Electronic Engine Controls: Other Ford Focus I рестайлинг

Material

MATERIAL SPECIFICATION

Scheme 57

1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-207791) .
2. Remove the camshaft position (CMP) sensor. Disconnect the CMP sensor electrical connector. Remove the bolt retaining the CMP sensor. Remove the CMP sensor.
3. To install, reverse the removal procedure.

Scheme 58

Scheme 59

1. Raise and support the vehicle. For additional information, refer to «JACKING AND LIFTING»(ref-234418) .
2. Disconnect the crankshaft position (CKP) sensor electrical connector.
3. Remove the CKP sensor.

Scheme 60

1. To install, reverse the removal procedure.

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-207791) .
2. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to «JACKING AND LIFTING»(ref-234418) .
3. Remove the two retaining screws and the crankshaft pulley shield.
4. Disconnect the crankshaft position (CKP) sensor electrical connector.
5. Remove the plug.
6. Turn the crankshaft pulley bolt to position the number one cylinder at top dead center, and install the special tool.
7. Remove the CKP sensor retaining bolts and the sensor.
8. Install an 6 mm x 18 mm standard bolt.

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

1. Install the CKP sensor, but do not tighten the bolts at this time.
2. Adjust the CKP sensor alignment jig and tighten the bolts.
3. Connect the CKP sensor electrical connector.
4. Remove the 6 mm bolt.
5. Remove the crankshaft timing peg.
6. Install the plug.
7. Install the crankshaft pulley shield.

Scheme 74

Scheme 75

Scheme 76

1. Disconnect the power steering pressure (PSP) switch electrical connector.
2. Remove the PSP switch.
3. To install, reverse the removal procedure.

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-207791) .
2. Remove the instrument panel side trim.
3. Remove the cowl side trim panel.
4. Remove the glove box.
5. Remove the passenger side lower footwell trim panel.
6. Remove the generic electronic module (GEM). Remove the two retaining nuts. Remove the GEM module and the bracket and position aside.
7. Disconnect the powertrain control (PCM) module electrical connectors and remove the PCM.
8. To install, reverse the removal procedure.

Scheme 83

Scheme 84

Scheme 85

Scheme 86

1. Remove the air cleaner outlet pipe.
2. Disconnect idle air control (IAC) valve electrical connector.
3. Remove the IAC valve upper bolt.
4. Raise and support the vehicle. For additional information, refer to «JACKING AND LIFTING»(ref-234418) .
5. Remove the IAC valve.

Scheme 87

Scheme 88

1. To install, reverse the removal procedure.

Scheme 89

Scheme 90

1. Disconnect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-207791) .
2. Remove throttle body snow shield. Remove the retaining screw. Release the emission tube. Remove the snow shield.
3. Remove the idle air control (IAC) valve. Disconnect the IAC electrical connector. Remove the two IAC retaining screws. Remove the IAC valve.
4. To install, reverse the removal procedure.

Scheme 91

Scheme 92

Scheme 93

1. Remove the air cleaner outlet pipe.
2. Disconnect the mass air flow (MAF) sensor electrical connector.
3. Remove the MAF sensor.
