Scheme 121
| Item | Description |
|---|---|
| 1 | Single-speed reduction gear |
| 2 | Park pawl mechanism |
| 3 | TR sensor |
| 4 | TCM |
OVERVIEW
| WARNING | To prevent the risk of high-voltage shock, always follow precisely all warnings and service instructions, including instructions to depower the system. The high-voltage hybrid system utilizes approximately 300 volts DC, provided through high-voltage cables to its components and modules. The high-voltage cables and wiring are identified by orange harness tape or orange wire covering. All high-voltage components are marked with high-voltage warning labels with a high-voltage symbol. Failure to follow these instructions may result in serious personal injury or death. |
The transmission assembly has the following components
- Single-speed reduction gear
- Park pawl mechanism
- TR sensor
- TCM
Single Speed Gearbox
This vehicle has a single speed gear reduction transmission that transfers power from the electric motor to the halfshafts. The gear reduction system is mounted on the back of the electric motor and is enclosed by a gear box housing. The gear reduction system consists of 3 component: the input gear assembly, intermediate shaft assembly and a differential assembly.
Park Pawl
This transmission has a park pawl mechanism with a park gear, park pawl, and a park pawl actuator rod. The park gear is splined to the intermediate shaft assembly. The park pawl is pinned to the gear box housing and the electric motor housing. The park pawl actuator rod is connected to the manual lever detent plate and pushes the park pawl into the park gear when park is selected.
TR Sensor
The TR sensor is bolted to the gear box housing and is keyed to the manual shaft by a flat keyway. The TR sensor provides the PCM with a signal for the manual lever position and is not adjustable.
TCM
The TCM is mounted on the electric motor and is not serviceable. The TCM converts high-voltage DC current into 3-phase AC current for the electric motor. The TCM also supplies fused high-voltage DC current to the DC/DC converter, air conditioning compressor module (ACCM) and the electric supplemental PTC heater.
System Operation
| Broadcast Message | Originating Module | Message Purpose |
|---|---|---|
| PATS security data | GWM | The GWM relays PATS status to allow or prohibit electric drive operation. |
| ABS Active | ABS | The ABS module indicates activity to the TCM. |
| Transmission HV Discharge Command | PCM | The PCM commands the TCM to discharge the high voltage capacitors. |
| Traction Battery Voltage | BECM | The BECM relays the current HVTB voltage. |
| Traction Battery Contactor Command | BECM | The BECM indicates that the contactors are opening or closing. |
| Motor A Torque Request | PCM | The PCM commands a specified output torque from the electric motor. |
| Inverter Coolant Temperature | PCM | The PCM relays coolant temperature at the high voltage inverters. |
| DC/DC High Voltage | DCDC | The DC/DC converter reports HV bus voltage. |
| Odometer Master Value | GWM | The GWM shares the master odometer count with all EV HS-CAN modules. |
NETWORK MESSAGE CHART
Park
When the selector lever is in the park position, the TR sensor sends a signal of 4.20-4.50 volts to the PCM on pins 1-2 and 0.60-0.90 volts on pins 4-5. The park pawl locks the final drive to the gearbox. Voltage is not supplied to the electric motor.
Reverse
When the selector lever is in the reverse position, the TR sensor sends a signal of 3.40-3.70 volts to the PCM on pins 1-2 and 1.40-1.70 volts on pins 4-5. The vehicle can only be operated in a rearward direction and the reversing lamps are illuminated. The PCM sends a signal to the TCM to supply voltage to the electric motor with reverse polarity based off of the TR sensor signal.
Neutral
When the selector lever is in the neutral position, the TR sensor sends a signal of 2.60-2.90 volts to the PCM on pins 1-2 and 2.20-2.50 volts on pins 4-5. The electric motor does not input any torque to the gearbox. Voltage is removed from the electric motor.
Drive
When the selector lever is in the drive position, the TR sensor sends a signal of 1.80-2.10 volts to the PCM on pins 1-2 and 3-3.30 volts on pins 4-5. The PCM sends a signal to the TCM to supply voltage to the electric motor based off of the TR sensor signal.
Low
When the selector lever is in the low position, the TR sensor sends a signal of 1-1.30 volts to the PCM on pins 1-2 and 3.80-4.10 volts on pins 4-5. The PCM sends a signal to the TCM to supply voltage to the electric motor based off of the TR sensor signal. In low, conventional low position is simulated with limited RPM and engine braking is simulated through the regenerative braking.
