Seat System: Removal & Installation Ford Focus I рестайлинг

Removal

Note. If a seat equipped with a seat mounted side air bag and/or a safety belt pretensioner (if equipped) system is being serviced, the supplemental restraint system (SRS) must be disabled.

Note. The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 8

Scheme 9

Scheme 10

Scheme 11

1. Move the seat fully rearwards.
2. Remove the seat track outer trim cover.
3. Remove the front retaining bolts.
4. Move the seat fully forwards.
5. Disable the SRS. For additional information, refer to «DISABLING SYSTEM»(ref-170306-S06776258282005011000000) .
6. Remove the rear retaining bolts.
7. Disconnect the underseat electrical connector.

Scheme 12

Scheme 13

Scheme 14

1. Connect the underseat electrical connector.
2. Install the rear retaining bolts.
3. Reactivate the SRS. For additional information, refer to «ACTIVATING SYSTEM»(ref-170306-S31995908812005011000000) .
4. Move the seat fully rearward.
5. Install the front retaining bolts.
6. Install the seat track outer trim cover.

Note. If a seat equipped with a seat mounted side air bag and/or a safety belt pretensioner (if equipped) system is being serviced, the supplemental restraint system (SRS) must be disabled.

Note. The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. Raise the seat to maximum height.
2. Disable the SRS. For additional information, refer to «DISABLING SYSTEM»(ref-170306-S06776258282005011000000) .
3. Remove the front seat cushion.
4. Remove the seat outer trim panel. Detach and discard the front retaining clip. Detach the rear locking tang.
5. Remove the seat outer trim panel. Using a suitable screwdriver, detach the rear retaining clip. Raise the seat outer trim panel.
6. Detach the side air bag module electrical connector from the underside of the seat. Using a suitable screwdriver, depress the locking tang. Disconnect the electrical connector. Detach the retaining clip.
7. Detach the side air bag module wiring harness from the seat frame. Detach the retaining clips.
8. Detach the backrest heater mat electrical connector from the underside of the seat. Using a suitable screwdriver, depress the locking tang. Disconnect the electrical connector. Detach the retaining clip.
9. Detach the backrest heater mat wiring harness from the seat frame. Detach the retaining clips.
10. Remove the safety belt buckle and pretensioner.
11. Remove the backrest recliner handwheel.
12. Remove the seat inner trim panel retaining clip pin and remove the trim panel.
13. Remove the front seat backrest. Release the front seat backrest latch. Remove the retaining nuts.

Installation

1. To install, reverse the removal procedure.
2. Reactivate the SRS. For additional information, refer to «ACTIVATING SYSTEM»(ref-170306-S31995908812005011000000) .

Note. If a seat equipped with a seat mounted side air bag and/or a safety belt pretensioner (if equipped) system is being serviced, the supplemental restraint system (SRS) must be disabled.

Note. The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

1. Disable the SRS. For additional information, refer to «DISABLING SYSTEM»(ref-170306-S06776258282005011000000) .
2. Remove the front seat cushion.
3. Remove the backrest recliner lever. Remove the screw.
4. Remove the outer side trim panel. Using a suitable screwdriver, detach the rear retaining clip. Raise the trim panel.
5. Detach the side air bag module electrical connectors from the underside of the seat. Using a suitable screwdriver, depress the locking tang. Disconnect the electrical connector.
6. Detach the wiring harness from the seat frame.
7. Remove the safety belt buckle (drive seat) or safety belt buckle and pretensioner (passenger seat).
8. Remove the inner side trim panel. Remove the retaining pin. Detach the rear retaining clip.
9. Remove the front seat backrest. Remove the retaining nuts. Slide the backrest to the side to remove it from the seat base frame.

1. To install, reverse the removal procedure.
2. Reactivate the SRS. For additional information, refer to «ACTIVATING SYSTEM»(ref-170306-S31995908812005011000000) .

Scheme 27

Scheme 28

1. Fold the rear seat cushion forwards.
2. Install the safety belt webbing retainer.
3. Detach the rear center safety belt buckle.
4. Fold the rear seat backrest forwards.
5. Remove the rear seat backrest. Remove the outer retaining bolts. Remove the center hinge locking plate retaining bolt.

1. To install, reverse the removal procedure.

Note. If a seat equipped with a seat mounted side air bag and/or a safety belt pretensioner (if equipped) system is being serviced, the supplemental restraint system (SRS) must be disabled.

Note. The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 29

Scheme 30

Scheme 31

Scheme 32

1. Remove the front seat and disable the SRS. For additional information, refer to «FRONT SEAT»(ref-207809-S01147521092005120100000) .
2. Detach the safety belt buckle pretensioner electrical connector from the underside of the seat. Using a suitable screwdriver, depress the locking tang. Disconnect the electrical connector. Detach the retaining clips.
3. Detach the cushion heater mat electrical connector from the underside of the seat. Using a suitable screwdriver, depress the locking tang. Disconnect the electrical connector. Detach the retaining clips.
4. Detach the seat height adjust motor electrical connector from the underside of the seat. Using a suitable screwdriver, depress the locking tang. Disconnect the electrical connector. Detach the retaining clips.
5. Remove the front seat cushion.

