Diagnostic Trouble Code (DTC) Chart
| ABS module | REFER to ANTI-LOCK BRAKE SYSTEM (ABS) AND STABILITY CONTROL . |
|---|---|
| Audio Front Control Module (ACM) | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| Accessory Protocol Interface Module (APIM) | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| Body Control Module B (BCM-B) | REFER to the Body Control Module B (BCM-B) DTC Chart . |
| Front Controls Interface Module (FCIM) | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| Front Display Interface Module (FDIM) | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| Global Positioning System Module (GPSM) | REFER to INFORMATION AND ENTERTAINMENT SYSTEMS . |
| HVAC Module | REFER to CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS . |
| Instrument Panel Cluster (IPC) | REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES . |
| Occupant Classification System Module (OCSM) | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| PCM | REFER to ELECTRONIC ENGINE CONTROLS . |
| Power Steering Control Module (PSCM) | REFER to STEERING SYSTEM . |
| Restraints Control Module (RCM) | REFER to SUPPLEMENTAL RESTRAINT SYSTEM . |
| Smart Junction Box (SJB) | REFER to the SMART JUNCTION BOX (SJB) DTC CHART . |
MASTER DTC CHART INDEX
Inspection and Verification
- Verify the customer concern.
- Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Smart Junction Box (SJB) fuse 5 (10A) Wiring, terminals or connectors SJB
- If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
- NOTE: Make sure to use the latest scan tool software release. If the cause is not visually evident, connect the scan tool to the Data Link Connector (DLC).
- NOTE: The Vehicle Communication Module (VCM) LED prove-out confirms power and ground from the DLC are provided to the VCM. If the scan tool does not communicate with the VCM Check the VCM connection to the vehicle. Check the scan tool connection to the VCM. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-574111) , No Power To The Scan Tool, to diagnose no power to the scan tool.
- If the scan tool does not communicate with the vehicle: Verify the ignition is in the ON state. Verify the scan tool operation with a known good vehicle. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-574111) to diagnose no response from the PCM.
- Carry out the network test. If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(ref-574111) . If the network test passes, retrieve and record the continuous memory DTCs.
- Clear the continuous DTCs and carry out the self-test diagnostics for the SJB.
- If the DTCs retrieved are related to the concern, go to the «Smart Junction Box (SJB) DTC Chart»(ref-574135-S33486518212013082300000) .
- If no DTCs related to the concern are retrieved, GO to «SYMPTOM CHART»(ref-574135-S37638034022013082300000) .
DTC Charts
| DTC | Description | Action |
|---|---|---|
| B106B | Tire Pressure Sensor Low Battery | REFER to WHEELS AND TIRES . |
| B106D | Tire Pressure Monitor System (TPMS) Initiators Not Configured | REFER to WHEELS AND TIRES . |
| B106E | Solid State Driver Disabled Due to Short Circuit | GO to PINPOINT TEST A . |
| B106F | Module Disabled Due to External Fault | GO to PINPOINT TEST A . |
| B1138 | Memory Full | REFER to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) . |
| B1139 | Invalid Transmitter Identification Code | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1302 | Accessory Delay Relay Coil Circuit Failure | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1304 | Accessory Delay Relay Coil Circuit Short To Battery | REFER to GLASS, FRAMES AND MECHANISMS . |
| B1317 | Battery Voltage High | GO to PINPOINT TEST B . |
| B1318 | Battery Voltage Low | GO to PINPOINT TEST C . |
| B1320 | Driver Door Ajar Circuit Open | REFER to INTERIOR LIGHTING . |
| B1328 | Passenger Door Ajar Circuit Open | REFER to INTERIOR LIGHTING . |
| B1331 | Decklid Ajar Rear Door Circuit Failure | REFER to INTERIOR LIGHTING . |
| B1342 | ECU Is Faulted | DIAGNOSE all other DTCs first. If no other DTCs are present, INSTALL a new SJB. REFER to SMART JUNCTION BOX (SJB) . TEST the system for normal operation. |
| B1352 | Ignition Key-In Circuit Failure | REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES . |
| B1472 | Lamp Headlamp Input Circuit Short To Ground | REFER to EXTERIOR LIGHTING . |
| B1485 | Brake Pedal Input Short To Battery | REFER to EXTERIOR LIGHTING . |
| B1510 | Flash To Pass Switch Circuit Short To Ground | REFER to EXTERIOR LIGHTING . |
| B1520 | Hood Switch Circuit Open | REFER to ANTI-THEFT - PERIMETER . |
| B1578 | Lamp Park Input Circuit Short To Ground | REFER to EXTERIOR LIGHTING . |
| B1688 | Lamp Dome Input Circuit Short To Ground | REFER to INTERIOR LIGHTING . |