Scheme 122
The single speed gear reduction transmission has an input gear assembly, intermediate shaft assembly and a differential assembly.
The input gear is pressed into a bearing retained in the motor housing by a snap ring and has 2 inner roller bearings that allows it to spin on the RH outer surface of the differential. The input gear transfers torque from the electric motor to the intermediate shaft assembly.
The intermediate shaft assembly spins on a bearing that is pressed into the motor housing and a bearing that is pressed into the gearbox housing. The intermediate shaft assembly has the park gear splined to it. The intermediate shaft transfers torque from the input gear to the differential ring gear.
The differential spins on 2 roller bearings housed in the input gear and a bearing that is retained by a snap ring in the gearbox housing. The differential is a conventional type with 2 pinion gears supported by a pinion shaft and 2 side gears supported by the differential case, the LH halfshaft and the transfer shaft (which splines to the RH halfshaft).
The gear reduction transmission has a final drive ratio of 7.82:1.
Scheme 123
The park gear is located on the intermediate shaft assembly. There are lugs around the outer diameter of the park gear to allow the park pawl to hold the park gear stationary to the motor housing, which holds the differential in place and keeps the vehicle from moving. The park pawl is pinned to the electric motor housing and the gear housing. The park pawl actuator rod is connected to the manual shaft detent plate and pushes the park pawl into the park gear when park is selected.
Scheme 124
The TR sensor has a 6-pin connector. The TR sensor is bolted to the gear box housing and is keyed to the manual shaft by a flat keyway. The manual shaft is turned by the selector lever linkage and the manual lever. The TR sensor sends a signal to the PCM to start the vehicle in PARK and NEUTRAL. The TR sensor opens/closes a set of 4 switches that are monitored by the PCM to determine the position of the manual lever (P, R, N, D, L). The TR sensor is not adjustable.
Scheme 125
The primary purpose of the TCM is to convert high-voltage DC current into 3-phase AC current to supply the field coils of the electric motor when requested by the PCM . This is accomplished through the use of inverters and internal speed sensors. Additionally, the TCM carries out regenerative braking when requested by the brake system control module (BSCM) by reconfiguring the electric motor to act as a generator. This decelerates the vehicle and returns energy to the high voltage traction battery (HVTB), extending vehicle range.
The TCM also serves as a high-voltage DC junction box, distributing fused high-voltage DC to the following underhood components
- DC/DC converter
- Air conditioning compressor module (ACCM)
- Electric supplemental PTC heater
The TCM and electric motor are serviceable as an assembly only. Do not attempt to open or carry out internal repairs on the TCM and electric motor.
DTC Chart: Transmission Control Module (TCM)
Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to DIAGNOSTIC METHODS for information about these practices.
Note. Before performing a self-test, turn the vehicle off and wait 20 seconds.
| DTC | Description | Action |
|---|---|---|
| P0297:94 | Vehicle Overspeed Condition: Unexpected Operation | This DTC sets if the motor speed exceeds 10, 000 rpm. CLEAR the DTC . REPEAT the self-test. RETURN the vehicle to the customer with information about the DTC . |
| P0560:16 | System Voltage: Circuit Voltage Below Threshold | GO to PINPOINT TEST B |
| P0560:17 | System Voltage: Circuit Voltage Above Threshold | The DC to DC converter regulates voltage to the low voltage system. DIAGNOSE other TCM and PCM DTCs first. |
| P0604:42 | Internal Control Module Random Access Memory (RAM) Error: General Memory Failure | This DTC indicates the TCM RAM has been corrupted. REPROGRAM the calibration. CHECK for other DTCs or drive symptoms for further action. If DTC P0604:42 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0605:42 | Internal Control Module Read Only Memory (ROM) Error: General Memory Failure | This DTC indicates the TCM ROM has been corrupted. REPROGRAM the calibration. CHECK for other DTCs or drive symptoms for further action. If DTC P0605:42 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P060A:01 | Internal Control Module Monitoring Processor Performance: General Electrical Failure | This DTC sets if any one of the AC phase currents exceeds 675A for 