Special Tool(s)
SPECIAL TOOLS Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A) Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
Scheme 11
SPECIAL TOOLS Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A) Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
SPECIAL TOOLS Socket, Exhaust Gas Oxygen Sensor 303-476 (T94P-9472-A) Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
SPECIAL TOOLS Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
Scheme 12
| Item | Part Number | Description |
|---|---|---|
| 1 | 14A464 | PCM electrical connector (3 required) |
| 2 | W505423 | PCM bolt (2 required) |
| 3 | 12A650 | PCM |
DESCRIPTION CHART
Scheme 13
- Retrieve the module configuration. Carry out the module configuration retrieval steps of the Programmable Module Installation (PMI) procedure. For additional information, refer to «MODULE COMMUNICATIONS NETWORK - MODULE CONFIGURATION»(ref-439797) article.
- Remove the 8 retainers and the radiator sight shield.
- Disconnect the 3 PCM electrical connectors.
- Remove the 2 bolts and the PCM.
