Front Suspension: Removal & Installation Ford Focus II рестайлинг

REMOVAL

1. Remove the wheel knuckle. For additional information, refer to «Wheel Knuckle»(ref-357147-S34264805252010030800000) .
2. Remove the circlip from the wheel knuckle.
3. Using the special tools, remove the wheel hub and outer bearing race.
4. Using the special tools, remove the bearing inner ring from the wheel hub.
5. To aid in removal of the bearing outer ring, install the bearing cage onto the inner ring and install the assembly into the wheel knuckle.
6. Using the special tools, remove the bearing outer ring from the wheel knuckle.

INSTALLATION

Note. To prevent wheel speed sensor ring damage, make sure that the sensor ring is clean. Make sure that the sensor ring does not make contact with metal surfaces and avoid any impact on the sensor ring.

1. Using the special tools, install the new wheel bearing to the wheel knuckle.
2. Using the special tools, install the wheel hub into the wheel knuckle.
3. Install the circlip into the wheel knuckle.
4. Install the wheel knuckle. For additional information, refer to «Wheel Knuckle»(ref-357147-S34264805252010030800000) .

1. Remove the brake disc. For additional information, refer to «FRONT DISC BRAKE»(ref-357149) article.
2. Using the special tool, remove the wheel stud.

1. Position the wheel stud in the flange, making sure the serrations on the stud line up with the serrations in the flange. Install the washers and a wheel nut.
2. Tighten the wheel nut until the stud is seated against the hub flange.
3. Remove the wheel nut and the washers. Discard the wheel nut.
4. Install the brake disc. For additional information, refer to «FRONT DISC BRAKE»(ref-357149) article.

Scheme 7

Note. Suspension fasteners are critical parts because they affect performance of vital components and systems and their failure may result in major service expense. New parts must be installed with the same part numbers or equivalent part, if replacement is necessary. Do not use a replacement part of lesser quality or substitute design. Torque values must be used as specified during reassembly to make sure correct retention of these parts.

1. Remove the wheel and tire. For additional information, refer to «WHEELS AND TIRES»(ref-357130) article.
2. Remove and discard the ball joint nut and bolt. Insert a pry bar in the lower arm body opening, separate the lower arm from the wheel knuckle and remove the ball joint heat shield.
3. Remove the lower arm bushing bracket nuts, bolts and the bracket. Discard the nuts and bolts.
4. Remove and discard the lower arm forward nut and bolt and remove the lower arm.

1. Position the lower arm and loosely install the forward nut and bolt and the 2 bracket nuts and bolts.
2. Install the ball joint heat shield.
3. Insert the ball joint stud into the wheel knuckle and install the ball joint bolt and nut. Tighten to 63 Nm (46 lb-ft).
4. Install the wheel and tire. For additional information, refer to «WHEELS AND TIRES»(ref-357130) article.
5. Lower the hoist so the weight of the vehicle is resting on the wheels and tires.
6. Tighten the lower arm forward bolt to 215 Nm (159 lb-ft).
7. Tighten the lower arm inboard bracket nut to 160 Nm (118 lb-ft).
8. Tighten the lower arm outboard bracket nut to 103 Nm (76 lb-ft).
9. Check and, if necessary, align the front end. For additional information, refer to «SUSPENSION SYSTEM - GENERAL INFORMATION»(ref-357131) article.

1. Remove the wheel and tire. For additional information, refer to «WHEELS AND TIRES»(ref-357130) article.
2. Loosen the tie-rod end nuts.
3. Using the special tool, detach the tie-rod ends from the wheel knuckles. Discard the tie-rod end nuts.
4. Remove and discard the stabilizer bar link lower nuts and detach the stabilizer bar links from the stabilizer bar.
5. Using a suitable transmission jack, support the subframe.
6. Index mark the subframe position.
7. Remove the 4 subframe front bolts and 2 subframe rear bolts.
8. Lower the subframe to gain access to the stabilizer bar.
9. Remove the stabilizer bar bracket bolts and brackets. Discard the bolts.
10. Remove the stabilizer bar bushings.
11. Remove the stabilizer bar.