250 milliseconds. CLEAR the DTC . REPEAT the self-test. If DTC P060A:01 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P060A:02 | Internal Control Module Monitoring Processor Performance: General Signal Failure | This DTC sets if there is an internal resolver issue during a commanded active discharge. CLEAR the DTC . REPEAT the self-test. If DTC P060A:02 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P060A:04 | Internal Control Module Monitoring Processor Performance: System Internal Failure | This DTC sets if the internal current sensor VREF (reference voltage) offset exceeds 5A. CLEAR the DTC . REPEAT the self-test. If DTC P060A:04 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P060B:02 | Internal Control Module A/D Processing Performance: General Signal Failure | This DTC sets if the A/D HV voltage rationality test or inverter enable rationality test fails. CLEAR the DTC . REPEAT the self-test. If DTC P060B:02 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P061B:1D | Internal Control Module Torque Calculation Performance: Circuit Current Out of Range | This DTC sets if the internal current sensor VREF (reference voltage) offset exceeds 5A. CLEAR the DTC . REPEAT the self-test. If DTC P061B:1D returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P061B:1F | Internal Control Module Torque Calculation Performance: Circuit Intermittent | This DTC sets if the TCM fails an internal quadrant and plausibility check. CLEAR the DTC . REPEAT the self-test. If DTC P061B:1F returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P062F:42 | Internal Control Module EEPROM Error: General Memory Failure | This DTC sets if the TCM EEPROM check fails. CLEAR the DTC . REPEAT the self-test. If DTC P062F:42 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0A3F:00 | Drive Motor "A" Position Sensor Circuit | This DTC sets if the TCM detects an internal resolver monitor channel fault. CLEAR the DTC . REPEAT the self-test. If DTC P0A3F:00 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0A3F:01 | Drive Motor "A" Position Sensor Circuit: General Electrical Failure | This DTC sets if the TCM detects an internal resolver signal degradation. CLEAR the DTC . REPEAT the self-test. If DTC P0A3F:01 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0A3F:02 | Drive Motor "A" Position Sensor Circuit: General Signal Failure | This DTC sets if the TCM detects an internal resolver tracking loss. CLEAR the DTC . REPEAT the self-test. If DTC P0A3F:02 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0A3F:08 | Drive Motor "A" Position Sensor Circuit: Bus Signal/Message Failure | This DTC sets if the TCM detects an internal resolver signal failure. CLEAR the DTC . REPEAT the self-test. If DTC P0A3F:08 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0A3F:1F | Drive Motor "A" Position Sensor Circuit: Circuit Intermittent | This DTC sets if the TCM detects an intermittent signal from the internal resolver. CLEAR the DTC . REPEAT the self-test. If DTC P0A3F:1F returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0A78:17 | Drive Motor "A" Inverter Performance: Circuit Voltage Above Threshold | This DTC sets if the TCM detects excessive inverter voltage. CLEAR the DTC . REPEAT the self-test. If DTC P0A78:17 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0A78:49 | Drive Motor "A" Inverter Performance: Internal Electronic Failure | This DTC sets if the TCM inverter fails an internal line switching test. CLEAR the DTC . REPEAT the self-test. If DTC P0A78:49 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0A90:46 | Drive Motor "A" Performance: Calibration/Parameter Memory Failure | This DTC sets if the TCM internal resolver stored offset does not match the actual measured offset. CLEAR the DTC . REPEAT the self-test. If DTC P0A90:46 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0AED:11 | Drive Motor Inverter Temperature Sensor "A" Circuit: Circuit Short To Ground | This DTC sets if the TCM detects an internal temperature sensor signal dropping below 0.3v. CLEAR the DTC . REPEAT the self-test. If DTC P0AED:11 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0AED:15 | Drive Motor Inverter Temperature Sensor "A" Circuit: Circuit Short To Battery or Open | This DTC sets if the TCM detects an internal temperature sensor signal rising above 2.9v when any motor phase exceeds 50A for 30 seconds or 200 amps for 5 seconds. CLEAR the DTC . REPEAT the self-test. If DTC P0AED:15 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0AED:1C | Drive Motor Inverter Temperature