Speed Control System: Removal & Installation Ford Focus I facelift

Cruise Control Systems 2 illustrations ~365 words

REMOVAL AND INSTALLATION

  1. Disconnect the speed control actuator electrical connector.
  2. Remove the 3 bolts and the speed control actuator. To install, tighten to 9 Nm (80 lb-in).
  3. Press the locking tab and rotate the speed control cable cover counterclockwise to remove.
  4. Remove the speed control cable. Press the spring retainer. Slide the core wire end out of the speed control actuator pulley and disconnect the speed control actuator cable.
  5. To install, reverse the removal procedure.

Scheme 21

Scheme 21: Speed Control Cable
ItemPart NumberDescription
1Speed control actuator bolts (3 required)
29C735Speed control actuator
39A820Speed control cable
  1. If equipped, remove the watershield. Remove the screw. Remove the 2 pin-type retainers.
  2. Disconnect the speed control cable from the throttle body linkage. Rotate the throttle body linkage and disconnect the speed control cable end by pushing forward.
  3. Position the speed control cable away from the throttle body bracket retaining ring.
  4. Remove the speed control cable from the throttle body bracket. Using a suitable tool, remove the retaining ring from the throttle body bracket.
  5. Remove the speed control cable from the retaining clips.
  6. Disconnect the speed control actuator electrical connector.
  7. Remove the 3 bolts and the speed control actuator. To install, tighten to 9 Nm (80 lb-in).
  8. Press the locking tab and rotate the speed control cable cover counterclockwise to remove.
  9. Remove the speed control cable from the speed control actuator pulley. Press the spring retainer. Slide the core wire end out of the speed control actuator pulley and disconnect the speed control actuator cable.
  10. To install, reverse the removal procedure.

Scheme 22

Scheme 22: Speed Control Deactivator Switch
ItemPart NumberDescription
1Speed control deactivator switch electrical connector (part of 14401)
29F924Speed control deactivator switch

REMOVAL

  1. Disconnect the electrical connector and remove the speed control deactivator switch. Rotate the speed control deactivator switch counterclockwise.

INSTALLATION

  1. Pull out the speed control deactivator switch plunger until it is fully extended. Measure the plunger length. It should measure 24 mm (0.94 in).
  2. Apply and hold the brake pedal.
  3. Install the speed control deactivator switch by turning the switch clockwise.
  4. Slowly release the brake pedal.
  5. Connect the speed control deactivator switch electrical connector.
  1. Remove the driver air bag module. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-278281) article.
  2. Disconnect the speed control switch electrical connector.
  3. Remove the 4 screws and the speed control switches. To install, tighten to 5 Nm (44 lb-in).
  4. To install, reverse the removal procedure.
