohol or methanol antifreeze. These can cause engine damage from overheating or freezing. Do not mix recycled coolant unless it meets the requirements of specification ESE-M97B44-A or WSSM97B51-A1. Not all coolant recycling processes meet these specifications. Use of such coolants may harm the engine and cooling system components.

Note. The addition of Motorcraft Cooling System Stop Leak Pellets, VC-6, darkens Motorcraft Premium Gold Engine Coolant from Yellow to Golden Tan.

Filling & Bleeding Procedure For Use With Partial Drain

Pinpoint Test C

C8 Filling & Bleeding Procedure For Use With Complete Drain
  1. Filling & Bleeding Procedure For Use With Complete Drain

Scheme 40

Scheme 40: Special Tool(s)
Scheme 40: Special Tool(s)
ItemSpecification
Motorcraft Premium Engine Coolant VC-4-A (In Oregon VC-5, In Canada CXC-10) (Green Color)ESE-M97B44-A
Motorcraft Premium Gold Engine Coolant VC-7-A (In Oregon VC-7-B) (Yellow Color)WSS-M97B51-A1

MATERIAL SPECIFICATIONS

  1. Using the special tool, install the RADKITPLUS and follow the RADKITPLUS manufacturer's instructions to fill and bleed the cooling system.

Filling Without RADKITPLUS

CAUTIONEngine coolant provides freeze protection, boil protection, cooling efficiency and corrosion protection to the engine and cooling components. In order to obtain these protections, the engine coolant must be maintained at the correct concentration and fluid level. When adding engine coolant, use a 50/50 mixture of engine coolant and clean, drinkable water. To maintain the integrity of the coolant and the cooling system: Add Motorcraft Premium Engine Coolant VC-4-A (in Oregon VC-5, in Canada CXC-10) or equivalent meeting Ford specification ESE-M97B44-A (Green color), or Motorcraft Premium Gold Engine Coolant VC-7-A (in Oregon VC-7-B) or equivalent meeting Ford specification WSS-M97B51-A1 (Yellow color). Use the same coolant that was drained from the cooling system. Do not mix coolant types. Do not add Motorcraft Specialty Engine Coolant VC-2 or an equivalent meeting Ford specification WSS-M97B44-D. Mixing coolants may degrade the coolant's corrosion protection. Do not add alcohol, methanol, brine, or any engine coolants mixed with alcohol or methanol antifreeze. These can cause engine damage from overheating or freezing. Do not mix recycled coolant unless it meets the requirements of specification ESE-M97B44-A or WSSM97B51-A1. Not all coolant recycling processes meet these specifications. Use of such coolants may harm the engine and cooling system components.

Note. The addition of Motorcraft Cooling System Stop Leak Pellets, VC-6, darkens Motorcraft Premium Gold Engine Coolant from Yellow to Golden Tan.

Scheme 41

Scheme 41
Scheme 41
  1. Install the lower radiator cover.
  2. Lower the vehicle.
  3. Fill the degas bottle with the correct engine coolant mixture.
  4. Install the pressure relief cap.
  5. Move the temperature blend selector to the full warm position.
  6. Run the engine until it reaches operating temperature.
  7. Add the correct coolant mixture to the degas bottle until the coolant level is between the "COOLANT FILL LEVEL" marks.
  8. Turn off the engine and allow the cooling system to cool. Recheck the coolant level and fill the cooling system to the FULL mark on the degas bottle.
  9. Repeat Steps 3 through 8 until the reservoir level is OK.

