GENERAL SPECIFICATIONS
| Item | Specification |
|---|---|
| MERCON® Multi-purpose transmission fluid | MERCON® |
GENERAL SPECIFICATIONS
STEERING GEAR INSULATOR BUSHING SPECIFICATION
| Description | Nominal Measurement mm | Tolerance mm |
|---|---|---|
| Bushing adjacent to the steering gear valve body | 5.83 | +/-0.5 |
| Bushing furthest from the steering gear valve body | 4.5 | +/- 0.5 |
STEERING GEAR INSULATOR BUSHING SPECIFICATION
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Power steering pressure switch | 20 |
| Pressure line to pump union | 65 |
| Power steering pump bolts | 23 |
| Pressure line support bracket (Zetec-E engine) | 25 |
| Pressure line support bracket (SPI engine) | 5 |
| Power steering gear hose clamps | 23 |
| Fluid cooler bolts | 5 |
| Steering gear bolts | 80 |
| Steering column shaft to steering gear pinion bolt | 35 |
| Crossmember rear bolts | 200 |
| Crossmember front bolts | 115 |
| Steering gear heat shield | 6 |
| Support insulator center bolt | 50 |
| Stabilizer bar link nuts | 50 |
| Tie-rod end retaining nuts | 47 |
| Wheel nuts | 128 |
| Steering column shaft coupling | 28 |
TORQUE SPECIFICATIONS
Scheme 1
Scheme 2
