MATERIAL SPECIFICATIONS
| Item | Specification | Fill Capacity |
|---|---|---|
| High Temperature Nickel Anti-Seize Lubricant XL-2 | ESE-M12A4-A | |
| Silicone Brake Caliper Grease and Dielectric Compound XG-3-A | ESE-M1C171-A |
MATERIAL SPECIFICATIONS
TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Lower arm forward bolt | 185 |
| Lower arm rearward nuts | 99 |
| Lower ball joint nut | 200 |
| Stabilizer bar bracket bolts | 55 |
| Stabilizer bar link nuts | 150 |
| Steering gear nuts and bolts Electronic Power Assist Steering (EPAS) | 165 |
| Steering gear nuts and bolts Hydraulic Power Assist Steering (HPAS) | 117 |
| Strut rod nut | 133 |
| Strut-to-wheel knuckle nut | 175 |
| Subframe bracket bolts | 55 |
| Subframe forward bolts | 200 |
| Subframe rearward bolts EPAS | 150 |
| Subframe rearward bolts HPAS | 175 |
| Tie-rod end nut | 150 |
| Upper strut mount nuts | 30 |
| Wheel bearing and wheel hub bolts a | |
| Wheel hub nut a | |
| Wheel speed sensor bolt | 15 |
TORQUE SPECIFICATIONS
Refer to the appropriate procedure(s).
The front suspension consists of the following components
- Wheel bearing and wheel hubs
- Wheel studs
- Lower arms
- Stabilizer bar
- Stabilizer bar links
- Struts
- Springs
- Wheel knuckles
The front suspension utilizes a MacPherson strut system.
This suspension system incorporates a strut assembly that takes the place of the upper arm and ball joint. The strut carries out the function of a shock absorber and is encompassed by a coil spring. The strut and spring assembly supports the weight of the vehicle and is also the pivot point for the steering knuckle. This system uses a lower control arm and ball joint for the lower (unloaded) pivot point of the steering knuckle.
Refer to SUSPENSION SYSTEM - GENERAL INFORMATION .
Scheme 20
| Item | Part Number | Description |
|---|---|---|
| 1 | W705967 | Wheel hub nut |
| 2 | 2C300 | Wheel bearing and wheel hub |
| 3 | 1107 | Wheel stud (also part of 1104) (5 required) |
| 4 | 3K171 LH/3K170 RH | Wheel knuckle |
| 5 | W710015 | Tie-rod end nut |
| 6 | W714331 | Wheel bearing and wheel hub bolt (4 required) |
| 7 | W520215 | Strut-to-wheel knuckle nut |
| 8 | W710396 | Strut-to-wheel knuckle flag bolt |
| 9 | 3051 | LH/3042 RH Lower control arm |
| 10 | W714890 | Lower ball joint nut |
| 11 | W710174 | Lower arm forward bolt |
| 12 | W520515 | Lower arm rearward nuts (2 required) |
| 13 | W708848 | Lower arm rearward bolt (2 required) |
| 14 | 3C339 LH/3C403 RH | Lower arm rearward bushing |
PARTS DESCRIPTION CHART
Scheme 21
| Item | Part Number | Description |
|---|---|---|
| 1 | W713968 | Stabilizer bar link upper nut |
| 2 | 5B421 | LH/5B420 RH Strut and spring assembly |
| 3 | W520215 | Strut-to-wheel knuckle nut |
| 4 | W714812 | Strut upper mount nut (4 required) |
| 5 | W710396 | Strut-to-wheel knuckle flag bolt |
| 6 | 3B439 | LH/3B438 RH Stabilizer bar link |
PARTS DESCRIPTION CHART
Scheme 22
| Item | Part Number | Description |
|---|---|---|
| 1 | W505274 | Stabilizer bar bracket bolts (4 required) |
| 2 | W520215 | Stabilizer bar link lower nut (2 required) |
| 3 | W713968 | Stabilizer bar link upper nut (2 required) |
| 4 | 5482 | Stabilizer bar assembly |
| 5 | 3B439 | LH/3B438 RH Stabilizer bar link (2 required) |
PARTS DESCRIPTION CHART
- For additional information, refer to the appropriate procedure(s).