Bleeding Without RADKITPLUS

  1. Bleed the cooling system as follows: Select the maximum heater temperature and blower motor speed settings. Position the control to discharge air from the A/C vents in the instrument panel. WARNING: Do not stand in line with or near the engine cooling fan blade when revving the engine. Start the engine and allow it to idle. While the engine is idling, feel for hot air from the A/C vents. CAUTION: If the air discharge remains cool and the engine coolant temperature gauge does not move, the engine coolant level is low in the engine and must be filled. Stop the engine, allow it to cool and fill the cooling system. Start the engine and allow it to idle until the normal operating temperature is reached. Hot air should discharge from the A/C vents. The engine coolant temperature gauge should maintain a stabilized reading in the middle of the NORMAL range and the upper radiator hose should feel hot to the touch. Shut the engine off and allow it to cool. Check the engine for coolant leaks. Check the engine coolant level in the degas bottle and fill it as necessary.
ItemSpecification
Motorcraft Premium Cooling System Flush VC-1 Or EquivalentESR-M14P7-A

MATERIAL SPECIFICATION

  1. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 2.3L»(ref-204985-S18667258522005111600000) or «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 3.0L & 4.0L»(ref-204985-S11979372962005111600000) .
  2. Remove the water thermostat.
  3. Install the water thermostat housing without the water thermostat.
  4. Use an appropriate cooling system flusher to flush the engine and radiator. Use premium cooling system flush.
  5. Install the water thermostat.
  6. Backflush the heater core. For additional information, refer to «HEATER CORE BACKFLUSHING»(ref-204985-S38783522652005111600000) .
  7. Fill the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 2.3L»(ref-204985-S18667258522005111600000) or «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 3.0L & 4.0L»(ref-204985-S11979372962005111600000) .
ItemSpecification
Motorcraft Cooling System Flush VC-1 Or EquivalentESR-M14P7-A

MATERIAL SPECIFICATION

  1. Partially drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 2.3L»(ref-204985-S18667258522005111600000) or «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 3.0L & 4.0L»(ref-204985-S11979372962005111600000) .
  2. Use an appropriate cooling system flusher to back flush the heater core. Use premium cooling system flush.
  3. Fill the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 2.3L»(ref-204985-S18667258522005111600000) or «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 3.0L & 4.0L»(ref-204985-S11979372962005111600000) .

Scheme 42

Scheme 42: Removal
Scheme 42: Removal
  1. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 2.3L»(ref-204985-S18667258522005111600000) or «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 3.0L & 4.0L»(ref-204985-S11979372962005111600000) .
  2. Raise and support the vehicle.
  3. Disconnect the connector.
  4. Remove the block heater (6A051). NOTE: Do not loosen the screw more than necessary for removal. Loosen the screw. Twist and slide the block heater to release the retainer clip and discard the retainer clip. Remove the block heater.

Scheme 43

Scheme 43: Installation
Scheme 43: Installation
  1. To install, reverse the removal procedure.

Scheme 44

Scheme 44: Removal
Scheme 44: Removal

Scheme 45

Scheme 45
Scheme 45
  1. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 3.0L & 4.0L»(ref-204985-S11979372962005111600000) .
  2. Remove the upper radiator hose (8260) from the water outlet connection.
  3. Remove the bolts, the water outlet connection and the water thermostat (8575).
  4. Discard the gasket and clean the sealing surfaces.
ItemSpecification
Motorcraft Premium Gold Engine Coolant VC-7-A (In Oregon VC-7-B, In Canada VC-7-C)WSS-M97B51-A1

MATERIAL SPECIFICATION

Scheme 46

Scheme 46: Removal & Installation
Scheme 46: Removal & Installation

Scheme 47

Scheme 47
Scheme 47
  1. Disconnect the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-204997) .
  2. Remove the air cleaner outlet pipe.
  3. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 2.3L»(ref-204985-S18667258522005111600000) .
  4. Remove the drive belt. For additional information, refer to «SPECIFICATIONS & DRIVE BELT ROUTING»(ref-139084) .
  5. Remove the bolts and the water pump pulley.
  6. Remove the bolts and the water pump.
  7. To install, reverse the removal procedure.