Sensor "A" Circuit: Circuit Voltage Out of Range | This DTC sets if the TCM detects an internal temperature sensor signal out of range. CLEAR the DTC . REPEAT the self-test. If DTC P0AED:1C returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0AED:1F | Drive Motor Inverter Temperature Sensor "A" Circuit: Circuit Intermittent | This DTC sets if the TCM detects an intermittent internal temperature sensor signal. CLEAR the DTC . REPEAT the self-test. If DTC P0AED:1F returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0AED:98 | Drive Motor Inverter Temperature Sensor "A" Circuit: Component or System Over Temperature | This DTC sets if the TCM detects excessive internal temperature. CLEAR the DTC . REPEAT the self-test. If DTC P0AED:98 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0AF8:16 | Hybrid/EV Battery System Voltage: Circuit Voltage Below Threshold | This DTC sets if the TCM detects that the high voltage DC (HVDC) system voltage is less than 190v. CLEAR the DTC . REPEAT the self-test. If DTC P0AF8:16 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0AFB:17 | Hybrid/EV Battery System Voltage High: Circuit Voltage Above Threshold | This DTC sets if the TCM detects that the high voltage DC (HVDC) system voltage is greater than 390v. CLEAR the DTC . REPEAT the self-test. If DTC P0AFB:17 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0AFB:1C | Hybrid/EV Battery System Voltage High: Circuit Voltage Out of Range | This DTC sets if the TCM detects that the high voltage DC (HVDC) system voltage is out of range. CLEAR the DTC . REPEAT the self-test. If DTC P0AFB:1C returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0B3D:16 | Hybrid/EV Battery Voltage Sense "A" Circuit Low: Circuit Voltage Below Threshold | This DTC sets if the TCM internal 25v supply voltage drops below 18v. CLEAR the DTC . REPEAT the self-test. If DTC P0B3D:16 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0B3D:1C | Hybrid/EV Battery Voltage Sense "A" Circuit Low: Circuit Voltage Out of Range | This DTC sets if the TCM internal 5v supply voltage drops below 4.5v. CLEAR the DTC . REPEAT the self-test. If DTC P0B3D:1C returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0B3D:1F | Hybrid/EV Battery Voltage Sense "A" Circuit Low: Circuit Intermittent | This DTC sets if the TCM internal 0.5 volt sensor is operating intermittently. CLEAR the DTC . REPEAT the self-test. If DTC P0B3D:1F returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0B3E:17 | Hybrid/EV Battery Voltage Sense "A" Circuit High: Circuit Voltage Above Threshold | This DTC sets if the TCM internal 25v supply voltage rises above 26.25v. CLEAR the DTC . REPEAT the self-test. If DTC P0B3E:17 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0B3E:1C | Hybrid/EV Battery Voltage Sense "A" Circuit High: Circuit Voltage Out of Range | This DTC sets if the TCM internal 5v supply voltage rises above 5.5v. CLEAR the DTC . REPEAT the self-test. If DTC P0B3E:1C returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0B3E:1F | Hybrid/EV Battery Voltage Sense "A" Circuit High: Circuit Intermittent | This DTC sets if the TCM internal 1.5 volt sensor is operating intermittently. CLEAR the DTC . REPEAT the self-test. If DTC P0B3D:1F returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0BFD:1D | Drive Motor "A" Phase U-V-W Current Sensor Correlation: Circuit Current Out of Range | This DTC sets if the TCM internal phase current sensors do not correlate. CLEAR the DTC . REPEAT the self-test. If DTC P0BFD:1D returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0BFD:1F | Drive Motor "A" Phase U-V-W Current Sensor Correlation: Circuit Intermittent | This DTC sets if the TCM internal phase current sensors do not correlate. CLEAR the DTC . REPEAT the self-test. If DTC P0BFD:1F returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0C05:1D | Drive Motor "A" Phase U-V-W Circuit/Open: Circuit Current Out of Range | This DTC sets if the TCM detects an open motor phase. CLEAR the DTC . REPEAT the self-test. If DTC P0C05:1D returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0C07:19 | Drive Motor "A" Phase U-V-W Circuit High: Circuit Current Above Threshold | This DTC sets if the TCM detects any motor phase current exceeding 650A. CLEAR the DTC . REPEAT the self-test. If DTC P0C07:19 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0CBC:11 | Drive Motor "A" Coolant Temperature Sensor Circuit: Circuit Short To Ground | This DTC sets if the TCM detects less than 0.15v on either motor coolant sensor signal circuit. CLEAR the