SPECIFICATIONS
| Item | Specification |
|---|---|
| Maximum starting circuit voltage drop (engine at normal engine temperature) | 0.5 volt |
| Normal engine cranking speed rpm | 100-140 rpm |
| Starter motor no load current draw amperes | 60-80 amps |
| Starter motor normal load current draw | 130 amps |
| Starter motor maximum load current draw amperes | 400 amps |
GENERAL SPECIFICATIONS
| Description | Nm |
|---|---|
| Starter motor bolts (3.7L) | 48 |
| Starter motor bolts (5.0L (4V) & 5.8L (4V)) | 25 |
| Starter motor solenoid B+ terminal nut | 12 |
| Starter motor solenoid S-terminal nut | 5 |
TORQUE SPECIFICATIONS
The starting system consists of the following
- Starter motor
- Starter motor relay (located in the Battery Junction Box (BJB))
- Battery
- Battery cables
- Digital Transmission Range (TR) sensor (automatic transmission-equipped vehicles) (located in the transmission)
- Clutch Pedal Position (CPP) switch (manual transmission-equipped vehicles) (located on the clutch pedal)
- Ignition switch
- PCM (located in the engine compartment, attached to the BJB)
SPECIAL TOOLS Flex Probe Kit NUD105-R025D or equivalent Fluke 77-IV Digital Multimeter FLU77-4 or equivalent
