SPECIFICATIONS
| Item | Specification | Fill Capacity |
|---|---|---|
| Dye-Lite® Gasoline Engine Oil Leak Detection Dye 164-R3700 (Rotunda) | ||
| High Temperature Retaining Compound Loctite® 620™/Permatex® 62050, or equivalent; obtain locally | WSK-M2G349-A9 | |
| Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP (US); Motorcraft® SAE 5W-20 Super Premium Motor Oil CXO-5W20-LSP12 (Canada); or equivalent | WSS-M2C930-A | |
| Motorcraft® SAE 5W-30 Premium Synthetic Blend Motor Oil XO-5W30-QSP (US); Motorcraft® SAE 5W-30 Super Premium Motor Oil CXO-5W30-LSP12 (Canada); or equivalent | WSS-M2C929-A | |
| Motorcraft® SAE 5W-50 Full Synthetic Motor Oil XO-5W50-QGT or equivalent | WSS-M2C931-B | |
| Threadlock 262 TA-26 | WSK-M2G351-A6 |
MATERIAL SPECIFICATIONS
| Description | Nm |
|---|---|
| Variable Camshaft Timing (VCT) oil control solenoid screw | 5 |
TORQUE SPECIFICATIONS
Note. When repairing engines, all parts must be contamination free. If contamination/foreign material is present when repairing an engine, premature engine failure may occur.
Note. Specifications show the expected minimum or maximum condition. Refer to the appropriate Engine article for the procedure.
Note. If a component fails to meet the specifications, it is necessary to refinish it or install a new component. Wear limits are provided as an aid to determine if the component can be refinished. A new component must be installed when any component fails to meet specifications and cannot be refinished.
Note. This service information contains information, steps and procedures that may not be specific to this engine.
This service information covers general procedures and diagnosis and testing of the engine system, except for exhaust emission control devices, which are covered in the ENGINE CONTROLS - INTRODUCTION (EXCEPT DIESEL & HYBRID) (SECTION 0).
The engine incorporates the following features: Refer to the appropriate Engine article for the procedure.
- Crankcase ventilation or breather system
- Exhaust emission control system
- Evaporative Emission (EVAP) control system
Some engines incorporate a fail-safe cooling system. Refer to the appropriate Engine article for the procedure.
The engine, fuel system, ignition system, emissions system and exhaust system all affect exhaust emission levels and must be maintained according to the maintenance schedule. Refer to the scheduled Maintenance Guide.
Correct engine identification is required to order parts. Refer to the appropriate Engine article for the procedure.
For complete vehicle and engine identification codes, refer to IDENTIFICATION CODES.
SPECIAL TOOLS 12-Volt Master UV Diagnostic Inspection Kit 164-R0756 or equivalent (Leak Detector) Dial Indicator Gauge with Holding Fixture 100-002 (TOOL-4201-C) or equivalent EngineEAR 107-R2103 or equivalent EngineEAR/ChassisEAR 107-R2102 or equivalent Oil Pressure Gauge 303-088 (T73L-6600-A) Vacuum/Pressure Tester 164-R0253 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
| Item | Specification |
|---|---|
| Dye-Lite® Gasoline Engine Oil Leak Detection Dye 164-R3700 (Rotunda) | |
| Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil (US); Motorcraft® SAE 5W-20 Super Premium Motor Oil (Canada) XO-5W20-QSP (US); CXO-5W20-LSP12 (Canada) | WSS-M2C945-A |
| Aceite para motor SAE 5W-30 de mezcla sintatica Motorcraft® Premium (EE. UU.);Aceite para motor SAE 5W-30 Motorcraft® Super Premium (Canada) XO-5W30-QSP (EE. UU.); CXO-5W30-LSP12 (Canada) | WSS-M2C946-A |
| Motorcraft® SAE 5W-50 Full Synthetic Motor Oil XO-5W50-QGT or equivalent | WSS-M2C931-B |
MATERIAL SPECIFICATIONS
There are 2 diagnostic paths that can be followed depending on the type of engine concern. Carry out INSPECTION AND VERIFICATION - ENGINE PERFORMANCE or INSPECTION AND VERIFICATION - ENGINE NVH.
See also:
• JACKING & LIFTING
