TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Catalytic converter-to-exhaust flexible pipe nuts | 40 |
| Inner tie-rod | 103 |
| Outer tie-rod end nuts | 48 |
| Power steering fluid reservoir bracket bolts (3.5L) | 7 |
| Power steering fluid reservoir nuts (3.0L) | 9 |
| Power steering pump bolts | 24 |
| Pressure line bracket-to-engine bolts (3.0L-3.5L) | 9 |
| Pressure line bracket-to-power steering fluid reservoir bolt (3.0L) | 9 |
| Pressure line bracket-to-RH valve cover stud nut (3.5L) | 9 |
| Pressure line bracket-to-steering gear bolt (2.3L) | 9 |
| Pressure line bracket-to-steering gear bolt (3.0L-3.5L) | 15 |
| Pressure line bracket-to-subframe bolt (2.3L) | 9 |
| Pressure line-to-power steering pump banjo bolt | 48 |
| Pressure line-to-steering gear banjo bolts | 55 |
| Steering column shaft-to-steering gear bolt | 25 |
| Steering gear heat shield bolts | 15 |
| Steering gear bolts | 107 |
| Subframe bolts | 103 |
| Subframe nuts | 150 |
| Tie-rod jam nuts | 90 |
| Underbody splash shield bolts-to-subframe | 7 |
TORQUE SPECIFICATIONS
The power steering system consists of the following components
- Power steering pump
- Power steering fluid reservoir
- Power steering pressure and return lines/hoses
- Power steering fluid cooler
- Power steering gear
- Inner tie rod
The power steering system uses a vane-type pump to move the fluid from the reservoir to the steering gear and through the rest of the steering hydraulic system. The power steering pump is mounted to the engine and driven by the engine accessory drive belt. Power steering fluid flows into the pump from the reservoir. The power steering fluid is then trapped between the pump vanes and moved to the high-pressure side of the pump creating a flow of fluid. The restriction of this flow by the steering gear creates the pressure that provides the steering assist. A combined pressure relief/flow valve is built into the pump to control the maximum pressure and flow provided to the steering system. This action prevents damage to the system and provides the correct level of assist during all engine speeds. While under pressure, the power steering fluid flows through the high-pressure power steering line to the steering gear. The fluid exits the gear and flows through the return line, cooler and finally to the reservoir. The reservoir slows the fluid, allows air to escape and filters the fluid before returning it to the pump.
Refer to STEERING SYSTEM - GENERAL INFORMATION article.
| Item | Specification |
|---|---|
| MERCON® V Automatic Transmission Fluid XT-5-QM (or XT-5-QMC) (US); CXT-5-LM12 (Canada) | MERCON® V |
Material
Scheme 3
| Item | Part Number | Description |
|---|---|---|
| 1 | 3R700 | Power steering fluid reservoir |
| 2 | W506413 | Pressure line bracket-to-power steering fluid reservoir bolt |
| 3 | W520111 | Power steering fluid reservoir nut (3 required) |
| 4 | 3691 | Power steering pump supply hose |
| 5 | 3A713A | Power steering return hose |
