TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Selector lever cable grommet nuts | 8 |
| Selector lever knob bolts | 2 |
| Selector lever nuts | 12 |
TORQUE SPECIFICATIONS
Scheme 494
| Item | Part Number | Description |
|---|---|---|
| 1 | 7E395 | Selector lever cable |
| 2 | 14489 | Selector lever electrical connector |
| 3 | W520102 | Selector lever nut (4 required) |
| 4 | Lower selector lever knob bezel | |
| 5 | Selector lever knob bolts | |
| 6 | 7L010 | Selector lever knob |
| 7 | Transmission Control Switch (TCS) (3.5L engine) (part of 7L010) (MKZ only) | |
| 8 | PRNDL light | |
| 9 | 7E034 | PRNDL bezel |
| 10 | 7K004 | Selector lever assembly (items 4-10) |
The transaxle selector lever control linkage consists of
- a selector lever cable that connects the transaxle range selector lever to the floor selector lever assembly.
- a Brake Shift Interlock Actuator (BSIA) that is integral to the floor selector lever assembly.
The floor selector lever assembly
- locks the transaxle range selector lever in the PARK position when the ignition switch is in the lock position.
- requires the transaxle range selector lever to be in the PARK position to turn the ignition switch to the lock position.
The MKZ Transmission Control Switch (TCS) is a momentary contact switch located on the selector lever knob that allows the driver to cancel the operation of OVERDRIVE.
Special Tools Illustration Tool Name Tool Number 73 III Digital Multimeter 105-R0057 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
