Sunroof: Other Ford Focus II

Roof Opening Panel

The roof opening panel consists of the following components

1. Roof opening panel switch
2. Air deflector
3. Roof opening panel glass
4. Roof opening panel weatherstrip
5. Roof opening panel frame
6. Roof opening panel shield
7. Roof opening panel motor
8. Roof opening panel front and rear drain hoses

SPECIAL TOOLS REFERENCE 73III Automotive Meter 105-R0057 or equivalent Flex Probe Kit 105-R025B or equivalent

Possible Causes

1. fuse(s)
2. circuit 15-AG7 (GN/BU) open
3. circuit 29-AG12 (OG/BK) open
4. circuit 31-AG7 (BK) open
5. circuit 31-AG12 (BK) open
6. circuit 31S-AG7 (BK/BU) open
7. circuit 31S-AG27 (BK/WH) open
8. roof opening panel switch
9. roof opening panel motor

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. A1 CHECK FOR VOLTAGE TO THE ROOF OPENING PANEL SWITCH Key in ON position. Check the operation of the roof opening panel switch lamp. Does the roof opening panel switch lamp illuminate? Yes : GO to A2 . No : VERIFY the central junction box (CJB) fuse 43 (15A) is OK. If OK, GO to A6 .
2. A2 CHECK CIRCUIT 29-AG12 (OG/BK) FOR VOLTAGE Key in OFF position. Disconnect: Central junction box (CJB) fuse 34 (20A). Disconnect: Roof Opening Panel Motor C9015. Connect: CJB fuse 34 (20A). Measure the voltage between the roof opening panel motor C9015-1, circuit 29-AG12 (OG/BK), harness side and ground. Is the voltage greater than 10 volts? Yes : Go to A3 . No : VERIFY the CJB fuse 34 (20A) is OK. If OK, REPAIR the circuit. TEST the system for normal operation.
3. A3 CHECK CIRCUIT 31S-AG7 (BK/BU) FOR AN OPEN While pressing the roof opening panel control switch to the DOWN/OPEN position, measure the resistance between the roof opening panel motor C9015-8, circuit 31S-AG7 (BK/BU), harness side and ground. Is the resistance less than 100 ohms? Yes : GO to A4 . No : REPAIR the circuit. TEST the system for normal operation.
4. A4 CHECK CIRCUIT 31S-AG27 (BK/WH) FOR AN OPEN While pressing the roof opening panel control switch to the UP/CLOSE position, measure the resistance between the roof opening panel motor C9015-9, circuit 31S-AG27 (BK/WH), harness side and ground. Is the resistance less than 100 ohms? Yes : GO to A5 . No : REPAIR the circuit. TEST the system for normal operation.
5. A5 CHECK CIRCUIT 31-AG12 (BK) FOR AN OPEN Measure the resistance between the roof opening panel motor C9015-10, circuit 31-AG12 (BK), harness side and ground. Is the resistance less than 5 ohms? Yes : INSTALL a new roof opening panel motor. REFER to «ROOF OPENING PANEL MOTOR»(ref-255451-S19158875022007053100000) in this article. TEST the system for normal operation. No : REPAIR the circuit. TEST the system for normal operation.
6. A6 CHECK CIRCUIT 15-AG7 (GN/BU) FOR VOLTAGE Key in OFF position. Disconnect: Roof Opening Panel Control Switch C9014. Key in ON position. Measure the voltage between the roof opening panel control switch C9014-1, circuit 15-AG7 (GN/BU), harness side and ground. Is the voltage greater than 10 volts? Yes : GO to A7 . No : REPAIR the circuit. TEST the system for normal operation.
7. A7 CHECK CIRCUIT 31-AG7 (BK) FOR AN OPEN Key in OFF position. Measure the resistance between the roof opening panel control switch C9014-4, circuit 31-AG7 (BK), harness side and ground. Is the resistance less than 5 ohms? Yes : GO to A8 . No : REPAIR the circuit. TEST the system for normal operation.
8. A8 CHECK THE ROOF OPENING PANEL SWITCH Carry out the «ROOF OPENING PANEL SWITCH»(ref-255451-S10794966982007053100000) . Is the roof opening panel switch OK?

Yes : VERIFY the customer concern.