1. Install the stabilizer bar.
2. Install the stabilizer bar bushings.
3. Position the stabilizer bar with the bushings against the spacer and set it to the specification listed using tie straps or mechanic's wire.
4. Position the stabilizer bar brackets and install the bolts. Tighten to 55 Nm (41 lb-ft).
5. Remove the stabilizer bar supports.
6. Using the index marks made during removal, install the subframe retaining bolts. Tighten the bolts until snug.
7. Tighten the 4 subframe front bolts. Tighten to 175 Nm (129 lb-ft).
8. Tighten the 2 subframe rear bolts. Tighten to 103 Nm (76 lb-ft).
9. Lower and remove the transmission jack.
10. Attach the stabilizer bar links to the stabilizer bar and install the nuts. Tighten to 55 Nm (41 lb-ft).
11. Attach the tie-rod ends to the wheel knuckles and install the nuts. Tighten to 35 Nm (26 lb-ft).
12. Install the wheel and tire. For additional information, refer to «WHEELS AND TIRES»(ref-357130) article.

Note. Suspension fasteners are critical parts because they affect performance of vital components and systems and their failure may result in major service expense. New parts must be installed with the same part numbers or equivalent part, if replacement is necessary. Do not use a replacement part of lesser quality or substitute design. Torque values must be used as specified during reassembly to make sure correct retention of these parts.

1. Loosen the 3 strut upper nuts 5 turns.
2. Remove the wheel and tire. For additional information, refer to «WHEELS AND TIRES»(ref-357130) article.
3. Remove and discard the wheel hub nut.
4. Remove the brake hose retainer.
5. Remove the 2 brake caliper guide pin bolts and position the caliper assembly aside. Support the caliper assembly using mechanic's wire.
6. Remove the brake disc.
7. If equipped with ABS, remove the wheel speed sensor bolt and position the sensor aside.
8. Loosen the tie-rod end nut.
9. Using the Tie-Rod End Remover, detach the tie-rod end from the wheel knuckle. Remove and discard the tie-rod end nut.
10. Remove and discard the ball joint nut and bolt. Insert a pry bar in the lower arm body opening and separate the ball joint from the wheel knuckle.
11. Using the Front Wheel Hub Remover, press out the halfshaft from the wheel hub and detach the halfshaft from the wheel hub. Support the halfshaft.
12. Remove and discard the wheel knuckle-to-strut bolt.
13. Remove the wheel knuckle.

1. Position the wheel knuckle and install a new wheel knuckle-to-strut bolt. Tighten to 150 Nm (111 lb-ft).
2. Insert the hafshaft into the wheel hub.
3. Insert the ball joint stud into the wheel knuckle and install a new bolt and nut. Tighten to 63 Nm (46 lb-ft).
4. Attach the tie-rod end to the wheel knuckle and install a new nut. Tighten to 35 Nm (26 lb-ft).
5. If equipped with ABS, position the wheel speed sensor and install the bolt. Tighten to 9 Nm (80 lb-in).
6. Install the brake disc.
7. Position the caliper assembly and install the 2 brake caliper guide pin bolts. Tighten to 27 Nm (20 lb-ft).
8. Install the brake hose retainer.
9. Tighten the 3 strut upper nuts to 35 Nm (26 lb-ft).
10. Using the Halfshaft Installer, install the halfshaft into the wheel hub.
11. Install the new wheel hub nut. Tighten to 270 Nm (199 lb-ft) in a continuous rotation.
12. Install the wheel and tire. For additional information, refer to «WHEELS AND TIRES»(ref-357130) article.

Scheme 8

REMOVAL AND INSTALLATION

1. Remove the wheel and tire. For additional information, refer to «WHEELS AND TIRES»(ref-357130) article.
2. Detach the brake hose from the support bracket.
3. Remove the stabilizer bar link upper nut and detach the link from the strut. To install, tighten to 55 Nm (41 lb-ft).
4. Remove the wheel knuckle-to-strut bolt. To install, tighten to 150 Nm (111 lb-ft).
5. Detach the wheel knuckle from the strut and spring assembly. Support the halfshaft using mechanic's wire.
6. Remove the strut upper nuts. To install, tighten to 35 Nm (26 lb-ft).
7. Remove the strut and spring assembly.
8. To install, reverse the removal procedure. For additional information on the disassembly and assembly of the strut and spring assembly, refer to «Strut and Spring Assembly»(ref-357147-S26267403512010030800000) .
9. Check and, if necessary, align the front end. For additional information, refer to «SUSPENSION SYSTEM - GENERAL INFORMATION»(ref-357131) article.

Scheme 9