1. To install, reverse the removal procedure.
2. Install the front seat and activate the SRS. For additional information, refer to «FRONT SEAT»(ref-207809-S01147521092005120100000) .

Note. If a seat equipped with a seat mounted side air bag and/or a safety belt pretensioner (if equipped) system is being serviced, the supplemental restraint system (SRS) must be disabled.

Note. The air bag warning lamp illuminates when the RCM fuse is removed and the ignition switch is ON. This is normal operation and does not indicate a supplemental restraint system (SRS) fault.

Note. The SRS must be fully operational and free of faults before releasing the vehicle to the customer.

Scheme 33

Scheme 34

1. Remove the front seat and activate the SRS. For additional information, refer to «FRONT SEAT»(ref-207809-S01147521092005120100000) .
2. Detach the safety belt buckle sensor wiring harness and the safety belt buckle pretensioner wiring harness (if equipped) from the underside of the cushion. Detach the retaining clips.
3. Remove the front seat cushion.

1. To install, reverse the removal procedure.
2. Install the front seat and activate the SRS. For additional information, refer to «FRONT SEAT»(ref-207809-S01147521092005120100000) .

Scheme 35

Scheme 36

Scheme 37

1. Fold the rear seat backrest(s) forward.
2. Detach the backrest release cable.
3. Remove the backrest latch cover. Release the two retaining tangs.
4. Remove the backrest latch screws.
5. Remove the backrest release latch.

Scheme 38

1. To install, reverse the removal procedure.

Scheme 39

1. Disassemble the rear seat backrest. For additional information, refer to «REAR SEAT BACKREST»(ref-207809-S28118723612005120100000) .
2. Detach the retractor lock cable.
3. Remove the backrest latch. Remove the screws.

1. To install, reverse the removal procedure.

Note. Some seat backrest heater mats can become loose or folded. Read and follow all the instructions in this procedure to correctly repair a loose or folded seat backrest heater mat. If referred here from Diagnosis and Testing or to install a new seat backrest heater mat, follow only those steps that apply.

Scheme 40

Scheme 41

Scheme 42

Scheme 43

1. If equipped, remove the seat back lumbar support adjust lever.
2. Detach the backrest trim cover J-strip from the underside of the backrest.
3. Invert the backrest trim cover to access the lower ends of the tension rods. Detach the lower ends of the tension rods from the backrest.
4. Invert the backrest trim cover to expose the entire seat backrest heater mat.
5. If the seat backrest heater mat shows no signs of damage, does not require any new parts or is not subject to any other repair, adhesion reinforcement can be carried out. See «INSTALLATION»(ref-207809-S25974673842005120100000) for adhesion reinforcement.
6. Inspect the seat backrest heater mat to see if it has not adhered correctly or is partially folded together. If so it can be smoothed out and re-adhered. See «INSTALLATION»(ref-207809-S25974673842005120100000) .
7. Inspect the seat backrest heater mat to see if it is completely folded. If it is completely folded, a new seat backrest heater mat must be installed.
8. If a new heater mat is needed, slowly and carefully peel the heater mat adhesive strip from the backrest foam pad. If the foam pad begins to tear or if the adhesive is not separating cleanly from the backrest foam pad, stop and try to separate the other end of the adhesive strip from the backrest foam pad. If necessary, use a razor or other sharp knife to trim the heater mat from the foam pad.

Scheme 44

Scheme 45

1. If the seat backrest heater mat shows no signs of damage, does not require any new parts or is not subject to any other repair, carry out the following for adhesion reinforcement of the seat backrest heater mat. CAUTION: Apply only enough adhesive to properly bond the heater mat to the foam pad. Applying too much adhesive can result in adhesive bleeding through to the seat trim cover. Apply the adhesive in a strip no more than 25 mm (0.98 in) wide, along the outer edges of the heater mat and on the mating surfaces of the foam pad, to make sure no adhesive is applied under the heater mat wire. Also, do not apply adhesive to an existing adhesive strip on the heater mat itself. Poor adhesion will result. Neatly apply adhesive on the side edges of the heater mat and the mating surface on the foam pad. Press the edges down, while smoothing the heater mat down, to avoid wrinkling or puckering. Allow the adhesive to dry for 5 minutes before assembling the seat. Test the edges to make sure they adhere well enough to avoid pulling the heater mat up when the trim cover is reinstalled.
2. If the seat backrest heater mat is not adhered properly or is partially folded, carry out the following: Unfold and smooth out the heater mat. On the loose end of the heater mat, check the adhesive strip to see if the backing was ever removed to expose the adhesive. If the backing is still present, peel it off, position the heater mat in its original position and press down along the adhesive strip to secure the heater mat to the foam pad. Neatly apply adhesive on the entire top and bottom edges of the heater mat, forward of the adhesive strip and on the mating surface on the foam pad. Pull the heater mat into position and press the top and bottom edges down to adhere them to the foam pad Neatly apply adhesive on the side edges of the heater mat and the mating surface on the foam pad. Press the edges down, while smoothing the heater mat down, to avoid wrinkling or puckering. Allow the adhesive to dry for 5 minutes before assembling the seat. Test the edges to make sure they adhere well enough to avoid pulling the heater mat up when the trim cover is reinstalled.
3. Install a new seat backrest heater mat. Position the heater mat onto the foam pad, feeding the wire harness through the hole in the foam pad. Remove the paper strips covering the adhesive before adhering the heater mat to the foam pad. Neatly apply adhesive to all 4 edges of the heater mat and the mating surface on the foam pad. Press the edges down, while smoothing the heater mat down, to avoid wrinkling or puckering. Allow the adhesive to dry for 5 minutes before assembling the seat. Test the edges to make sure they adhere well enough to avoid pulling the heater mat up when the trim cover is reinstalled.
4. Roll the backrest trim cover down. Attach the lower ends of the tension rods to the backrest.
5. Attach the backrest trim cover J-strip from the underside of the backrest.
6. If equipped, install the seat back lumbar support adjust lever.

