Removal
Note. Removal steps in this procedure may contain installation details.
Note. Not all procedure steps are required for some components.
Mirror Assembly
Pinpoint Test G
G3
Mirror Glass
- click to open the image
- Mirror Glass
G6
Exterior Mirror Motor
- click to open the image
- Exterior Mirror Motor
G7
Exterior Mirror Cover
- NOTE: Use a flat-blade screwdriver and remove the exterior mirror motor from the 3 mounting clips.
- Torque: 13 lb.in (1.45 Nm)
- click to open the image
- Exterior Mirror Cover
G8
Mirror Mounted Turn Signal
- click to open the image
- Mirror Mounted Turn Signal
G10
Puddle Lamp
- click to open the image
- Puddle Lamp
Installation
- To install, reverse the removal procedure.
SPECIAL TOOLS/GENERAL EQUIPMENT 501-025 Installer, Rear Mirror 501-D118A Mirror Remover
Scheme 2
Pinpoint Test G
G1
Mirror type 1
- click to open the image
- Mirror type 1
G6
Mirror type 2
- click to open the image
- Mirror type 2
G7
501-D118A Mirror Remover
- click to open the image
- Mirror type 3
G10
Mirror type 4
- click to open the image
- Mirror type 4
G11
IPMA
G14
Mirror type 5
- click to open the image
- Mirror type 5
Mirror type 1
Pinpoint Test G
G4
Mirror type 2
- Mirror type 2
G5
501-025 Installer, Rear View Mirror
- click to open the image
G6
Mirror type 3
- Mirror type 3
G7
Mirror type 4
- Mirror type 4
G9
IPMA
- Mirror type 5
