MATERIAL SPECIFICATIONS
| Item | Specification | Fill Capacity |
|---|---|---|
| Motorcraft® MERCON® LV Automatic Transmission Fluid XT-10-QLVC | MERCON® LV | 12.30L (13.0 qt) |
MATERIAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| A/C condenser retaining bolts | 10 |
| A/C condenser retaining nuts | 8 |
| Degas bottle | 8 |
| Front crossmember brace nuts | 48 |
| Radiator support bracket bolts | 10 |
| Transmission fluid cooler screws | 9 |
| Transmission fluid cooler tube bolt | 25 |
| Transmission fluid cooler tube bracket-to-engine mount nut | 48 |
| Transmission fluid cooler tube bracket-to-fan shroud bolt | 8 |
| Transmission fluid cooler tube bracket-to-transmission nut | 13 |
TORQUE SPECIFICATIONS
Vehicles with automatic transmissions are equipped with a transmission fluid cooler. The transmission fluid cooler transfers heat from the transmission fluid to the ambient air.
For Transmission Fluid Cooler Backflushing and Cleaning, refer to AUTOMATIC TRANSMISSION - 6R80 article.
Scheme 26
| Item | Part Number | Description |
|---|---|---|
| 1 | 7A095 | Transmission fluid cooler |
| 2 | Transmission fluid cooler assembly bracket (part of 7R081) | |
| 3 | 7R081 | Transmission fluid cooler outlet hose |
| 4 | 7R081 | Transmission fluid cooler inlet hose |
| 5 | 7R081 | Transmission fluid cooler tube assembly |
| 6 | Transmission fluid cooler tube assembly bracket (part of 7R081) | |
| 7 | Transmission fluid cooler tube assembly bracket (part of 7R081) | |
| 8 | 7Z465 | Transmission fluid cooler tube quick connect secondary latches |
| 9 | 7006 | Transmission case |
TRANSMISSION FLUID COOLER TUBES REFERENCE (5.0L ENGINE) CHART
Scheme 27
| Item | Part Number | Description |
|---|---|---|
| 1 | 7A095 | Transmission fluid cooler |
| 2 | 7R081 | Transmission fluid cooler inlet hose |
| 3 | 7R081 | Transmission fluid cooler outlet hose |
| 4 | Transmission fluid cooler assembly bracket (part of 7R081) | |
| 5 | 7R081 | Transmission fluid cooler tube assembly |
| 6 | Transmission fluid cooler tube assembly bracket (part of 7R081) | |
| 7 | Transmission fluid cooler tube assembly bracket (part of 7R081) | |
| 8 | 7Z465 | Transmission fluid cooler tube quick connect secondary latches |
| 9 | 7006 | Transmission case |
TRANSMISSION FLUID COOLER TUBES REFERENCE (3.7L ENGINE) CHART
Note. Whenever a transmission has been disassembled to install new parts, a new transmission fluid cooler must be installed and the transmission fluid cooler tubes must be cleaned and backflushed. Refer to Transmission Fluid Cooler Backflushing and Cleaning in AUTOMATIC TRANSMISSION - 6R80 article.
Note. Cleaning and backflushing the transmission fluid cooling system, along with normal cleaning and inspection procedures as outlined in this service information during disassembly and reassembly, will keep contamination from re-entering the transmission and causing a repeat repair. Refer to Transmission Fluid Cooler Backflushing and Cleaning in AUTOMATIC TRANSMISSION - 6R80 article.
When internal wear or damage has occurred in the transmission, metal particles, clutch plate material or band material may have been carried into the torque converter and transmission fluid cooler. These contaminants are a major cause of recurring transmission issues and must be removed from the system before the transmission is put back in use. Refer to Transmission Fluid Cooler Backflushing and Cleaning in AUTOMATIC TRANSMISSION - 6R80 article.
