Automatic Transaxle/transmission External Controls: Other Ford Fusion I facelift

Pinpoint Tests

Refer to SYSTEM WIRING DIAGRAMS article for Fusion, SYSTEM WIRING DIAGRAMS article for Milan or SYSTEM WIRING DIAGRAMS article for MKZ, Transmission Controls -6 Speed for schematic and connector information.

Refer to SYSTEM WIRING DIAGRAMS article for Fusion, SYSTEM WIRING DIAGRAMS article for Milan or SYSTEM WIRING DIAGRAMS article for MKZ, Transmission Controls-FNR5 for schematic and connector information.

Refer to SYSTEM WIRING DIAGRAMS article for Fusion, SYSTEM WIRING DIAGRAMS article for Milan or SYSTEM WIRING DIAGRAMS article for MKZ, Shift Interlock for schematic and connector information.

Scheme 503

Scheme 504

Scheme 505

Scheme 506

Scheme 507

Scheme 508

Scheme 509

Scheme 510

1. A1 TEST THE BRAKE LIGHTS Apply the brake pedal and view the brake lights. Do the brake lights illuminate? YES : Go to A2 . NO : REFER to «EXTERIOR LIGHTING»(ref-291872) article.
2. A2 TEST Brake Shift Interlock Actuator (BSIA) POWER CIRCUIT Disconnect: Selector Lever Electrical C3245 (2.3L/3.0L engine) or C3233 (3.5L engine) Key in ON position. Vehicles equipped with a 3.0L or a 2.3L engine, measure the voltage between selector lever harness C3245-1, circuit VET13 (GY/BU), vehicle harness side and ground, while applying the brake pedal. Vehicles equipped with a 3.5L engine, measure the voltage between selector lever harness C3233-1, circuit VET13 (GY/BU), vehicle harness side and ground, while applying the brake pedal. Is the voltage greater than 10 volts? YES : Go to A5 . NO : Go to A3 .
3. A3 TEST THE BSIA POWER CIRCUIT FOR A SHORT TO GROUND Key in OFF position. Disconnect: Smart Junction Box (SJB) C2280C Vehicles equipped with a 3.0L or a 2.3L engine, measure the resistance between the selector lever harness C3245-1, circuit VET13 (GY/BU), vehicle harness side and ground. Vehicles equipped with a 3.5L engine, measure the resistance between selector lever harness C3233-1, circuit VET13 (GY/BU), vehicle harness side and ground. Is the resistance greater than 10,000 ohms? YES : Go to A4 . NO : REPAIR the circuit. TEST the system for normal operation.
4. A4 TEST THE BSIA POWER CIRCUIT FOR AN OPEN Key in OFF position. Vehicles equipped with a 3.0L or a 2.3L engine, measure the resistance between the selector lever harness C3245-1, circuit VET13 (GY/BU), vehicle harness side and SJB C2280C-14, circuit VET13 (GY/BU), vehicle harness side. Vehicles equipped with a 3.5L engine, measure the resistance between the selector lever harness C3233-1, circuit VET13 (GY/BU), vehicle harness side and SJB C2280C-14, circuit VET13 (GY/BU), vehicle harness side. Is the resistance less than 5 ohms? YES : INSTALL a new SJB. TEST the system for normal operation. NO : REPAIR the circuit. TEST the system for normal operation.
5. A5 TEST THE BSIA GROUND CIRCUIT Key in OFF position. Vehicles equipped with a 3.0L or a 2.3L engine, measure the resistance between the selector lever harness C3245-4, circuit GD116 (BK/VT), vehicle harness side and ground. Vehicles equipped with a 3.5L engine, measure the resistance between selector lever harness C3233-5, circuit GD116 (BK/VT), vehicle harness side and ground. Is the resistance less than 5 ohms? YES : INSTALL a new selector lever. REFER to «Selector Lever»(ref-291891-S36878866342008073000000) . NO : REPAIR the circuit. TEST the system for normal operation.

Scheme 511

Scheme 512

Scheme 513

Scheme 514

1. B1 TEST THE Instrument Cluster (IC) Connect the diagnostic tool. Using the scan tool, monitor the TCS PID while cycling the TCS. Does the TCS PID cycle from depressed to not depressed? YES : REFER to «INSTRUMENT CLUSTER (IC), MESSAGE CENTER, AND WARNING CHIMES»(ref-291880) article. NO : Go to B2 .
2. B2 TEST THE SELECTOR LEVER GROUND CIRCUIT FOR AN OPEN Disconnect: Selector Lever Harness C3233 Measure the resistance between selector lever harness C3233-5, circuit GD116 (BK/VT), vehicle harness side and ground. Is the resistance less than 5 ohms? YES : Go to B3 . NO : REPAIR the selector lever ground circuit for an open. TEST the system for normal operation.
3. B3 TEST THE TCS CIRCUIT FOR AN OPEN Disconnect: Transmission Control Module (TCM) C1533 Measure the resistance between selector lever harness C3233-6, circuit CET34 (BN/GN), vehicle harness side and TCM C1533-7 circuit CET34 (BN/GN), vehicle harness side. Is the resistance less than 5 ohms? YES : Go to B4 . NO : REPAIR the circuit for an open. TEST the system for normal operation.
4. B4 TEST THE TCS CIRCUIT FOR A SHORT TO GROUND Measure the resistance between selector lever harness C3233-6, circuit CET34 (BN/GN), vehicle harness side and ground. Is the resistance greater than 10,000 ohms? YES : Go to B5 . NO : REPAIR the circuit for a short to ground. TEST the system for normal operation.
5. B5 TEST THE TCS Measure the resistance between selector lever harness C3233-5 and C3233-6, component side, while cycling the TCS. Is the resistance less than 5 ohms when pressed and greater than 10,000 ohms when released? YES : INSTALL a new TCM. REFER to «AUTOMATIC TRANSAXLE/TRANSMISSION - AISIN AW21»(ref-291884) article. TEST the system for normal operation. NO : INSTALL a new selector lever knob. REFER to «Selector Lever Knob - 3.5L»(ref-291891-S26320348612008073000000) . TEST the system for normal operation.