| B1696 | Autolamp On Circuit Short To Ground | REFER to EXTERIOR LIGHTING . |
| B1791 | Autolamp Sensor Input Circuit Open | REFER to EXTERIOR LIGHTING . |
| B1793 | Autolamp Sensor Input Circuit Short to Ground | REFER to EXTERIOR LIGHTING . |
| B2008 | Wipers On Signal Circuit Short to Ground | REFER to EXTERIOR LIGHTING . |
| B2044 | Left Rear Stop Lamp Circuit Short To Ground | REFER to EXTERIOR LIGHTING . |
| B2046 | Right Rear Stop Lamp Circuit Short To Ground | REFER to EXTERIOR LIGHTING . |
| B2048 | Left Rear Turn Lamp Circuit Short To Ground | REFER to EXTERIOR LIGHTING . |
| B2050 | Right Rear Turn Lamp Circuit Short To Ground | REFER to EXTERIOR LIGHTING . |
| B2071 | Hazard Switch Signal Short To Ground | REFER to EXTERIOR LIGHTING . |
| B2100 | Door Driver Key Cylinder Switch Failure | REFER to ANTI-THEFT - PERIMETER . |
| B2212 | Panel Dim Switch Out of Range | REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION . |
| B2254 | Front Fog Lamp Switch Failure | REFER to EXTERIOR LIGHTING . |
| B2276 | Less Than 2 Transmitters Programmed | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2281 | Right Turn Switch Short To Ground | REFER to EXTERIOR LIGHTING . |
| B2282 | Left Turn Switch Short To Ground | REFER to EXTERIOR LIGHTING . |
| B2425 | Remote Keyless Entry Out of Synchronization | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2477 | Module Configuration Failure | CARRY OUT Programmable Module Installation (PMI) on the SJB. REFER to MODULE CONFIGURATION . |
| B2479 | Park Brake Switch Circuit Short To Ground | REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES . |
| B2498 | Headlamp Switch Multiple Signals Input Active | REFER to EXTERIOR LIGHTING . |
| B2572 | Brake Shift Interlock Output Circuit Failure | REFER to AUTOMATIC TRANSAXLE/TRANSMISSION EXTERNAL CONTROLS . |
| B2844 | Ignition Fault | REFER to STEERING COLUMN SWITCHES . |
| B2868 | Left Front Tire Pressure Sensor Fault | REFER to WHEELS AND TIRES . |
| B2869 | Right Front Tire Pressure Sensor Fault | REFER to WHEELS AND TIRES . |
| B2870 | Right Rear Tire Pressure Sensor Fault | REFER to WHEELS AND TIRES . |
| B2871 | Left Rear Tire Pressure Sensor Fault | REFER to WHEELS AND TIRES . |
| B2872 | Tire Pressure Sensor Fault | REFER to WHEELS AND TIRES . |
| B287A | Tire Pressure System Fault | REFER to WHEELS AND TIRES . |
| B2A20 | Ignition Stuck in START | REFER to STEERING COLUMN SWITCHES . |
| B2A21 | One or More Configuration Files Missing or Corrupt | CARRY out Programmable Module Installation (PMI) on the SJB. REFER to MODULE CONFIGURATION . CLEAR the DTCs. REPEAT the self-test. If DTC B2A21 is retrieved again, INSTALL a new SJB. REFER to SMART JUNCTION BOX (SJB) . TEST the system for normal operation. |
| B2A22 | Headlamp OFF Circuit Open | REFER to EXTERIOR LIGHTING . |
| B2A23 | High Beam Input Circuit Short To Ground | REFER to EXTERIOR LIGHTING . |
| B2A24 | Turn Signal Input Circuit Failure | REFER to EXTERIOR LIGHTING . |
| B2A25 | Trim Panel Lock Switch Circuit Failure | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B2A27 | Right Front Turn Lamp Circuit Open | REFER to EXTERIOR LIGHTING . |
| B2A28 | Right Front Turn Lamp Circuit Short to Ground | REFER to EXTERIOR LIGHTING . |
| B2A29 | Left Front Turn Lamp Circuit Open | REFER to EXTERIOR LIGHTING . |
| B2A2A | Left Front Turn Lamp Circuit Short to Ground | REFER to EXTERIOR LIGHTING . |
| B2A2B | Left Corner Lamp Output Circuit Short to Ground | REFER to EXTERIOR LIGHTING . |
| B2A2C | Right Corner Lamp Output Circuit Short to Ground | REFER to EXTERIOR LIGHTING . |
| B2A2E | Right Front Lamp Low Beam Circuit Open | REFER to EXTERIOR LIGHTING . |
| B2A2F | Right Front Lamp Low Beam Circuit Short to Ground | REFER to EXTERIOR LIGHTING . |
| B2A30 | Left Front Lamp Low Beam Circuit Open | REFER to EXTERIOR LIGHTING . |
| B2A31 | Left Front Lamp Low Beam Circuit Short to Ground | REFER to EXTERIOR LIGHTING . |
| B2A32 | LED Backlighting Output Circuit Open | REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION . |
| B2A33 | LED Backlighting Output Circuit Short to Ground | REFER to INSTRUMENT CLUSTER AND PANEL ILLUMINATION . |
| B2A35 | Interior Lighting Output Circuit Open | REFER to INTERIOR LIGHTING . |
| B2A36 | Interior Lighting Output Circuit Short to Ground | REFER to INTERIOR LIGHTING . |
| B2A38 | Floor Lamp Output Circuit Short to Ground | REFER to INTERIOR LIGHTING . |
| B2A3A | Puddle Lamp Output Circuit Short to Ground | REFER to INTERIOR LIGHTING . |
| P062F | Internal Control Module EEPROM Error | CLEAR the DTCs. REPEAT the self-test. If DTC P062F is retrieved again, INSTALL a new SJB. REFER to SMART JUNCTION BOX (SJB) . TEST the system for normal operation. |