DTC . REPEAT the self-test. If DTC P0CBC:11 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0CBC:15 | Drive Motor "A" Coolant Temperature Sensor Circuit: Circuit Short To Battery or Open | This DTC sets if the TCM detects more than 2.97v on either motor coolant sensor signal circuit. CLEAR the DTC . REPEAT the self-test. If DTC P0CBC:15 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P0CBD:17 | Drive Motor "A" Coolant Temperature Sensor Circuit Range/Performance: Circuit Voltage Above Threshold | This DTC sets if the TCM detects more than 155°C on either motor coolant sensor signal circuit. CLEAR the DTC . REPEAT the self-test. If DTC P0CBD:17 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P1601:02 | ECM/TCM Serial Communication Error: General Signal Failure | This DTC sets if the TCM fails the PCM rationalit check. CLEAR the DTC . REPEAT the self-test. If DTC P1601:02 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P1608:1F | Watchdog Malfunction: Circuit Intermittent | This DTC sets if the TCM indicates a watchdog failure. CLEAR the DTC . REPEAT the self-test. If DTC P1608:1F returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P1627:01 | Module Supply Voltage Out Of Range: General Electrical Failure | This DTC sets if the TCM internal VREF (reference voltage) drops below or exceeds a calibrated value. CLEAR the DTC . REPEAT the self-test. If DTC P1627:01 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P1627:02 | Module Supply Voltage Out Of Range: General Signal Failure | This DTC sets if the TCM internal VREF (reference voltage drops below or exceeds a calibrated value. CLEAR the DTC . REPEAT the self-test. If DTC P1627:02 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P1627:1C | Module Supply Voltage Out Of Range: Circuit Voltage Out of Range | This DTC sets if the TCM internal VREF (reference voltage) drops below or exceeds a calibrated value. CLEAR the DTC . REPEAT the self-test. If DTC P1627:1C returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| P1A0A:01 | Immediate Shutdown Signal A: General Electrical Failure | GO to PINPOINT TEST A |
| P1A0A:17 | Immediate Shutdown Signal A: Circuit Voltage Above Threshold | GO to PINPOINT TEST A |
| P1A0A:18 | Immediate Shutdown Signal A: Circuit Current Below Threshold | GO to PINPOINT TEST A |
| P1A0A:29 | Immediate Shutdown Signal A: Signal Invalid | GO to PINPOINT TEST A |
| B10D6:51 | PATS Enable Status: Not Programmed | This DTC sets if the TCM indicates the PATS configuration is incomplete. CLEAR the DTC . REPEAT the self-test. If DTC B10D6:51 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| U0100:00 | Lost Communication With ECM/PCM "A" | REFER to: COMMUNICATIONS NETWORK . |
| U0111:00 | Lost Communication With Battery Energy Control Module "A" | REFER to: COMMUNICATIONS NETWORK . |
| U0121:00 | Lost Communication With Anti-Lock Brake System (ABS) Control Module | REFER to: COMMUNICATIONS NETWORK . |
| U0140:00 | Lost Communication With Body Control Module | REFER to: COMMUNICATIONS NETWORK . |
| U0298:00 | Lost Communication With DC to DC Converter Control Module "A" | REFER to: COMMUNICATIONS NETWORK . |
| U0300:00 | Internal Control Module Software Incompatibility | This DTC sets if the TCM fails an internal software components compatibility check. CLEAR the DTC . REPEAT the self-test. If DTC U0300:00 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
| U0401:00 | Invalid Data Received from ECM/PCM A | REFER to: COMMUNICATIONS NETWORK . |
| U0418:00 | Invalid Data Received From Brake System Control Module | REFER to: COMMUNICATIONS NETWORK . |
| U0422:00 | Invalid Data Received From Body Control Module | REFER to: COMMUNICATIONS NETWORK . |
| U0426:00 | Invalid Data Received From Vehicle Immobilizer Control Module | Diagnose all non-network DTCs set in the BCM or RFA module. For BCM REFER to: BODY CONTROL MODULE (BCM) . For RFA REFER to: REMOTE FUNCTION ACTUATOR (RFA) MODULE . |
| U1012:00 | Invalid Internal Control Module Monitoring Data Received from Anti-Lock Brake System (ABS) Control Module | REFER to: COMMUNICATIONS NETWORK . |
| U1A14:09 | CAN Initialization Failure: Component Failure | This DTC sets if the TCM fails to initialize its internal CAN hardware. CLEAR the DTC . REPEAT the self-test. If DTC U1A14:09 returns, INSTALL a new TCM . REFER to: ELECTRIC MOTOR . |
Diagnostic Routine(s)
Diagnostics in this service information assume a certain skill level and knowledge of Ford-specific diagnostic practices. Refer to DIAGNOSTIC METHODS for information about these practices.