Scheme 48

Scheme 48: Removal
Scheme 48: Removal

Scheme 49

Scheme 49
Scheme 49

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54
  1. Disconnect the battery ground cable (14301). For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-204997) .
  2. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 3.0L & 4.0L»(ref-204985-S11979372962005111600000) .
  3. Remove the air cleaner outlet tube (9B659).
  4. Remove the fan blade (8600) and the fan shroud (8146). For additional information, refer to «SHROUD - 3.0L & 4.0L»(ref-204985-S18304269362005111600000) .
  5. Disconnect the water bypass tube (8555).
  6. Remove the accessory drive belt (8620). For additional information, refer to «SPECIFICATIONS & DRIVE BELT ROUTING»(ref-139084) .
  7. Remove the bolts and the water pump pulley (8509).
  8. Remove the bolts from the A/C compressor mounting bracket (2882).
  9. Disconnect the lower radiator hose.
  10. Remove the bolts and position the bracket and compressor aside.
  11. Remove the bolts and remove the water pump (8501).
  12. Clean the sealing surfaces.

Scheme 55

Scheme 55: Installation
Scheme 55: Installation

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57

Scheme 58

Scheme 58
Scheme 58

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60
Scheme 60
  1. Install the water pump.
  2. Install the A/C compressor mounting bracket.
  3. Install the A/C compressor.
  4. Install the water pump pulley.
  5. Install the accessory drive belt. For additional information, refer to «SPECIFICATIONS & DRIVE BELT ROUTING»(ref-139084) .
  6. Connect the heater hose.
  7. Connect the lower radiator hose.
  8. Install the fan blade and fan shroud. For additional information, refer to «SHROUD - 3.0L & 4.0L»(ref-204985-S18304269362005111600000) .
  9. Install the air cleaner outlet tube.
  10. Connect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-204997) .
  11. Fill the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 3.0L & 4.0L»(ref-204985-S11979372962005111600000) .

Scheme 61

Scheme 61: Removal & Installation
Scheme 61: Removal & Installation

Scheme 62

Scheme 62
Scheme 62

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65

Scheme 66

Scheme 66
Scheme 66
  1. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 3.0L & 4.0L»(ref-204985-S11979372962005111600000) .
  2. Remove the fan shroud. For additional information, refer to «SHROUD - 3.0L & 4.0L»(ref-204985-S18304269362005111600000) .
  3. Remove the accessory drive belt. For additional information, refer to «SPECIFICATIONS & DRIVE BELT ROUTING»(ref-139084) .
  4. Remove the belt idler pulley.
  5. Slide the water bypass hose clamp back.
  6. Disconnect the heater hose at the water pump. Release the clamp. Remove the hose.
  7. Disconnect the lower radiator hose at the water pump. Release the clamp. Remove the hose.
  8. Remove the water pump pulley.
  9. Remove the water pump.
  10. Clean all the sealing surfaces.
  11. To install, reverse the removal procedure.

Scheme 67

Scheme 67: Removal
Scheme 67: Removal

Scheme 68

Scheme 68
Scheme 68

Scheme 69

Scheme 69
Scheme 69

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71
Scheme 71
  1. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 2.3L»(ref-204985-S18667258522005111600000) .
  2. Disconnect the coolant overflow hose from the radiator, position the hose away from the radiator.
  3. Disconnect the upper radiator hose.
  4. Remove the cooling fan and shroud. For additional information, refer to «COOLING FAN MOTOR & SHROUD - 2.3L»(ref-204985-S20168361412005111600000) .
  5. Disconnect the lower radiator hose.
  6. Remove the bolts, tilt the radiator back and lift it directly upward.
  7. Remove the three pushpins and the plastic cap from the top of the radiator channel.

Scheme 72

Scheme 72: Installation
Scheme 72: Installation

Scheme 73

Scheme 73
Scheme 73

Scheme 74

Scheme 74
Scheme 74
  1. Install the plastic cap and the three pushpins on the top of the radiator channel.
  2. Position the radiator into the engine compartment and install the bolts.
  3. Install the lower radiator hose to the radiator.
  4. Install the cooling fan and shroud. For additional information, refer to «COOLING FAN MOTOR & SHROUD - 2.3L»(ref-204985-S20168361412005111600000) .
  5. Install the upper radiator hose to the radiator.
  6. Position the coolant overflow hose in the channel on top of the radiator, then connect the hose to the radiator.
  7. Fill the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 2.3L»(ref-204985-S18667258522005111600000) .
  8. Operate the engine for several minutes and check the hoses and connections for leaks.

