The antenna system consists of the following
- Antenna mast
- Antenna base
- Insulator clip and retaining screw
- Antenna cable
The antenna receives AM and FM radio waves. The radio waves are sent to the audio unit through the radio antenna lead-in cable.
The fixed mast antenna is mounted to the roof. The antenna is connected to the audio unit by an antenna cable routed down the A-pillar and under the sound deadening panel.
REFER to ENTERTAINMENT SYSTEM - GENERAL INFORMATION .
Scheme 46
Scheme 47
Scheme 48
Scheme 49
Scheme 50
Scheme 51
- Remove the antenna mast from the base.
- Detach the interior light.
- Remove the interior lamp. Disconnect the interior light electrical connector.
- Remove the interior lamp bezel.
- Remove the antenna cable/base retaining screw.
- Remove the antenna base.