P1A0A:01 P1A0A:17 P1A0A:18 P1A0A:29
Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.
Normal Operation and Fault Conditions
The TCM receives any immediate shutdown messages from the PCM by way of a dedicated PCM shutoff circuit. The TCM monitors the PCM shutoff circuit and sets the appropriate DTC if a fault is detected.
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| P1A0A:01 | Immediate Shutdown Signal A: General Electrical Failure | This DTC sets if the TCM detects that the PCM has initiated an immediate shutdown. |
| P1A0A:17 | Immediate Shutdown Signal A: Circuit Voltage Above Threshold | This DTC sets if the TCM detects that the PCM shutoff signal is greater than 1.18v. |
| P1A0A:18 | Immediate Shutdown Signal A: Circuit Current Below Threshold | This DTC sets if the TCM detects that the PCM shutoff signal is less than 0.63v. |
| P1A0A:29 | Immediate Shutdown Signal A: Signal Invalid | This DTC sets if the TCM detects that the PCM shutoff signal is not within a specified range. |
DTC FAULT TRIGGER CONDITIONS
PINPOINT TEST A
- A1 RETRIEVE THE RECORDED DTCS FROM THE TCM SELF-TEST Using a scan tool, carry out the TCM self-test. Are DTCs P1A0A:01, P1A0A:17, P1A0A:18, or P1A0A:29 present? Yes : GO to A2 No : The system is operating normally at this time.
- A2 CHECK THE PCM SHUTOFF CIRCUIT FOR AN OPEN Ignition OFF Disconnect C1822A. Disconnect C175B. Measure: Positive Lead Measurement/Action Negative Lead C1822A-3 C175B-58 Is the resistance less than 3 ohms? Yes : GO to A3 No : REPAIR the circuit.
- A3 CHECK THE PCM SHUTOFF CIRCUIT FOR A SHORT TO GROUND Measure: Positive Lead Measurement/Action Negative Lead C1822A-3 Ground Is the resistance greater than 10, 000 ohms? Yes : GO to A4 No : REPAIR the circuit.
- A4 CHECK THE PCM SHUTOFF CIRCUIT FOR A SHORT TO VOLTAGE Ignition ON Measure: Positive Lead Measurement/Action Negative Lead C1822A-3 Ground Is any voltage present? Yes : REPAIR the circuit. No : GO to A5
- A5 CHECK FOR CORRECT TCM OPERATION Ignition OFF Inspect the TCM connector. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the TCM connector. Make sure it seats and latches correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes : CHECK OASIS for any applicable TSBs. If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no TSBs address this concern, INSTALL a new TCM . REFER to: «ELECTRIC MOTOR»(/ford/focus-st/iii-2012-2015/remont/mechanical/#electric-motor) . No : The system is operating correctly at this time. The concern may have been caused by module connections. Address the root cause of any connector or pin issues.
P0560:16
Refer to SYSTEM WIRING DIAGRAMS for schematic and connector information.
The TCM monitors the low voltage system and sets a DTC if the system voltage falls below or exceeds a calibrated limit.
| DTC | Description | Fault Trigger Conditions |
|---|---|---|
| P0560:16 | System Voltage: Circuit Voltage Below Threshold | This DTC sets when the TCM has detected that the 12V battery voltage has fallen below normal operating range. |
DTC FAULT TRIGGER CONDITIONS
Possible Sources
- Voltage to TCM concern
- TCM ground concern
PINPOINT TEST B
- B1 CHECK FOR SELF-TEST DTCS Using a scan tool, carry out the TCM self-test. Is DTC P0560:16 present? Yes : GO to B2 No : Unable to duplicate or identify the concern at this time.