| C1125 | Brake Fluid Level Sensor Input Circuit Failure | REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES . |
| C2780 | ECU in Manufacturer Sub-State | REFER to WHEELS AND TIRES . |
| U0155 | Lost Communication With Instrument Panel Cluster (IC) Control Module | GO to PINPOINT TEST D . |
| U2050 | No Application Present | CARRY out Programmable Module Installation (PMI) on the SJB. REFER to MODULE CONFIGURATION . CLEAR the DTCs. REPEAT the self-test. If DTC U2050 is retrieved again, INSTALL a new SJB. REFER to SMART JUNCTION BOX (SJB) . TEST the system for normal operation. |
| U2472 | Unexpected Ignition State | REFER to STEERING COLUMN SWITCHES . |
| U2473 | Unexpected Vehicle Speed (VSS) | NOTE: Sets during the self-test if vehicle speed exceeds 3 mph (5 kph) or vehicle speed cannot be determined by the SJB. VERIFY the speedometer operates correctly. If the speedometer does not operate correctly, REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES . If the speedometer operates correctly, the self-test is carried out while the vehicle is moving. STOP the vehicle and REPEAT the self-test. |
| NOTE |
|---|
| Sets during the self-test if vehicle speed exceeds 3 mph (5 kph) or vehicle speed cannot be determined by the SJB. |
SMART JUNCTION BOX (SJB) DTC CHART
Symptom Chart
| Condition | Possible Sources | Action |
|---|---|---|
| No communication with the Smart Junction Box (SJB) | Fuse Wiring, terminals or connectors SJB | REFER to MODULE COMMUNICATIONS NETWORK , The SJB Does Not Respond To The Scan Tool. |
SYMPTOM CHART
PINPOINT TEST A: DTCs B106E, B106F
- A1 REVIEW THE DTCs NOTE: First follow the necessary diagnostics to resolve DTC B106E and any other present DTCs (ignoring B106F). DTC B106E is only present when there is another DTC due to software or circuitry issues that must be resolved before another self-test is run. DTC B106F is only present once the final threshold has been met. Failure to correct the fault condition first may cause damage to the new SJB, resulting in a repeat repair. Review the DTCs from the SJB self-test. Are any other DTCs present, besides B106E, B106F or B1342? Yes : CORRECT the DTCs. REFER to the «Smart Junction Box (SJB) DTC chart»(ref-574135-S33486518212013082300000) . After the repair, GO to A2. No : GO to A2.
- A2 REPEAT THE SJB SELF-TEST Ignition ON. Enter the following diagnostic mode on the scan tool: SJB Self-Test. Clear the DTCs and repeat the SJB self-test. Is DTC B106F or DTC B1342 present? Yes : INSTALL a new SJB. REFER to «SMART JUNCTION BOX (SJB)»(ref-574135-S02891211992013082300000) . TEST the system for normal operation. No : The system is operating correctly at this time. The circuit short has been repaired.
Pinpoint Test B: DTC B1317
Refer to SYSTEM WIRING DIAGRAMS , Power Distribution/SJB for schematic and connector information.
Note. DTC B1317 may be stored in the module memory due to previous battery charging or vehicle jump starting events.
- B1 CHECK FOR DTCs B1317, B1676 OR P0563 SET IN OTHER MODULES Ignition ON. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC B1317, B1676 or P0563 (PCM) set in more than one module? Yes : REFER to «CHARGING SYSTEM»(ref-574126) to diagnose an overcharging condition. No : GO to B2.
- B2 CHECK THE BATTERY VOLTAGE Turn off all interior/exterior lights and accessories. Start and run the engine at approximately 2, 000 rpm for 3 minutes while monitoring the battery voltage. Does the battery voltage rise to 15 volts or higher? Yes : REFER to «CHARGING SYSTEM»(ref-574126) to diagnose an overcharging condition. No : GO to B3.
- B3 RECHECK FOR DTC B1317 Turn the engine off. Ignition ON. Enter the following diagnostic mode on the scan tool: SJB Self-Test. Clear the continuous memory DTCs. Carry out the SJB self-test. Is DTC B1317 present? Yes : INSTALL a new SJB. REFER to «SMART JUNCTION BOX (SJB)»(ref-574135-S02891211992013082300000) . TEST the system for normal operation. No : The system is operating normally at this time. The DTC may have been set previously during battery charging or while jump starting the vehicle.
Pinpoint Test C: DTC B1318
Refer to SYSTEM WIRING DIAGRAMS , Power Distribution/SJB for schematic and connector information.
Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.
Note. Failure to disconnect the battery when instructed results in false resistance readings. Refer to BATTERY, MOUNTING AND CABLES .
Scheme 3
Scheme 4
- C1 RECHECK THE SJB DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: SJB Self-Test. Clear the DTCs. Repeat the SJB self-test. Is DTC B1318 still present? Yes : GO to C2. No : The system is operating normally at this time. The DTC may have been set due to a previous low battery voltage condition.
