Automatic Transmission - Automatic Transaxle/transmission - External Controls: Removal & Installation Ford Mustang V рестайлинг

Automatic Trans 13 illustrations ~545 words

Removal and Installation

  1. For additional information, refer to «SELECTOR LEVER»(ref-439821-S39749763232011120900000) in this service information.

Scheme 5

Scheme 5: SELECTOR LEVER CABLE AND BRACKET
ItemPart NumberDescription
17H181Selector lever cable retaining clip
2Selector lever cable routing retainer (part of 7E395)
37E395Selector lever cable
4W500223Selector lever cable bracket bolts (2 required)
57B229Selector lever cable bracket
6Selector lever cable retaining clip (part of 7E395)

ITEM DESCRIPTION REFERENCE

Removal

All vehicles

Pinpoint Test C

C3 Vehicles equipped with a 5.0L (4V) engine
  1. Vehicles equipped with a 5.0L (4V) engine
C4 All vehicles
  1. All vehicles

Installation

All vehicles

Pinpoint Test C

C3 Vehicles equipped with a 5.0L (4V) engine
  1. Vehicles equipped with a 5.0L (4V) engine
C4 CMS
  1. All vehicles

Scheme 6

Scheme 6: Selector Lever
ItemPart NumberDescription
17E391Selector lever bezel
2044D90Floor console finish panel
3W505424Selector lever assembly screws
4W707137Selector lever assembly nuts
57210Selector lever assembly
6045A36Floor console
77E395Selector lever cable
87H181Selector lever cable retaining clip

ITEM DESCRIPTION REFERENCE

Scheme 7

Scheme 7: Removal

Scheme 8

Scheme 8

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 11

Scheme 11

Scheme 12

Scheme 12
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING & LIFTING»(ref-439777) article.
  2. Disconnect the selector lever cable from the selector lever.
  3. Remove the selector lever cable from the selector lever cable bracket and discard the selector lever cable retaining clip.
  4. Remove the selector lever bezel. With a non-marring tool, lift the selector lever bezel upward.
  5. Open the storage compartment door.
  6. Remove the floor console finish panel. Lift the floor console finish panel upward to release the retaining clips. Disconnect the traction/hazard/trunk switch electrical connector. Disconnect the 2 ambient light electrical connectors, if equipped.
  7. Remove the carpet retainer from the selector lever stud and position the carpet.
  8. Detach the wiring harness retainer from the selector lever stud.
  9. Disconnect the selector lever electrical connector.
  10. Remove the 2 selector lever assembly nuts, the 2 selector lever assembly bolts and carefully lift the selector lever assembly from the vehicle.

Scheme 13

Scheme 13

Scheme 14

Scheme 14
  1. Position the selector lever assembly in the vehicle and install the 2 selector lever assembly nuts and the 2 selector lever assembly bolts. Tighten to 9 Nm (80 lb-in).
  2. Connect the selector lever electrical connector.
  3. Attach the wiring harness retainer to the selector lever stud.
  4. Position the carpet and install the carpet retainer to the selector lever stud.
  5. Install the floor console finish panel. Connect the 2 ambient light electrical connectors, if equipped. Connect the traction/hazard/trunk switch electrical connector.
  6. Close the storage compartment door.
  7. Install the selector lever bezel.
  8. Install the selector lever cable into the selector lever cable bracket.
  9. Connect the selector lever cable to the selector lever.
  10. Adjust the selector lever cable. For additional information, refer to «SELECTOR LEVER CABLE ADJUSTMENT»(ref-439821-S36641821892011120900000) in this service information.
  1. For additional information, refer to «SELECTOR LEVER KNOB»(ref-439821-S18819782332011120900000) in this service information.

Scheme 15

Scheme 15: Removal
ItemPart NumberDescription
1W701894Selector lever knob screws (2 required)
27213Selector lever knob
3Selector lever knob shroud (part of 7213)
47210Selector lever assembly

ITEM DESCRIPTION REFERENCE

Scheme 16

Scheme 16

Scheme 17

Scheme 17
  1. Remove the selector lever. For additional information, refer to «SELECTOR LEVER»(ref-439821-S39749763232011120900000) in this service information.
  2. Disconnect the Transmission Control Switch (TCS) electrical connector.
  3. Using a suitable tool, carefully pry the selector lever knob shroud down.
  4. With the selector lever knob shroud down, remove the 2 selector lever knob screws.
  5. Remove the selector lever knob and shroud from the selector shaft.

Pinpoint Test C

C1 TCS
  1. Position the TCS wire towards the back right corner of the selector knob shroud.
  2. Route the TCS wire through the selector lever opening.
