Engine Ignition System - 5.4L (4V): Removal & Installation Ford Mustang V рестайлинг

Removal and Installation

LH ignition coil-on-plugs

1. Remove the Air Cleaner (ACL) outlet pipe. For additional information, refer to «INTAKE AIR DISTRIBUTION SYSTEM & INTAKE AIR FILTERING SYSTEM»(ref-439816) article.
2. Remove the 2 bolts and the LH ignition coil-on-plug cover. Inspect the gasket. Install a new gasket if necessary. To install, tighten to 10 Nm (89 lb-in).
3. Disconnect the 4 LH ignition coil-on-plug electrical connectors.
4. Remove the 4 LH ignition coil-on-plugs, using a twisting motion while pulling up on the ignition coil-on-plug. RH ignition coil-on-plugs
5. Detach the 2 wire harness retainers from the stud bolts.
6. Remove the bolt, stud bolt and the RH ignition coil-on-plug cover. Inspect the gasket. Install a new gasket if necessary. To install, tighten to 10 Nm (89 lb-in).
7. Disconnect the 4 RH ignition coil-on-plug electrical connectors.
8. Remove the 4 RH ignition coil-on-plugs, using a twisting motion while pulling up on the ignition coil-on-plug. All ignition coil-on-plugs
9. To install, reverse the removal procedure

1. Apply a light coat of dielectric grease to the inside of the ignition coil-on-plug boots.

Scheme 11

1. Remove the ignition coil-on-plugs. For additional information, refer to «IGNITION COIL-ON-PLUG»(ref-439826-S01213391382011120900000) in this service information.
2. Remove the 8 spark plugs. To install, tighten to 18 Nm (159 lb-in).
3. Inspect the spark plugs. Install new spark plugs as necessary. For additional information, refer to «ENGINE MECHANICAL SYSTEM - GENERAL INFORMATION»(ref-439783) article.
4. Adjust the spark plug gap as necessary.
5. To install, reverse the removal procedure.