- B2 CHECK FOR ANY OTHER TCM AND PCM DTCS Using a scan tool, carry out the TCM and PCM self-test. Are any other DTCs received from the TCM or PCM self-tests? Yes : DISREGARD the current DTC at this time. DIAGNOSE the next DTC. No : GO to B3
- B3 CHECK THE B+ CIRCUITS FOR VOLTAGE Disconnect C1822A. Ignition ON Measure: Positive Lead Measurement/Action Negative Lead C1822A-15 C1822A-10 C1822A-16 C1822A-11 Are the voltages greater than 10 V? Yes : GO to B5 No : GO to B4
- B4 CHECK THE VOLTAGE TO THE TCM USING GROUND AS A REFERENCE Measure: Positive Lead Measurement/Action Negative Lead C1822A-15 Ground C1822A-16 Ground Are the voltages greater than 10 V? Yes : CHECK the ground to C1822A for corrosion or loose wires. REPAIR as necessary. No : REPAIR the open circuit.
- B5 CHECK THE TCM POWER AND GROUND CIRCUIT(S) FOR INTERMITTENT CONCERNS Ignition OFF Connect a non-powered test lamp between: Positive Lead Measurement/Action Negative Lead C1822A-15 C1822A-10 C1822A-16 C1822A-11 Ignition ON Observe the test lamp for a sudden illumination of the test lamp, indicating a concern, while completing the following: Shake, wiggle, and bend the B+ and GND circuit(s). Visually inspect the TCM and harness connectors for damage and corrosion. Is a concern present? Yes : ISOLATE the concern and REPAIR as necessary. No : GO to B6
- B6 CHECK FOR SELF-TEST DTCS Ignition OFF Connect C1822A. Clear the TCM DTCs. Using a scan tool, carry out the TCM self-test. Is DTC P0560:16 present during the TCM self-test? Yes : INSTALL a new TCM . REFER to: «ELECTRIC MOTOR»(/ford/focus-st/iii-2012-2015/remont/mechanical/#electric-motor) . No : Unable to duplicate or identify the concern at this time. The DC to DC Converter Control Module (DC/DC) regulates voltage to the low voltage system. CHECK the wiring and the appropriate fuse.
Transmission Fluid Drain and Refill
Special Tool(s)/General Equipment
| Name | Specification |
|---|---|
| Motorcraft® MERCON® LV Automatic Transmission Fluid XT-10-QLVC | WSS-M2C938-A MERCON® LV |
MATERIALS SPECIFICATIONS
Scheme 126
- Refer to: «JACKING AND LIFTING - OVERVIEW»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#jacking-lifting-electric) .
- If equipped.
Scheme 127
- General Equipment : Material : Motorcraft® MERCON® LV Automatic Transmission Fluid/XT-10-QLVC (WSS-M2C938-A) (MERCON® LV)
- Torque : 35 Nm
- If equipped.
Halfshaft Seal LH
SPECIAL TOOL(S)/GENERAL EQUIPMENT 205-115 Installer, Drive Pinion Seal TKIT-2000-F/FM/FLM Flat Headed Screw Driver Rubber Mallet
Scheme 128
Scheme 129
- Refer to: «FRONT HALFSHAFT LH»(/ford/focus-st/iii-2012-2015/remont/axle-shafts/#front-drive-halfshafts-electric__front-halfshaft-lh) .
- General Equipment : Flat Headed Screw Driver
Installation
Pinpoint Test B
- click to open the image
- General Equipment : Rubber Mallet
- click to open the image
Halfshaft Seal RH
SPECIAL TOOL(S)/GENERAL EQUIPMENT 205-115 Installer, Drive Pinion Seal TKIT-2000-F/FM/FLM Flat Headed Screw Driver Plastic Mallet
Scheme 130
- Refer to: «FRONT HALFSHAFT RH»(/ford/focus-st/iii-2012-2015/remont/axle-shafts/#front-drive-halfshafts-electric__front-halfshaft-rh) .
- General Equipment : Flat Headed Screw Driver
Pinpoint Test B
- click to open the image
- General Equipment : Plastic Mallet
- click to open the image
Scheme 131
Scheme 132
- Refer to: «JACKING AND LIFTING - OVERVIEW»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#jacking-lifting-electric) .
- If equipped.
Scheme 133
- Torque : 145 Nm Torque : 125 Nm
- Torque : 80 Nm
- If equipped.
Removal
- Refer to: «ELECTRIC MOTOR»(/ford/focus-st/iii-2012-2015/remont/mechanical/#electric-motor) .
