Power Steering System: Specifications Ford Focus I рестайлинг

Manual & Power Steering 39 illustrations ~819 words

LUBRICANTS, FLUIDS, SEALERS AND ADHESIVES SPECIFICATION

ItemSpecification
MERCON® Multi-purpose transmission fluidMERCON®

LUBRICANTS, FLUIDS, SEALERS AND ADHESIVES SPECIFICATION

STEERING GEAR INSULATOR BUSHING SPECIFICATION

DescriptionNominal Measurement mmTolerance mm
Bushing adjacent to the steering gear valve body5.830.5
Bushing furthest from the steering gear valve body4.5+/- 0.5

STEERING GEAR INSULATOR BUSHING SPECIFICATION

TORQUE SPECIFICATIONS

DescriptionNm
Power steering pressure switch20
Pressure line to pump union65
Power steering pump bolts23
Pressure line support bracket10
Power steering gear hose clamps23
Fluid cooler bolts5
Steering gear bolts80
Steering gear clamp plate18
Steering column shaft to steering gear pinion bolt35
Crossmember rear bolts200
Crossmember front bolts115
Steering gear heat shield6
Support insulator center bolt50
Stabilizer bar link nuts50
Tie-rod end retaining nuts47
Wheel nuts128
Steering column shaft coupling28

TORQUE SPECIFICATIONS

Scheme 8

Scheme 8: 2.0L Zetec-E Shown, Other Variants Similar

Refer to STEERING SYSTEM-GENERAL INFORMATION .

Scheme 9

Scheme 9: Special Tool(s)

Scheme 10

Scheme 10: Removal

Scheme 11

Scheme 11

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14

Scheme 15

Scheme 15

Scheme 16

Scheme 16
  1. Remove the accessory drive belt. For additional information, refer to «SPECIFICATIONS & DRIVE BELT ROUTING»(ref-165277) .
  2. Using the special tool, disconnect the fluid cooler hose. Insert the special tool into the hose quick-release coupling. Move the special tool along the pipe to release the locking tangs. Allow the fluid to drain into a suitable container.
  3. Disconnect the power steering line from the power steering pump. Allow the fluid to drain into a suitable container.
  4. Lower the vehicle.
  5. Detach the power steering line support bracket. Remove the bolts. Detach the speed control cable (if equipped).
  6. Disconnect the power steering pressure (PSP) switch electrical connector. Depress the locking tang.
  7. Disconnect the power steering hose from the power steering pump. Allow the fluid to drain into a suitable container.
  8. Remove the power steering pump.
  9. Remove the PSP switch.

Scheme 17

Scheme 17: Installation

Scheme 18

Scheme 18

Scheme 19

Scheme 19

Scheme 20

Scheme 20

Scheme 21

Scheme 21

Scheme 22

Scheme 22

Scheme 23

Scheme 23
  1. Using the special tool, install a new O-ring seal onto the steering gear to power steering pump union. Push the new O-ring seal onto the special tool. Locate the special tool onto the union and install the O-ring seal.
  2. Install the PSP switch.
  3. Install the power steering pump.
  4. Connect the power steering hose to the power steering pump.
  5. Connect the PSP switch electrical connector.
  6. Attach the power steering line support bracket. Attach the bolts. Attach the speed control cable (if equipped).
  7. Raise and support the vehicle. For additional information, refer to «JACKING AND LIFTING»(/ford/focus/i-2001-2007/remont/hoistjack/#jacking-and-lifting) .
  8. Connect the power steering line.
  9. Connect the fluid cooler hose.
  10. Install the accessory drive belt. For additional information, refer to «SPECIFICATIONS & DRIVE BELT ROUTING»(ref-165277) .
  11. Fill the power steering system.

Scheme 24

Scheme 24: Special Tool(s)

Scheme 25

Scheme 25: Removal

Scheme 26

Scheme 26

Scheme 27

Scheme 27

Scheme 28

Scheme 28

Scheme 29

Scheme 29
  1. Detach the accessory drive belt from the power steering pump pulley. Using a 1/2" square drive breaker bar in the hole provided, rotate the tensioner in a clockwise direction. Detach the accessory drive belt from the power steering pump pulley.
  2. Remove the power steering pump pulley retaining nut.
  3. Remove the power steering pump pulley.
  4. Detach the power steering fluid reservoir hose from the power steering pump. Allow the fluid to drain into a suitable container.
  5. Detach the power steering high-pressure line from the power steering pump. Allow the fluid to drain into a suitable container.
  6. Remove the power steering pump.
  7. Remove the power steering fluid reservoir to power steering pump hose union. Discard the O-ring seal.

Scheme 30

Scheme 30: Installation

Scheme 31

Scheme 31

Scheme 32

Scheme 32

Scheme 33

Scheme 33

Scheme 34

Scheme 34

Scheme 35

Scheme 35
  1. Install a new power steering fluid reservoir hose union O-ring seal.
  2. Install the power steering fluid reservoir union.
  3. Install the power steering pump.
  4. Using the special tool, install a new O-ring seal onto the power steering high-pressure line to power steering pump union. Push the O-ring seal onto the special tool. Locate the special tool onto the union and install the O-ring seal.
  5. Attach the power steering high-pressure line to the power steering pump.
  6. Attach the power steering fluid reservoir hose to the power steering pump.
  7. Install the power steering pump pulley.
  8. Attach the accessory drive belt to the power steering pump pulley. Using a 1/2" square drive breaker bar in the hole provided, rotate the tensioner in a clockwise direction. Attach the accessory drive belt to the power steering pump pulley.
  9. Fill the power steering system. For additional information, refer to «STEERING SYSTEM-GENERAL INFORMATION»(ref-207742) .

Scheme 36

Scheme 36: Special Tool(s)

Scheme 37

Scheme 37: Removal

Scheme 38

Scheme 38

Scheme 39

Scheme 39

Scheme 40

Scheme 40

Scheme 41

Scheme 41

Scheme 42

Scheme 42

Scheme 43

Scheme 43

Scheme 44

Scheme 44

Scheme 45

Scheme 45

Scheme 46

Scheme 46
  1. Remove the accessory drive belt. For additional information, refer to «SPECIFICATIONS & DRIVE BELT ROUTING»(ref-165277) .
  2. Detach the fender splash shield from the front bumper cover to gain access to the right-hand headlamp assembly lower retaining bolt.
  3. Remove the right-hand headlamp assembly lower retaining bolt.
  4. Using the special tool, disconnect the power steering fluid cooler line from the power steering fluid cooler. Insert the special tool into the spring lock coupling. Slide the special tool along the line to release the locking tangs. Allow the fluid to drain into a suitable container.
  5. Disconnect the power steering line from the power steering pump. Allow the fluid to drain into a suitable container. Discard the O-ring seal.
  6. Remove the power steering pump lower retaining bolts.
  7. Lower the vehicle.
  8. Remove the radiator grille.
  9. Remove the right-hand headlamp assembly. Disconnect the electrical connector.
  10. Disconnect the power steering hose from the power steering pump. Allow the fluid to drain into a suitable container.
  11. Detach the power steering line from the engine and position to one side.
  12. Remove the power steering pump.