- C2 CHECK FOR CHARGING SYSTEM DTCs IN THE PCM Enter the following diagnostic mode on the scan tool: PCM Self-Test. Carry out the PCM KOEO self-test. Retrieve the continuous memory DTCs from the PCM. Is DTC P0562, P0620, P0622, P0625, P0626 or P065B set in the PCM? Yes : REFER to «CHARGING SYSTEM»(ref-574126) . No : GO to C3.
- C3 CHECK THE BATTERY CONDITION AND STATE OF CHARGE Ignition OFF. Check the battery condition and verify the battery is fully charged. Refer to «BATTERY, MOUNTING AND CABLES»(ref-574143) . Is the battery OK and fully charged? Yes : GO to C4. No : REFER to «CHARGING SYSTEM»(ref-574126) .
- C4 CHECK THE SJB VOLTAGE PID Ignition ON. Measure and record the voltage at the battery. Enter the following diagnostic mode on the scan tool: SJB DataLogger. Monitor the SJB voltage PID (GEM_VBAT). Is the voltage within 0.2 volt of the recorded battery voltage? Yes : GO to C7 . No : GO to C5.
- C5 CHECK THE SJB VOLTAGE SUPPLY Ignition OFF. Disconnect: SJB C2280g. Ignition ON. Measure the voltage between the SJB C2280g-1, circuit SBB01 (RD), harness side and ground. Is the voltage within 0.2 volt of the recorded battery voltage? Yes : GO to C6. No : REPAIR circuit SBB01 (RD) for high resistance. CLEAR the DTC. REPEAT the self-test.
- C6 CHECK THE SJB GROUND CIRCUIT FOR HIGH RESISTANCE Ignition OFF. Disconnect: Negative Battery Cable. Disconnect: SJB C2280d. Measure the resistance between the SJB and ground as follows: SJB Connector-Pin Circuit C2280d-7 GD133 (BK) C2280d-8 GD139 (BK/YE) C2280d-12 GD139 (BK/YE) C2280d-24 GD139 (BK/YE) Are the resistances less than 5 ohms? Yes : GO to C7. No : REPAIR the ground circuit in question for high resistance. CLEAR the DTC. REPEAT the self-test.
- C7 CHECK FOR CORRECT SJB OPERATION Disconnect the SJB connectors. Check for: corrosion damaged pins pushed-out pins Connect the SJB connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new SJB. REFER to «SMART JUNCTION BOX (SJB)»(ref-574135-S02891211992013082300000) . TEST the system for normal operation. No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
PINPOINT TEST D: DTC U0155
- D1 VERIFY CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes : GO to D2. No : The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- D2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the IPC pass the network test? Yes : GO to D3. No : REFER to «MODULE COMMUNICATIONS NETWORK»(ref-574111) , The IPC Does Not Respond To The Scan Tool.
- D3 RETRIEVE THE RECORDED DTCs FROM THE SJB SELF-TEST Check for recorded SJB DTCs from the self-test. Is DTC B1317 or DTC B1318 recorded? Yes : For DTC B1317, GO to «PINPOINT TEST B»(ref-574135-S11100518452013082300000) . For DTC B1318, GO to «PINPOINT TEST C»(ref-574135-S02294566312013082300000) . No : GO to D4.
- D4 RECHECK THE SJB DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the SJB self-test. Is DTC U0155 still present? Yes : GO to D5. No : The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- D5 CHECK FOR DTC U0155 SET IN OTHER MODULES Clear the DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0155 set in any other module? Yes : INSTALL a new IPC. REFER to «INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES»(ref-574138) . No : INSTALL a new SJB. REFER to «SMART JUNCTION BOX (SJB)»(ref-574135-S02891211992013082300000) .
- Verify the customer concern.
- Visually inspect for obvious signs of electrical damage. VISUAL INSPECTION CHART Electrical Battery Junction Box (BJB) fuse 18 (20A) Smart Junction Box (SJB) fuse 35 (10A) Wiring, terminals or connectors Body Control Module B (BCM-B)
- If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
- NOTE: Make sure to use the latest scan tool software release. If the cause is not visually evident, connect the scan tool to the Data Link Connector (DLC).
- NOTE: The Vehicle Communication Module (VCM) LED prove-out confirms power and ground from the DLC are provided to the VCM. If the scan tool does not communicate with the VCM: Check the VCM connection to the vehicle. Check the scan tool connection to the VCM. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-574111) , No Power To The Scan Tool, to diagnose no power to the scan tool.
- If the scan tool does not communicate with the vehicle: Verify the ignition key is in the ON state. Verify the scan tool operation with a known good vehicle. Refer to «MODULE COMMUNICATIONS NETWORK»(ref-574111) to diagnose no response from the PCM.
- Carry out the network test. If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(ref-574111) . If the network test passes, retrieve and record the continuous memory DTCs.
- Clear the continuous DTCs and carry out the self-test diagnostics for the BCM-B.
- If the DTCs retrieved are related to the concern, go to the «Body Control Module B (BCM-B) DTC Chart»(ref-574135-S34534381592013082300000) .
