MATERIAL SPECIFICATIONS
| Item | Specification | Fill Capacity |
|---|---|---|
| Dye-Lite® ATF/Power Steering Fluid Leak Detection Dye 164-R3701 (Rotunda) | ||
| MERCON® V Automatic Transmission Fluid XT-5-QM (or XT-5-QMC) (US); CXT-5-LM12 (Canada) | MERCON® V | 0.74L (1.6 pt) a |
| A Capacities listed are average system capacities and may vary. | ||
MATERIAL SPECIFICATIONS
GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| Power Steering Pump | |
| Flow | 6.8-8.3L/min (1.8-2.2 gpm) Fluid at 41-46°C (105°-115°F) Engine at 2,500 RPM |
| Minimum capacity | 4.9L/min (1.3 gpm) Fluid at 41-46°C (105°-115°F) Engine at idle Pressure at 5,171 kPa (750 psi) |
| Pressure | 345 kPa (50 psi) Fluid at 41-46°C (105°-115°F) Engine at 2,500 RPM |
| Relief pressure | 8274-9515 kPa (1,200-1,380 psi) |
| Power Steering Purge Vacuum | |
| Vacuum | 68-85 kPa (20-25 in/hg) |
GENERAL SPECIFICATIONS
The power steering system consists of the following components
- Power steering pump
- Power steering fluid reservoir
- Steering gear
- Power steering lines
- Steering column
- Steering column shaft
- Power Steering Pressure (PSP) sensor
The power steering system transfers driver inputs at the steering wheel to the front wheels of the vehicle. The steering column, hydraulic system and linkages that transfer these driver inputs make up the steering system. Gearing and hydraulic assist are used to significantly reduce steering efforts.
For information on the power steering fluid reservoir, power steering pump, power steering lines and steering gear, refer to POWER STEERING article.
For information on the steering wheel, steering column and steering column shaft, refer to STEERING COLUMN article.
SPECIAL TOOLS - STEERING SYSTEM Illustration Tool Name Tool Number 100W/12 Volt DC UV Lamp 164-R0751 Dial Thermometer 0-220°F 023-R0007 or equivalent Evacuation Cap, Power Steering 211-265 or equivalent Vacuum Pump Kit 416-D002 (D95L-7559-A) or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool
Scheme 1
Scheme 2
| Item | Specification |
|---|---|
| Dye-Lite® ATF/Power Steering Fluid Leak Detection Dye 164-R3701 (Rotunda) | |
| MERCON® V Automatic Transmission Fluid XT-5-QM (or XT-5-QMC) (US); CXT-5-LM12 (Canada) | MERCON® V |
MATERIAL - STEERING SYSTEM
