Generator and Regulator - Except Electric Ford Focus ST III

Specifications

GENERAL SPECIFICATIONS

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) .
2. Refer to: «JACKING AND LIFTING - OVERVIEW»(/ford/focus-st/iii-2012-2015/remont/hoistjack/#jacking-lifting-except-electric) .
3. Refer to: «BATTERY DISCONNECT AND CONNECT»(/ford/focus-st/iii-2012-2015/remont/charging-system/#battery-mounting-and-cables-except-electric) .

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

1. Finger-tight.
2. Torque : 8 Nm
3. Torque : 25 Nm Torque : 25 Nm Torque : 25 Nm
4. Torque : 17 Nm
5. Refer to: «BATTERY DISCONNECT AND CONNECT»(/ford/focus-st/iii-2012-2015/remont/charging-system/#battery-mounting-and-cables-except-electric) .

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) .
2. Refer to: «JACKING AND LIFTING - OVERVIEW»(/ford/focus-st/iii-2012-2015/remont/hoistjack/#jacking-lifting-except-electric) .
3. Refer to: «BATTERY DISCONNECT AND CONNECT»(/ford/focus-st/iii-2012-2015/remont/charging-system/#battery-mounting-and-cables-except-electric) .
4. Refer to: «AIR CONDITIONING (A/C) COMPRESSOR BELT»(/ford/focus-st/iii-2012-2015/remont/accessory-drive-belts/#accessory-drive-20l-ecoboost__air-conditioning-ac-compressor-belt) .
5. NOTE: This step is only necessary when installing a new component.

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

1. If removed, finger-tight.
2. Finger-tight.
3. Torque : 25 Nm
4. Torque : 25 Nm If removed. Torque : 25 Nm If removed. Torque : 25 Nm
5. Torque : 25 Nm
6. Torque : 17 Nm
7. Refer to: «AIR CONDITIONING (A/C) COMPRESSOR BELT»(/ford/focus-st/iii-2012-2015/remont/accessory-drive-belts/#accessory-drive-20l-ecoboost__air-conditioning-ac-compressor-belt) .
8. Refer to: «BATTERY DISCONNECT AND CONNECT»(/ford/focus-st/iii-2012-2015/remont/charging-system/#battery-mounting-and-cables-except-electric) .

Scheme 41

1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#service-information-introduction-except-electric) .
2. Refer to: «Generator - 2.0L Duratec-HE»(/ford/focus-st/iii-2012-2015/remont/charging-system/#generator-and-regulator-except-electric) . Refer to: «Generator - 2.0L EcoBoost»(/ford/focus-st/iii-2012-2015/remont/charging-system/#generator-and-regulator-except-electric) .
3. Using a 17 mm hex tool and an impact gun, remove the clutch pulley. A couple of short bursts with the impact gun will remove the clutch pulley.

Scheme 42

Scheme 43

1. Hand start.
2. While holding the outer diameter of the clutch pulley, torque the clutch pulley using a 17 mm hex tool, 75 Nm torque stick and an impact gun for 3-4 seconds. This makes sure the proper torque has been applied. Torque : 75 Nm
3. Install a new cap onto the pulley with the rubber button facing inwards.
4. Refer to: «Generator - 2.0L Duratec-HE»(/ford/focus-st/iii-2012-2015/remont/charging-system/#generator-and-regulator-except-electric) . Refer to: «Generator - 2.0L EcoBoost»(/ford/focus-st/iii-2012-2015/remont/charging-system/#generator-and-regulator-except-electric) .