- If no DTCs related to the concern are retrieved, GO to «SYMPTOM CHART»(ref-574135-S37638034022013082300000) .
Note. This module utilizes a 5-character DTC followed by a 2-character failure-type code. The failure-type code provides information about specific fault conditions such as opens, or shorts to ground. Continuous memory DTCs have an additional 2-character DTC status code suffix to assist in determining DTC history.
| DTC | Description | Action |
|---|---|---|
| B109F:08 | Intrusion Sensor Module: Bus Signal/Message Failures | REFER to ANTI-THEFT - PERIMETER . |
| B109F:49 | Intrusion Sensor Module: Internal Electronic Failure | REFER to ANTI-THEFT - PERIMETER . |
| B109F:55 | Intrusion Sensor Module: Not Configured | CARRY OUT Programmable Module Installation (PMI) on the BCM-B. REFER to MODULE CONFIGURATION . |
| B109F:97 | Intrusion Sensor Module: Component Or System Operation Obstructed Or Blocked | REFER to ANTI-THEFT - PERIMETER . |
| B1219:11 | Interior Boot/Trunk Release Switch: Circuit Short To Ground | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1265:23 | Left Rear Turn Lamp Feedback: Signal Stuck Low | REFER to EXTERIOR LIGHTING . |
| B1265:24 | Left Rear Turn Lamp Feedback: Signal Stuck High | REFER to EXTERIOR LIGHTING . |
| B1266:23 | Right Rear Turn Lamp Feedback: Signal Stuck Low | REFER to EXTERIOR LIGHTING . |
| B1266:24 | Right Rear Turn Lamp Feedback: Signal Stuck High | REFER to EXTERIOR LIGHTING . |
| B1267:11 | Convertible/Folding Top Activation Up Switch: Circuit Short To Ground | REFER to CONVERTIBLE TOP . |
| B1268:11 | Convertible/Folding Top Activation Down Switch: Circuit Short To Ground | REFER to CONVERTIBLE TOP . |
| B1269:11 | Convertible/Folding Top Fully Up Position Switch: Circuit Short To Ground | REFER to GLASS, FRAMES AND MECHANISMS . |
| B126D:15 | Convertible/Folding Top Fully Down Position Switch: Circuit Short To Battery Or Open | REFER to GLASS, FRAMES AND MECHANISMS . |
| B126E:23 | Right Rear Window Fully Down Feedback: Signal Stuck Low | REFER to CONVERTIBLE TOP . |
| B126E:24 | Right Rear Window Fully Down Feedback: Signal Stuck High | REFER to CONVERTIBLE TOP . |
| B126F:23 | Left Rear Window Fully Down Feedback: Signal Stuck Low | REFER to CONVERTIBLE TOP . |
| B126F:24 | Left Rear Window Fully Down Feedback: Signal Stuck High | REFER to CONVERTIBLE TOP . |
| B1270:11 | High Mounted Stop Lamp: Circuit Short To Ground | REFER to EXTERIOR LIGHTING . |
| B1270:15 | High Mounted Stop Lamp: Circuit Short To Battery Or Open | REFER to EXTERIOR LIGHTING . |
| B1271:11 | Left Stop/Turn Inner Lamp: Circuit Short To Ground | REFER to EXTERIOR LIGHTING . |
| B1271:15 | Left Stop/Turn Inner Lamp: Circuit Short To Battery Or Open | REFER to EXTERIOR LIGHTING . |
| B1272:11 | Right Stop/Turn Inner Lamp: Circuit Short To Ground | REFER to EXTERIOR LIGHTING . |
| B1272:15 | Right Stop/Turn Inner Lamp: Circuit Short To Battery Or Open | REFER to EXTERIOR LIGHTING . |
| B1273:11 | Right Stop/Turn Middle Lamp: Circuit Short To Ground | REFER to EXTERIOR LIGHTING . |
| B1273:15 | Right Stop/Turn Middle Lamp: Circuit Short To Battery Or Open | REFER to EXTERIOR LIGHTING . |
| B1274:11 | Left Stop/Turn Middle Lamp: Circuit Short To Ground | REFER to EXTERIOR LIGHTING . |
| B1274:15 | Left Stop/Turn Middle Lamp: Circuit Short To Battery Or Open | REFER to EXTERIOR LIGHTING . |
| B1275:11 | Left Stop/Turn Outer Lamp: Circuit Short To Ground | REFER to EXTERIOR LIGHTING . |
| B1275:15 | Left Stop/Turn Outer Lamp: Circuit Short To Battery Or Open | REFER to EXTERIOR LIGHTING . |
| B1276:11 | Right Stop/Turn Outer Lamp: Circuit Short To Ground | REFER to EXTERIOR LIGHTING . |
| B1276:15 | Right Stop/Turn Outer Lamp: Circuit Short To Battery Or Open | REFER to EXTERIOR LIGHTING . |
| B1277:11 | Reverse Lamp: Circuit Short To Ground | REFER to EXTERIOR LIGHTING . |
| B1277:15 | Reverse Lamp: Circuit Short To Battery Or Open | REFER to EXTERIOR LIGHTING . |
| B1278:12 | Convertible/Foldable Top Up Relay: Circuit Short To Battery | REFER to CONVERTIBLE TOP . |
| B1278:14 | Convertible/Foldable Top Up Relay: Circuit Short To Ground Or Open | REFER to CONVERTIBLE TOP . |
| B1279:12 | Convertible/Foldable Top Down Relay: Circuit Short To Battery | REFER to CONVERTIBLE TOP . |
| B1279:14 | Convertible/Foldable Top Down Relay: Circuit Short To Ground Or Open | REFER to CONVERTIBLE TOP . |
| B127A:12 | Global Window Control: Circuit Short To Battery | REFER to GLASS, FRAMES AND MECHANISMS . |
| B127A:14 | Global Window Control: Circuit Short To Ground Or Open | REFER to GLASS, FRAMES AND MECHANISMS . |