No : INSTALL a new roof opening panel switch. TEST the system for normal operation.

1. circuit 8-GB8 (WH/BU) open
2. circuit 8-RE22 (WH/VT) open
3. speedometer
4. roof opening panel motor

1. roof opening panel alignment
2. roof opening panel weatherstrip
3. roof opening panel trough and trough guides
4. roof opening panel drain hose(s)

Roof Opening Panel Switch

1. Measure the resistance between the following: ROOF OPENING PANEL SWITCH RESISTANCE SPECIFICATIONS Roof Opening Panel Switch Position Pins Measurement Neutral 1 -5 Greater than 10,000 ohms Neutral 2-6 Greater than 10,000 ohms Neutral 5 -6 Greater than 10,000 ohms Neutral 6- 1 Greater than 10,000 ohms Fully Up/Close 5 -6 Less than 100 ohms Fully Up/Close 5 - 1 Greater than 10,000 ohms Fully Up/Close 5 -2 Less than 100 ohms Fully Up/Close 2-6 Less than 100 ohms Fully Down/Open 2-6 Less than 100 ohms Fully Down/Open 2-5 Less than 100 ohms Fully Down/Open 5 -6 Less than 100 ohms Fully Down/Open 2- 1 Greater than 10,000 ohms
2. Apply battery voltage to the roof opening panel control switch C9014-1, component side, and ground to the roof opening panel control switch C9014-6, component side. The LED should illuminate.
3. If all measurements of the roof opening panel control switch are as shown, return to the pinpoint test. Otherwise, install a new roof opening panel control switch.

Updating Roof Opening Panel Motor Initialization

Note. This procedure should only be carried out when the roof opening panel motor is not disconnected.

Note. The roof opening panel alignment must be carried out prior to carrying out roof opening panel motor initialization. For additional information, refer to ROOF OPENING PANEL ALIGNMENT in this article.

1. Operate the roof opening panel control switch to the up/close position until the roof opening panel is in the fully open/vent position.
2. Release the roof opening panel control switch.
3. Press the roof opening panel control switch in the up/close position and hold for 30 seconds until there is a small movement of approximately 2 mm (0.08 in) and the roof opening panel motor stops.
4. Release the roof opening panel control switch.
5. Press the roof opening panel control switch in the up/close position again within 0.5 second until the roof opening panel stops (1 complete cycle).

Initial Roof Opening Panel Motor Initialization

Note. This procedure must be carried out when installing any roof opening panel motor or roof opening panel.

Note. The roof opening panel alignment must be carried out prior to carrying out the roof opening panel motor initialization. For additional information, refer to ROOF OPENING PANEL ALIGNMENT in this article.

1. Operate the roof opening panel control switch to the up/close position.
2. Release the roof opening panel control switch.
3. Operate the roof opening panel control switch to the up/close position again within 0.5 second until the roof opening panel stops (1 complete cycle).

Erasing Roof Opening Panel Motor Initialization

Note. The erasing procedure is to be carried out only when the roof opening panel motor is removed from the roof opening panel.

Note. This procedure must be carried out before installing a previously used roof opening panel motor.

1. Connect the roof opening panel motor electrical connector.
2. Operate the roof opening panel control switch to the up/close position until the roof opening panel motor stops.
3. Release the roof opening panel control switch.
4. Operate the roof opening panel control switch again to the up/close position and hold for 30 seconds. With the roof opening panel control switch held, the roof opening panel motor rotates in 1 direction.
5. Release the roof opening panel control switch.
6. Operate the roof opening panel control switch to the down/open position. If the roof opening panel motor does not rotate, the erasing procedure has been carried out successfully.
7. If the roof opening panel motor rotates (with the roof opening panel control switch in the down/open position), repeat the procedure.

Scheme 24

1. For additional information, refer to the procedures in this article.

Scheme 25

Scheme 26

1. Place the roof opening panel in the FULL open position.
2. From the top of the vehicle, press the spring steel locating tab downward on each side with a flat-blade screwdriver while pushing the deflector toward the rear of the vehicle.
3. Tilt the air deflector upward and pull forward to remove.
4. To install, reverse the removal procedure. Make sure the locating tabs are firmly locked in place.