Scheme 515

Scheme 516

Scheme 517

Scheme 518

Scheme 519

Scheme 520

Scheme 521

Scheme 522

Scheme 523

1. C1 TEST Battery Junction Box (BJB) FUSE 14 (15A) Check fuse: BJB Fuse 14 (15A) Is the resistance less than 5 ohms? YES : Go to C2 . NO : REPAIR the circuit. INSTALL a new fuse. TEST the system for normal operation.
2. C2 TEST THE INHIBIT SOLENOID POWER CIRCUIT FOR AN OPEN Disconnect: Ignition Switch Electrical C250 Measure the resistance between the output side of BJB fuse 14 (15A) and ignition switch electrical C250-4, circuit SBB14 (BN/RD), vehicle harness side. Is the resistance less than 5 ohms? YES : Go to C3 . NO : REPAIR the circuit. TEST the system for normal operation.
3. C3 TEST FOR VOLTAGE AT THE SELECTOR LEVER CONNECTOR Select PARK. Key in OFF position. Disconnect: Selector Lever Electrical C3245 (2.3L/3.0L engine) or C3233 (3.5L engine) Visually inspect the connector and wires for damage. Key in ON position. Vehicles equipped with a 3.0L or a 2.3L engine, measure the voltage between selector lever harness C3245-2, circuit CET22 (GY/BN), vehicle harness side and ground. Vehicles equipped with a 3.5L engine, measure the voltage between selector lever harness C3233-2, circuit CET22 (GY/BN), vehicle harness side and ground. Is the voltage greater than 10 volts? YES : Go to C6 . NO : Go to C4 .
4. C4 TEST FOR AN OPEN CIRCUIT Key in OFF position. Disconnect: Ignition Switch Electrical C250 Vehicles equipped with a 3.0L or a 2.3L engine, measure the resistance between selector lever harness C3245-2, circuit CET22 (GY/BN), vehicle harness side and ignition switch electrical C250-3, circuit CET22 (GY/BN), vehicle harness side. Vehicles equipped with a 3.5L engine, measure the resistance between selector lever harness C3233-2, circuit CET22 (GY/BN), vehicle harness side and ignition switch electrical C250-3, circuit CET22 (GY/BN), vehicle harness side. Is the resistance less than 5 ohms? YES : Go to C5 . NO : REPAIR the circuit. TEST the system for normal operation.
5. C5 TEST FOR A SHORT TO GROUND Vehicles equipped with a 3.0L or a 2.3L engine, measure the resistance between selector lever harness 3245-2, circuit CET22 (GY/BN), vehicle harness side and ground. Vehicles equipped with a 3.5L engine, measure the resistance between selector lever harness 3233-2, circuit CET22 (GY/BN), vehicle harness side and ground. Is the resistance greater than 10,000 ohms? YES : INSTALL a new steering column lock module. REFER to «STEERING COLUMN SWITCHES»(ref-291886) article. NO : REPAIR the circuit. TEST the system for normal operation.
6. C6 TEST THE VEHICLE HARNESS GROUND CIRCUIT Vehicles equipped with a 3.0L or a 2.3L engine, measure the resistance between selector lever harness C3245-4, circuit GD116 (BK/VT), vehicle harness side and ground. Vehicles equipped with a 3.5L engine, measure the resistance between selector lever harness C3233-5, circuit GD116 (BK/VT), vehicle harness side and ground. Is the resistance less than 5 ohms? YES : Go to C7 . NO : REPAIR the circuit. TEST the system for normal operation.
7. C7 TEST THE PARK DETECT SWITCH Vehicles equipped with a 3.0L or a 2.3L engine, measure the resistance between selector lever harness C3245-2 and C3245-4, component side, with the selector lever in PARK and DRIVE. Vehicles equipped with a 3.5L engine, measure the resistance between selector lever harness C3233-2 and C3233-5, component side, with the selector lever in PARK and DRIVE. Is the resistance greater than 10,000 ohms in PARK and less than 5 ohms in DRIVE? YES : INSTALL a new steering column lock module. REFER to «STEERING COLUMN SWITCHES»(ref-291886) article. NO : INSTALL a new selector lever assembly. REFER to «Selector Lever»(ref-291891-S36878866342008073000000) .

Brake Shift Interlock Override

Note. If it is necessary to use the override procedure to move the selector lever out of the PARK position, it is possible that a fuse has blown and the brake lights are not operational. Before driving the vehicle, verify that the brake lights are working. This vehicle is equipped with a brake shift interlock feature that prevents the selector lever from being moved out of PARK when the ignition is in the ON position unless the brake pedal is depressed. If the selector lever cannot be moved out of the PARK position when the ignition is in the ON position and the brake pedal is depressed carry out the following procedure

1. Apply the parking brake.
2. Remove the access panel.
3. Using an suitable tool, depress the brake shift interlock override mechanism on the selector lever, apply the brake, depress the button on the selector lever and move the selector lever into NEUTRAL.
4. Start the vehicle.
5. Install the access panel.

Selector Lever Knob - 3.5L