| B127B:11 | Ambient Lighting Zone 1 Output Red LED: Circuit Short To Ground | REFER to INTERIOR LIGHTING . |
| B127B:15 | Ambient Lighting Zone 1 Output Red LED: Circuit Short To Battery Or Open | REFER to INTERIOR LIGHTING . |
| B127C:11 | Ambient Lighting Zone 2 Output Red LED: Circuit Short To Ground | REFER to INTERIOR LIGHTING . |
| B127C:15 | Ambient Lighting Zone 2 Output Red LED: Circuit Short To Battery Or Open | REFER to INTERIOR LIGHTING . |
| B127D:11 | Ambient Lighting Zone 3 Output Red LED: Circuit Short To Ground | REFER to INTERIOR LIGHTING . |
| B127D:15 | Ambient Lighting Zone 3 Output Red LED: Circuit Short To Battery Or Open | REFER to INTERIOR LIGHTING . |
| B127E:11 | Ambient Lighting Zone 1 Output Green LED: Circuit Short To Ground | REFER to INTERIOR LIGHTING . |
| B127E:15 | Ambient Lighting Zone 1 Output Green LED: Circuit Short To Battery Or Open | REFER to INTERIOR LIGHTING . |
| B127F:11 | Ambient Lighting Zone 2 Output Green LED: Circuit Short To Ground | REFER to INTERIOR LIGHTING . |
| B127F:15 | Ambient Lighting Zone 2 Output Green LED: Circuit Short To Battery Or Open | REFER to INTERIOR LIGHTING . |
| B1280:11 | Ambient Lighting Zone 3 Output Green LED: Circuit Short To Ground | REFER to INTERIOR LIGHTING . |
| B1280:15 | Ambient Lighting Zone 3 Output Green LED: Circuit Short To Battery Or Open | REFER to INTERIOR LIGHTING . |
| B1281:11 | Ambient Lighting Zone 1 Output Blue LED: Circuit Short To Ground | REFER to INTERIOR LIGHTING . |
| B1281:15 | Ambient Lighting Zone 1 Output Blue LED: Circuit Short To Battery Or Open | REFER to INTERIOR LIGHTING . |
| B1282:11 | Ambient Lighting Zone 2 Output Blue LED: Circuit Short To Ground | REFER to INTERIOR LIGHTING . |
| B1282:15 | Ambient Lighting Zone 2 Output Blue LED: Circuit Short To Battery Or Open | REFER to INTERIOR LIGHTING . |
| B1283:11 | Ambient Lighting Zone 3 Output Blue LED: Circuit Short To Ground | REFER to INTERIOR LIGHTING . |
| B1283:15 | Ambient Lighting Zone 3 Output Blue LED: Circuit Short To Battery Or Open | REFER to INTERIOR LIGHTING . |
| B1284:12 | Trunk/Boot Open Activation Request Hardwire: Circuit Short To Battery | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| B1284:14 | Trunk/Boot Open Activation Request Hardwire: Circuit Short To Ground Or Open | REFER to HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS . |
| P0801:11 | Reverse Inhibit Control Circuit: Circuit Short To Ground | REFER to REAR VIEW MIRRORS . |
| P0801:12 | Reverse Inhibit Control Circuit: Circuit Short To Battery | REFER to REAR VIEW MIRRORS . |
| P0801:13 | Reverse Inhibit Control Circuit: Circuit Open | REFER to REAR VIEW MIRRORS . |
| P1571:12 | Brake Switch: Circuit Short To Battery | REFER to EXTERIOR LIGHTING . |
| P2533:14 | Ignition Switch Run/Start Position Circuit: Circuit Short To Ground Or Open | GO to PINPOINT TEST E . |
| U0140:87 | Lost Communication With Body Control Module: Missing Message | GO to PINPOINT TEST F . |
| U0155:87 | Lost Communication With Instrument Panel Cluster (IPC) Control Module: Missing Message | GO to PINPOINT TEST G . |
| U0422:68 | Invalid Data Received From Body Control Module: Event Information | This DTC is set when the BCM-B receives invalid data from the SJB. RETRIEVE and REPAIR all non-network DTCs in the SJB. REFER to the SMART JUNCTION BOX (SJB) DTC CHART . |
| U0423:68 | Invalid Data Received from Instrument Panel Cluster Control Module: Event Information | This DTC is set when the BCM-B receives invalid data from the IPC. RETRIEVE and REPAIR all non-network DTCs in the IPC. REFER to INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES . |
| U1000:00 | Solid State Driver Protection Active - Driver Disabled: No Sub Type Information | GO to PINPOINT TEST H . |
| U2100:55 | Initial Configuration Not Complete: Not Configured | CARRY OUT Programmable Module Installation (PMI) on the BCM-B. REFER to MODULE CONFIGURATION . |
| U3000:49 | Control Module: Internal Electronic Failure | ADDRESS all other DTCs first. CLEAR the DTCs. REPEAT the self-test. If DTC U3000:49 is retrieved again, INSTALL a new BCM-B. REFER to BODY CONTROL MODULE B (BCM-B) . |
| U3003:62 | Battery Voltage: Signal Compare Failure | GO to PINPOINT TEST I . |
BODY CONTROL MODULE B (BCM-B) DTC CHART
| Condition | Possible Sources | Action |
|---|---|---|
| No communication with the Body Control Module B (BCM-B) | Fuse Wiring, terminals or connectors BCM-B | REFER to MODULE COMMUNICATIONS NETWORK , The BCM-B Does Not Respond To The Scan Tool. |
SYMPTOM CHART
Pinpoint Test E: DTC P2533:14
Refer to SYSTEM WIRING DIAGRAMS , Fuse and Relay Information for schematic and connector information.
