Parking Aid System: Component Locations Ford Flex I

Warning System 4 illustrations ~107 words

Special Tool(s)

SPECIAL TOOLS DESCRIPTION CHART Fluke 77-IV Digital Multimeter FLU77-4 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool Flex Probe Kit 300-NUD105-R025DE or equivalent

Scheme 43

Scheme 43: Special Tool(s)
Scheme 43: Special Tool(s)

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

SPECIAL TOOLS DESCRIPTION CHART Fluke 77-IV Digital Multimeter FLU77-4 or equivalent Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool Flex Probe Kit 300-NUD105-R025DE or equivalent

SPECIAL TOOL DESCRIPTION CHART Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool

Scheme 46

Scheme 46: Special Tool(s)
Scheme 46: Special Tool(s)
ItemPart NumberDescription
1Parking aid sensor electrical connectors (part of 14N139)
215K859Parking aid sensors (4 required)
3Parking aid sensor bezel

PARTS DESCRIPTION CHART