- Refer to: «ELECTRIC MOTOR»(/ford/focus-st/iii-2012-2015/remont/mechanical/#electric-motor) .
- Refer to: «TRANSMISSION FLUID DRAIN AND REFILL»(/ford/focus-st/iii-2012-2015/remont/automatic-trans/#automatic-transaxle-electric__transmission-fluid-drain-and-refill) .
Scheme 134
Scheme 135
Scheme 136
Scheme 137
Scheme 138
Scheme 139
- NOTE: The O-ring seal is to be reused unless damaged.
- Torque : 8 Nm
- Torque : 8 Nm
Scheme 140
Scheme 141
Scheme 142
Scheme 143
Scheme 144
Scheme 145
- Refer to: «BATTERY DISCONNECT AND CONNECT»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#battery-mounting-cables-electric) .
- Refer to: «HIGH VOLTAGE BATTERY DISCONNECT AND CONNECT»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#high-voltage-battery-mounting-cables-electric) .
- NOTE: Use an antistatic wrist strap grounded to the vehicle when performing this procedure.
- NOTE: The gasket is to be reused unless damaged.
- NOTE: Note the position of the component before removal. Cabin coolant heater Air conditioning compressor Direct current/direct current converter control module
Scheme 146
Scheme 147
Scheme 148
Scheme 149
Scheme 150
- NOTE: Make sure that the components are installed to the position noted before removal. Cabin coolant heater Air conditioning compressor Direct current/direct current converter control module
- Torque : 4 Nm
- NOTE: Make sure that new components are installed.
- NOTE: Make sure that new components are installed. Torque : 4 Nm
- Refer to: «HIGH VOLTAGE BATTERY DISCONNECT AND CONNECT»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#high-voltage-battery-mounting-cables-electric) .
- Refer to: «BATTERY DISCONNECT AND CONNECT»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#battery-mounting-cables-electric) .
Transmission Support Insulator
| Trolley Jack |
|---|
| Wooden Block |
SPECIAL TOOL(S)/GENERAL EQUIPMENT
Scheme 151
Scheme 152
Scheme 153
- Refer to: «BATTERY TRAY»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#battery-mounting-cables-electric) .
- Refer to: «JACKING AND LIFTING - OVERVIEW»(/ford/focus-st/iii-2012-2015/remont/oem-general-information/#jacking-lifting-electric) .
- If equipped.
- General Equipment : Trolley Jack General Equipment : Wooden Block
Scheme 154
- Torque : 148 Nm
- Torque : 48 Nm
- If equipped.
- Refer to: «BATTERY TRAY»(/ford/focus-st/iii-2012-2015/remont/body-electrical/#battery-mounting-cables-electric) .
Transmission
SPECIAL TOOL(S)/GENERAL EQUIPMENT 100-D112 Slider Hammer Master Set 205-115 Installer, Drive Pinion Seal TKIT-2000-F/FM/FLM 205-153 (T80T-4000-W) Handle 303-D012 (D80L-100-H) Actuator Pin 303-D022 (D80L-100-T) Collet, 1 1/4 to 1 1/2 307-626 Installer, Differential Seal TKIT-2008ET-FLM TKIT-2008ET-ROW
Scheme 155
Scheme 156
Scheme 157
| Name | Specification |
|---|---|
| Ultra Silicone Sealant TA-29 |
MATERIALS SPECIFICATIONS
DISASSEMBLY
Pinpoint Test B
- click to open the image
ASSEMBLY
Pinpoint Test B
- Special Tool(s) : 205-153 (T80T-4000-W) Handle , 307-626 Installer, Differential Seal
- click to open the image
- click to open the image
- Special Tool(s) : 205-115 Installer, Drive Pinion Seal
- click to open the image
- Special Tool(s) : 205-115 Installer, Drive Pinion Seal
- click to open the image
See also:
• DIAGNOSTIC METHODS
• ELECTRIC MOTOR
• COMMUNICATIONS NETWORK
• BODY CONTROL MODULE (BCM)
• JACKING AND LIFTING - OVERVIEW
• FRONT HALFSHAFT LH
• FRONT HALFSHAFT RH
• BATTERY DISCONNECT AND CONNECT
• HIGH VOLTAGE BATTERY DISCONNECT AND CONNECT
• PINPOINT TEST B
• PINPOINT TEST A
• TRANSMISSION FLUID DRAIN AND REFILL