Refer to SYSTEM WIRING DIAGRAMS , Interior Lamps for schematic and connector information.
PINPOINT TEST F: DTC U0140:87
- F1 VERIFY CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes : GO to F2. No : The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- F2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the SJB pass the network test? Yes : GO to F3. No : REFER to «MODULE COMMUNICATIONS NETWORK»(ref-574111) , The SJB Does Not Respond To The Scan Tool.
- F3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded BCM-B DTCs from the self-test. Is DTC U3003:62 recorded? Yes : GO to «PINPOINT TEST I»(ref-574135-S34254513382013082300000) . No : GO to F4.
- F4 RECHECK THE BCM-B DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the BCM-B self-test. Is DTC U0140:87 still present? Yes : GO to F5. No : The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- F5 CHECK FOR DTC U0140:87 SET IN OTHER MODULES Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0140:87 or DTC U0140 set in any other module? Yes : INSTALL a new SJB. REFER to «SMART JUNCTION BOX (SJB)»(ref-574135-S02891211992013082300000) . CLEAR the DTCs. REPEAT the BCM-B self-test. No : INSTALL a new BCM-B. REFER to «BODY CONTROL MODULE B (BCM-B)»(ref-574135-S09451975482013082300000) . TEST the system for normal operation.
PINPOINT TEST G: DTC U0155:87
- G1 VERIFY CUSTOMER CONCERN Ignition ON. Verify that there is an observable symptom present. Is an observable symptom present? Yes : GO to G2. No : The system is operating normally at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- G2 CHECK THE COMMUNICATION NETWORK Ignition ON. Enter the following diagnostic mode on the scan tool: Network Test. Carry out the network test. Does the IPC pass the network test? Yes : GO to G3. No : REFER to «MODULE COMMUNICATIONS NETWORK»(ref-574111) , The IPC Does Not Respond To The Scan Tool.
- G3 RETRIEVE THE RECORDED DTCs FROM THE SELF-TEST Check for recorded BCM-B DTCs from the self-test. Is DTC U3003:62 recorded? Yes : GO to «PINPOINT TEST I»(ref-574135-S34254513382013082300000) . No : GO to G4.
- G4 RECHECK THE BCM-B DTCs NOTE: If new modules were installed prior to the DTC being set, the module configuration may be incorrectly set during Programmable Module Installation (PMI) or the PMI may not have been carried out. Clear the DTCs. Repeat the BCM-B self-test. Is DTC U0155:87 still present? Yes : GO to G5. No : The system is operating correctly at this time. The DTC may have been set due to high network traffic or an intermittent fault condition.
- G5 CHECK FOR DTC U0155:87 SET IN OTHER MODULES Clear all DTCs. Ignition OFF. Ignition ON. Wait 10 seconds. Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC U0155:87 or DTC U0155 set in any other module? Yes : INSTALL a new IPC. REFER to «INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES»(ref-574138) . CLEAR the DTCs. REPEAT the BCM-B self-test. No : INSTALL a new BCM-B. REFER to «BODY CONTROL MODULE B (BCM-B)»(ref-574135-S09451975482013082300000) . TEST the system for normal operation.
PINPOINT TEST H: DTC U1000: 00
- H1 REVIEW THE DTCs NOTE: First follow the necessary diagnostics to resolve DTC U1000:00 and any other present DTCs (ignoring U3000:49). DTC U1000:00 is only present when there is another DTC due to software or circuitry issues that must be resolved before another self-test is run. DTC U3000:49 is only present once the final threshold has been met. Failure to correct the fault condition first may cause damage to the new BCM-B, resulting in a repeat repair. Review the DTCs from the BCM-B self-test. Are any other DTCs present, besides U1000:00 or U3000:49? Yes : REFER to the «Body Control Module B (BCM-B) DTC chart»(ref-574135-S34534381592013082300000) . After the repair, GO to H2. No : GO to H2.
