Steering Column - Except Electric Ford Focus ST III

Steering Column 4 illustrations ~396 words

Steering Column Overview

The steering column system consists of the following components

  1. Steering wheel
  2. Deployable steering column
  3. Upper and lower steering column shrouds
  4. Steering column switches
  5. Intermediate shaft

The steering column is the mechanical linkage between the steering wheel and the steering gear. The steering wheel is mounted to a shaft which passes through the center of the steering column. The shaft is centered by roller ball bearings within the steering column. The steering column shaft then connects the steering column to the steering gear. The steering column shaft utilizes U-joint type couplings.

If a crash event occurs, the steering column is equipped with a deployable feature.

For additional information, refer to: Airbag and Safety Belt Pretensioner Supplemental Restraint System (SRS) - Vehicles Built From: 11-June-2012 - Component Location ( AIRBAG AND SAFETY BELT PRETENSIONER SUPPLEMENTAL RESTRAINT SYSTEM (SRS) - VEHICLES BUILT UP TO: 25-JUNE-2012 - COMPONENT LOCATION ).

Steering Wheel Cover Repair

NameSpecification
Instant Gel Adhesive TA-19WSK-M2G402-A4

MATERIALS SPECIFICATIONS

  1. If necessary, remove the steering wheel. Refer to: «Steering Wheel»(/ford/focus-st/iii-2012-2015/remont/steering-column/#steering-column-except-electric) .
  2. Position the loose leather out of the way.
  3. Apply the specified adhesive evenly over the wheel spoke. Material: Instant Gel Adhesive / TA-19 (WSK-M2G402-A4)
  4. Position the loose leather back into the original position.
  5. Smooth the leather and tuck in for neat appearance.
  6. Apply pressure (for at least 30 seconds) until the leather is bonded to the wheel spoke.
  7. If removed, install the steering wheel. Refer to: «Steering Wheel»(/ford/focus-st/iii-2012-2015/remont/steering-column/#steering-column-except-electric) .

Scheme 1

Scheme 1: Removal
Scheme 1: Removal
  1. Refer to: Health and Safety Precautions ( «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) ).
  2. Refer to: Driver Airbag ( «DRIVER AIRBAG»(/ford/focus-st/iii-2012-2015/remont/airbag/#supplemental-restraint-system-except-electric) ).
  3. Torque: 48 Nm
  4. Apply tape to specified component or area.

Installation

  1. To install, reverse the removal procedure.

Scheme 2

Scheme 2: Removal
Scheme 2: Removal

Scheme 3

Scheme 3
Scheme 3
  1. Refer to: Health and Safety Precautions ( «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) ).
  2. Refer to: «Steering Wheel»(/ford/focus-st/iii-2012-2015/remont/steering-column/#steering-column-except-electric) .
  3. Refer to: Driver Lower Airbag - Vehicles Built From: 11-June-2012 ( «DRIVER LOWER AIRBAG - VEHICLES BUILT FROM: 11-JUNE-2012»(/ford/focus-st/iii-2012-2015/remont/airbag/#supplemental-restraint-system-except-electric) ).
  4. NOTE: Steering column without push button start shown in illustration, steering column with push button start similar.
  5. Discard the specified component. Follow local disposal regulations. Torque: 28 Nm
  6. If equipped.
  7. Discard the specified component. Follow local disposal regulations. Torque: 28 Nm

Scheme 4

Scheme 4
Scheme 4
  1. To install, reverse the removal procedure.
