Removal and Installation
Pinpoint Test I
I1
PAM
- NOTE: Module configuration is required when a new Parking Aid Module (PAM) is being installed.
- Upload the PAM configuration information to the scan tool. For additional information, refer to Programmable Module Installation (PMI) in «MODULE CONFIGURATION»(ref-372774) .
I4
PAM
I5
PAM
- Remove the rear bumper cover. For additional information, Refer to «BUMPERS»(ref-372811) .
- Using a suitable tool, (such as a flat-bladed screwdriver), gently pry the retaining tabs and remove the parking aid sensor(s). Disconnect the electrical connectors.
- To install, reverse the removal procedure. Using the scan tool, verify that the parking aid sensor PIDs read no object present.
Scheme 41
| Item | Part Number | Description |
|---|---|---|
| 1 | 7842528 | Ford oval emblem (adhesive sticker part of the Ford oval) |
| 2 | W505426 | Ford oval emblem bezel bolts (3 required) |
PARTS DESCRIPTION CHART
Scheme 42
| Item | Part Number | Description |
|---|---|---|
| 1 | Video camera cover | |
| 2 | Ford oval emblem bezel | |
| 3 | 19G490 | Video camera |
| 4 | Video camera electrical connector | |
| 5 | Video camera cover screws (2 required) |
PARTS DESCRIPTION CHART
- Remove the liftgate trim panel. For additional information, Refer to «HANDLES, LOCKS, LATCHES AND ENTRY SYSTEMS»(ref-372789) .
- Remove the Ford oval emblem by carefully prying the emblem away from the emblem bezel with a suitable pry tool.
- Remove the 3 Ford oval emblem bezel bolts.
- Remove the Ford emblem bezel from the tailgate. Disconnect the electrical connector.
- Remove the video camera cover.
- Remove the video camera.
- To install, reverse the removal procedure.