- H2 REPEAT THE BCM-B SELF-TEST Ignition ON. Enter the following diagnostic mode on the scan tool: BCM-B Self-Test. Clear the DTCs and repeat the BCM-B self-test. Is DTC U3000:49 present? Yes : INSTALL a new BCM-B. REFER to «BODY CONTROL MODULE B (BCM-B)»(ref-574135-S09451975482013082300000) . TEST the system for normal operation. No : The system is operating correctly at this time. The circuit short has been repaired.
Pinpoint Test I: DTC U3003:62
Refer to SYSTEM WIRING DIAGRAMS , Interior Lamps for schematic and connector information.
Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.
Note. Failure to disconnect the battery when instructed results in false resistance readings. Refer to BATTERY, MOUNTING AND CABLES .
Note. DTC U3003:62 may be stored in the module memory due to previous battery charging or vehicle jump starting events.
Scheme 5
Scheme 6
- I1 RECHECK THE BCM-B DTCs Ignition OFF. Ignition ON. Enter the following diagnostic mode on the scan tool: BCM-B Self-Test. Clear the DTCs. Repeat the BCM-B self-test. Is DTC U3003:62 still present? Yes : GO to I2. No : The system is operating normally at this time. The DTC may have been set due to a previous low battery voltage condition, during battery charging or while jump starting the vehicle.
- I2 CHECK FOR CHARGING SYSTEM DTCs IN THE PCM Enter the following diagnostic mode on the scan tool: PCM Self-Test. Carry out the PCM KOEO self-test. Retrieve the continuous memory DTCs from the PCM. Is DTC P0562, P0620, P0622, P0625, P0626 or P065B set in the PCM? Yes : REFER to «CHARGING SYSTEM»(ref-574126) . No : GO to I3.
- I3 CHECK FOR DTCs B1317, B1318 B1676, P0563 OR U3003:62 SET IN OTHER MODULES Enter the following diagnostic mode on the scan tool: Self-Test. Retrieve the continuous memory DTCs from all modules. Is DTC B1317, B1676, P0563 (PCM) or U3003:17 set in more than one module? Yes : REFER to «CHARGING SYSTEM»(ref-574126) to diagnose the charging system condition. No : GO to I4.
- I4 CHECK THE BATTERY VOLTAGE Turn off all interior/exterior lights and accessories. Start and run the engine at approximately 2, 000 rpm for 3 minutes while monitoring the battery voltage. Does the battery voltage rise to 15 volts or higher? Yes : REFER to «CHARGING SYSTEM»(ref-574126) to diagnose an overcharging condition. No : GO to I5.
- I5 CHECK THE BATTERY CONDITION AND STATE OF CHARGE Ignition OFF. Check the battery condition and verify the battery is fully charged. Refer to «BATTERY, MOUNTING AND CABLES»(ref-574143) . Is the battery OK and fully charged? Yes : GO to I6. No : REFER to «CHARGING SYSTEM»(ref-574126) .
- I6 CHECK THE BCM-B VOLTAGE PID Ignition ON. Measure and record the voltage at the battery. Enter the following diagnostic mode on the scan tool: BCM-B DataLogger. Monitor the BCM-B voltage PID (VPWR_BCMB). Is the voltage within 0.2 volt of the recorded battery voltage? Yes : GO to I9 . No : GO to I7.
- I7 CHECK THE BCM-B VOLTAGE SUPPLY Ignition OFF. Disconnect: BCM-B C4368a. Ignition ON. Measure the voltage between the BCM-B C4368a-1, circuit SBB18 (YE/RD), harness side and ground. Is the voltage within 0.2 volt of the recorded battery voltage? Yes : GO to I8. No : REPAIR circuit SBB18 (YE/RD) for high resistance. CLEAR the DTC. REPEAT the self-test.
- I8 CHECK THE BCM-B GROUND CIRCUIT FOR HIGH RESISTANCE Ignition OFF. Disconnect: Negative Battery Cable. Measure the resistance between the BCM-B C4368a-13, circuit GD110 (BK/WH), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to I9. No : REPAIR circuit GD110 (BK/WH) for high resistance. CLEAR the DTC. REPEAT the self-test.
- I9 CHECK FOR CORRECT BCM-B OPERATION Disconnect the BCM-B connectors. Check for: corrosion damaged pins pushed-out pins Connect the BCM-B connectors and make sure they seat correctly. Operate the system and verify the concern is still present. Is the concern still present? Yes : INSTALL a new BCM-B. REFER to «BODY CONTROL MODULE B (BCM-B)»(ref-574135-S09451975482013082300000) . TEST the system for normal operation. No : The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector.
Scheme 7
| Item | Part Number | Description |
|---|---|---|
| 1 | Smart Junction Box (SJB) Electrical connectors (part of 14A005) (2 required) | |
| 2 | SJB Electrical connectors (part of 14290) (3 required) | |
| 3 | SJB Electrical connectors (part of 14401) (2 required) | |
| 4 | W706287-S | SJB nut |
| 5 | 14B476 | SJB |