Scheme 75

Scheme 75: Removal & Installation
Scheme 75: Removal & Installation

Scheme 76

Scheme 76
Scheme 76

Scheme 77

Scheme 77
Scheme 77

Scheme 78

Scheme 78
Scheme 78

Scheme 79

Scheme 79
Scheme 79
  1. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 3.0L & 4.0L»(ref-204985-S11979372962005111600000) .
  2. Disconnect the radiator overflow hose or radiator vent hose.
  3. Remove the cooling fan and shroud. For additional information, refer to «SHROUD - 3.0L & 4.0L»(ref-204985-S18304269362005111600000) .
  4. Disconnect the upper radiator hose from the radiator.
  5. Disconnect the lower radiator hose from the radiator.
  6. If equipped, disconnect the two transmission cooler lines.
  7. If equipped, disconnect the transmission cooler tubes at the bottom of the radiator.
  8. Remove the bolts and tilt the radiator back and lift directly upward.
  9. To install, reverse the removal procedure.

Scheme 80

Scheme 80: Special Tool(s)
Scheme 80: Special Tool(s)

Scheme 81

Scheme 81
Scheme 81

Scheme 82

Scheme 82
Scheme 82
  1. Remove the air cleaner outlet pipe.
  2. Remove the accessory drive belt. For additional information, refer to «SPECIFICATIONS & DRIVE BELT ROUTING»(ref-139084) .
  3. Using the special tool, loosen the mechanical fan nut.
  4. Remove the fan and clutch assembly.
  5. To install, reverse the removal procedure.

Scheme 83

Scheme 83: Removal & Installation
Scheme 83: Removal & Installation

Scheme 84

Scheme 84
Scheme 84
  1. Remove fan shroud. For additional information, refer to «SHROUD - 3.0L & 4.0L»(ref-204985-S18304269362005111600000) .
  2. Remove the bolts.
  3. Separate the fan blade from the fan clutch.
  4. To install, reverse the removal procedure.
ItemSpecification
Pipe Sealant with Teflon(R) D8AZ-19554-AWSK-M2G350-A2

MATERIAL SPECIFICATION

Scheme 85

Scheme 85: Removal & Installation
Scheme 85: Removal & Installation

Scheme 86

Scheme 86
Scheme 86
  1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-204997) .
  2. Drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 2.3L»(ref-204985-S18667258522005111600000) .
  3. Disconnect the electrical connector.
  4. Remove the engine coolant temperature sender unit.
  5. To install, reverse the removal procedure.
ItemSpecification
Pipe Sealant With Teflon(R) D8AZ-19554-A Or EquivalentWSK-M2G350-A2 & ESRM18P7-A

MATERIAL SPECIFICATION

Scheme 87

Scheme 87: Removal & Installation
Scheme 87: Removal & Installation

Scheme 88

Scheme 88
Scheme 88
  1. Drain the cooling system. For additional information, refer to «ENGINE COOLING»(ref-204985-S12728852082005111600000) .
  2. Disconnect the temperature sending unit wire.
  3. Remove the water temperature indicator sender unit (10884).
  4. To install, reverse the removal procedure.

Scheme 89

Scheme 89: Removal & Installation
Scheme 89: Removal & Installation

Scheme 90

Scheme 90
Scheme 90

Scheme 91

Scheme 91
Scheme 91

Scheme 92

Scheme 92
Scheme 92

Scheme 93

Scheme 93
Scheme 93
  1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-204997) .
  2. Partially drain the cooling system. For additional information, refer to «COOLING SYSTEM DRAINING, FILLING & BLEEDING - 3.0L & 4.0L»(ref-204985-S11979372962005111600000) .
  3. Loosen the clamp and disconnect the air cleaner outlet tube.
  4. Loosen the fitting and disconnect the exhaust manifold-to-Exhaust Gas Recirculation (EGR) valve tube.
  5. Remove the ignition coil bracket bolts.
  6. Remove the intake manifold bolts and position aside the intake manifold.
  7. Disconnect the electrical connector.
  8. Remove the clip and the engine coolant temperature sender unit.
  9. To install, reverse the removal procedure.

More articles — Engine Cooling System