Note. Some seat cushion heater mats can become loose or folded. Read and follow all the instructions in this procedure to correctly repair a loose or folded seat cushion heater mat. If referred here from Diagnosis and Testing or to install a new seat cushion heater mat, follow only those steps that apply.

Scheme 46

Scheme 47

1. Remove the front seat. For additional information, refer to «FRONT SEAT»(ref-207809-S01147521092005120100000) .
2. Remove the front seat cushion. For additional information, refer to «FRONT SEAT CUSHION - SVT»(ref-207809-S24516486052005120100000) or «FRONT SEAT CUSHION»(ref-207809-S01581380242005120100000) .
3. Disassemble the front seat cushion. For additional information, refer to «FRONT SEAT CUSHION»(ref-207809-S01581380242005120100000) .
4. If the seat cushion heater mat shows no signs of damage, does not require any new parts or is not subject to any other repair, adhesion reinforcement can be carried out. See «INSTALLATION»(ref-207809-S08327008312005120100000) for adhesion reinforcement.
5. Inspect the seat cushion heater mat to see if it has not adhered correctly or is partially folded together. If so it can be smoothed out and re-adhered. See «INSTALLATION»(ref-207809-S08327008312005120100000) .
6. Inspect the seat cushion heater mat to see if it is completely folded. If it is completely folded, a new seat cushion heater mat must be installed.
7. If a new heater mat is needed, slowly and carefully peel the heater mat adhesive strip from the cushion foam pad. If the foam pad begins to tear or if the adhesive is not separating cleanly from the cushion foam pad, stop and try to separate the other end of the adhesive strip from the cushion foam pad. If necessary, use a razor or other sharp knife to trim the heater mat from the foam pad.

1. If the seat cushion heater mat shows no signs of damage, does not require any new parts or is not subject to any other repair, carry out the following for adhesion reinforcement of the seat cushion heater mat. CAUTION: Apply only enough adhesive to properly bond the heater mat to the foam pad. Applying too much adhesive can result in adhesive bleeding through to the seat trim cover. Apply the adhesive in a strip no more than 25 mm (0.98 in) wide, along the outer edges of the heater mat and on the mating surfaces of the foam pad, to make sure no adhesive is applied under the heater mat wire. Also, do not apply adhesive to an existing adhesive strip on the heater mat itself. Poor adhesion will result. Neatly apply adhesive on the side edges of the heater mat and the mating surface on the foam pad. Press the edges down, while smoothing the heater mat down, to avoid wrinkling or puckering. Allow the adhesive to dry for 5 minutes before assembling the seat. Test the edges to make sure they adhere well enough to avoid pulling the heater mat up when the trim cover is reinstalled.
2. If the seat cushion heater mat is not adhered properly or is partially folded, carry out the following: Unfold and smooth out the heater mat. On the loose end of the heater mat, check the adhesive strip to see if the backing was ever removed to expose the adhesive. If the backing is still present, peel it off, position the heater mat in its original position and press down along the adhesive strip to secure the heater mat to the foam pad. Neatly apply adhesive on the entire front edge of the heater mat forward of the adhesive strip and on the mating surface on the foam pad. Pull the heater mat into position and press the leading edge down to adhere it to the foam pad Neatly apply adhesive on the side edges of the heater mat and the mating surface on the foam pad. Press the edges down, while smoothing the heater mat down, to avoid wrinkling or puckering. Allow the adhesive to dry for 5 minutes before assembling the seat. Test the edges to make sure they adhere well enough to avoid pulling the heater mat up when the trim cover is reinstalled.
3. Install a new seat cushion heater mat. Position the heater mat onto the foam pad, feeding the wire harness through the hole in the foam pad. Remove the paper strips covering the adhesive before adhering the heater mat to the foam pad. Neatly apply adhesive to all 4 edges of the heater mat and the mating surface on the foam pad. Press the edges down, while smoothing the heater mat down, to avoid wrinkling or puckering. Allow the adhesive to dry for 5 minutes before assembling the seat. Test the edges to make sure they adhere well enough to avoid pulling the heater mat up when the trim cover is reinstalled.
