Engine Cooling System: Removal & Installation Ford Focus II facelift

Cooling System (Mechanical) 3 illustrations ~526 words

REMOVAL AND INSTALLATION

  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-357126) article.
  2. Drain the cooling system. For additional information, refer to «Cooling System Draining, Filling and Bleeding»(ref-357157-S33631403912010030800000) .
  3. Remove the accessory drive belt. For additional information, refer to «ACCESSORY DRIVE»(ref-357139) article.
  4. Remove the 2 nuts and position aside the power steering tube. To install, tighten to 10 Nm (89 lb-in).
  5. Remove the cooling fan motor and shroud. For additional information, refer to «Cooling Fan Motor and Shroud»(ref-357157-S41285620092010030800000) .
  6. Remove the 2 bolts, the stud bolt and position aside the A/C compressor. To install, tighten to 25 Nm (18 lb-ft).
  7. Disconnect the radiator and heater hoses from the thermostat housing.
  8. Remove the 3 bolts, thermostat housing and thermostat as an assembly. To install, tighten to 10 Nm (89 lb-in).
  9. To install, reverse the removal procedure.
  10. Fill and bleed the cooling system. For additional information, refer to «Cooling System Draining, Filling and Bleeding»(ref-357157-S33631403912010030800000) .
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-357126) article.
  2. Remove the 2 bolts and position aside the coolant expansion tank. To install, tighten to 4 Nm (35 lb-in).
  3. Loosen the 3 coolant pump pulley bolts.
  4. Remove the accessory drive belt. For additional information, refer to «ACCESSORY DRIVE»(ref-357139) article.
  5. Drain the cooling system. For additional information, refer to «Cooling System Draining, Filling and Bleeding»(ref-357157-S33631403912010030800000) .
  6. Remove the 3 coolant pump pulley bolts and the pulley. To install, tighten to 20 Nm (15 lb-ft).
  7. Remove the 3 coolant pump bolts and the coolant pump. To install, tighten to 10 Nm (89 lb-in).
  8. To install, reverse the removal procedure.
  9. Fill and bleed the cooling system. For additional information, refer to «Cooling System Draining, Filling and Bleeding»(ref-357157-S33631403912010030800000) .

Scheme 1

Scheme 1: Radiator and Cooling Fan
ItemPart NumberDescription
1Horn assembly electrical connector (part of 14290)
2W710090Lower radiator support bolt (4 required)
316138Lower radiator support
414A464Cooling fan motor and shroud electrical connector
5W503924Cooling fan motor and shroud bolt (2 required)
68C607Cooling fan motor and shroud
78B274Upper radiator hose
88B273Lower radiator hose
98N029Overflow hose
108005Radiator
11W709180Transmission oil cooler tube bracket pin-type retainer (if equipped)
12W503924Condenser core bolt (2 required)
1319712Condenser core
1413A506Pin-type retainer (4 required)
  1. For additional information, refer to the appropriate procedures in this service information.
  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-357126) article.
  2. Remove the lower radiator air deflector. For additional information, refer to «FRONT END BODY PANELS»(ref-357183) article.
  3. Disconnect the cooling fan motor and shroud electrical connector and the pin-type retainers.
  4. Remove the 2 bolts and remove the cooling fan motor and shroud from the vehicle. To install, tighten to 5 Nm (44 lb-in).
  5. To install, reverse the removal procedure.

Scheme 2

Scheme 2: Block Heater
ItemPart NumberDescription
114A464Block heater electrical connector
26A051Block heater
  1. Drain the cooling system. For additional information, refer to «Cooling System Draining, Filling and Bleeding»(ref-357157-S33631403912010030800000) .
  2. Disconnect the block heater electrical connector.
  3. Remove the block heater. To install, tighten to 20 Nm (15 lb-ft).
  4. To install, reverse the removal procedure.
  5. Fill and bleed the cooling system. For additional information, refer to «Cooling System Draining, Filling and Bleeding»(ref-357157-S33631403912010030800000) .

Scheme 3

Scheme 3: Coolant Expansion Tank
ItemPart NumberDescription
18N029Overflow hose
2W701107Coolant expansion tank bolt (2 required)
38C045Coolant expansion tank
  1. Using a suitable suction device, siphon the coolant from the coolant expansion tank.
  2. Disconnect the overflow hose from the coolant expansion tank.
  3. Remove the 2 coolant expansion tank bolts. To install, tighten to 4 Nm (35 lb-in).
  4. Lift and remove the coolant expansion tank.
  5. To install, reverse the removal procedure.
  6. Fill the coolant expansion tank. Refer to «Cooling System Draining, Filling and Bleeding»(ref-357157-S33631403912010030800000) for the recommended coolant mixture and fill level.
