TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Front seat retaining bolts | 38 |
| Front seat backrest retaining nuts | 28 |
| Front seat cushion retaining bolts | 28 |
| Rear seat backrest retaining bolts | 28 |
| Rear seat backrest latch retaining bolts | 28 |
| Rear seat cushion retaining bolts | 38 |
TORQUE SPECIFICATIONS
Scheme 1
The vehicle is equipped with a manual adjust 4-way driver seat. Lumbar adjustment is standard on luxury seats and available as an option in some markets. The passenger seat is a manual adjust 2-way seat.
Side air bags are optional on those vehicles with driver and passenger air bags. For additional information, refer to SAFETY BELT SYSTEM or AIR BAG RESTRAINT SYSTEMS .
The rear seats are of the split 60/40 design, with the 60 rear seat backrest incorporating the safety belt retractor on 3-door and wagon variants.
Seats - SVT
Refer to POWER SEATS for schematic and connector information.
