PCV System
Note. Do not permanently remove or render inoperative any part of the vehicle emission control system including related hardware. Failure to comply may violate applicable state and federal law. The engine emission control system consists of the PCV system.
The PCV system
- uses intake manifold vacuum to ventilate blow-by vapors from the crankcase.
- returns the vapors to the intake manifold for combustion.
The PCV system consists of the
- crankcase ventilation tube.
- PCV valve.
The crankcase ventilation tube
- is connected to the PCV valve and the intake manifold fitting with a spring clamp on the manifold end.
The PCV valve
- varies the amount of blow-by vapors returned to the intake manifold based on available engine vacuum.
- threads into the RH valve cover.
Scheme 33
| Item | Part Number | Description |
|---|---|---|
| 1 | 6A505 | LH valve cover |
| 2 | 9F805 | Air Cleaner (ACL) outlet tube |
| 3 | 9G641 | Evaporative Emission (EVAP) canister purge valve |
| 4 | 9S455 | Upper intake manifold |
| 5 | 6A666 | PCV valve |
| 6 | 6582 | RH valve cover |
| 7 | 9E857 | EVAP canister |
| 8 | Fuel vapor vent valve (part of 9002) | |
| 9 | Fuel vapor vent valve (part of 9002) | |
| 10 | 9034 | Fuel tank filler pipe |
| 11 | 9002 | Fuel tank |
| 12 | Fuel Tank Pressure (FTP) sensor (part of 9C047) | |
| 13 | 9275 | Fuel level sender |
PARTS DESCRIPTION CHART
Note. Do not permanently remove or render inoperative any part of the vehicle emission control system including related hardware. Failure to comply may violate applicable state and federal law.
The engine emission control system consists of the PCV system.
The PCV system
- uses intake manifold vacuum to ventilate blow-by vapors from the crankcase.
- returns the vapors to the intake manifold for combustion.
The PCV system consists of the
- crankcase vent oil separator
- crankcase ventilation tube.
- PCV heater element (early build only).
- PCV valve.
The crankcase vent oil separator
- is retained by 3 bolts, mounted to the RH valve cover.
The crankcase ventilation tube
- is connected to the PCV valve and the PCV heater element with a quick connect coupling at each end.
The PCV valve
- varies the amount of blow-by vapors returned to the intake manifold based on available engine vacuum.
- utilizes an electronic internal heater (early build only).
- threads into the crankcase vent oil separator, mounted on the RH valve cover.
The PCV heater element (early build only)
- heats the ventilating air and blow-by vapors going to the intake manifold.
- is retained by 2 screws, mounted to the intake manifold.
Scheme 34
| Item | Part Number | Description |
|---|---|---|
| 1 | 6A505 | LH valve cover |
| 2 | 9R530 | Air Cleaner (ACL) outlet tube |
| 3 | 9G271 | Evaporative Emission (EVAP) canister purge valve |
| 4 | 9S455 | Upper intake manifold |
| 5 | 6A666 | PCV valve |
| 6 | 6A485 | Crankcase vent oil separator |
| 7 | 6582 | RH valve cover |
| 8 | 9E857 | EVAP canister |
| 9 | Fuel vapor vent valve (part of 9002) | |
| 10 | Fuel vapor vent valve (part of 9002) | |
| 11 | 9034 | Fuel tank filler pipe assembly |
| 12 | 9002 | Fuel tank |
| 13 | Fuel Tank Pressure (FTP) sensor (part of 9C047) | |
| 14 | 9275 | Fuel level sender |
PARTS DESCRIPTION CHART
Refer to the INTRODUCTION - GASOLINE MODELS .
Material
| Item | Specification |
|---|---|
| Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP (US); Motorcraft® SAE 5W-20 Super Premium Motor Oil CXO-5W20-LSP12 (Canada); or equivalent | WSS-M2C930-A |
MATERIAL SPECIFICATIONS
Scheme 35
| Item | Part Number | Description |
|---|---|---|
| 1 | Crankcase ventilation tube spring clamp (part of 6K817) | |
| 2 | 6K817 | Crankcase ventilation tube |
| 3 | 6A666 | PCV valve |
| 4 | PCV valve O-ring seal (part of 6A666) |
PARTS DESCRIPTION CHART
| Item | Specification |
|---|---|
| Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP (US); Motorcraft® SAE 5W-20 Super Premium Motor Oil CXO-5W20-LSP12 (Canada); or equivalent | WSS-M2C930-A |
MATERIAL SPECIFICATIONS
Note. Early build engine with PCV heater element and electric heated PCV valve shown in illustration, late build engine without PCV heater element and standard PCV valve similar.
Scheme 36
| Item | Part Number | Description |
|---|---|---|
| 1 | 6A666 | PCV valve |
| 2 | 14A464 | PCV valve electrical connector (early build only) |
| 3 | Crankcase ventilation tube-to-PCV valve quick connect coupling (part of 6C658) | |
| 4 | 6C658 | Crankcase ventilation tube |
| 5 | 6A485 | Crankcase vent oil separator |
PARTS DESCRIPTION CHART
| Item | Specification |
|---|---|
| Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP (US); Motorcraft® SAE 5W-20 Super Premium Motor Oil CXO-5W20-LSP12 (Canada); or equivalent | WSS-M2C930-A |
MATERIAL SPECIFICATIONS
Scheme 37
| Item | Part Number | Description |
|---|---|---|
| 1 | W503276 | PCV heater element bolt (2 required) |
| 2 | 9F624 | PCV heater element |
| 3 | 9L479 | PCV heater element O-ring seal |
| 4 | 14A464 | PCV heater element electrical connector |
| 5 | 9S455 | Intake manifold |
| 6 | 6C658 | Crankcase ventilation tube |
| 7 | Crankcase ventilation tube-to-PCV heater element quick connect coupling (part of 6C658) |
PARTS DESCRIPTION CHART
Crankcase Vent Oil Separator - 3.5L GTDI
Note. Early build engine with PCV heater element and electric heated PCV valve shown in illustration, late build engine without PCV heater element and standard PCV valve similar.
Scheme 38
| Item | Part Number | Description |
|---|---|---|
| 1 | 6C658 | Crankcase ventilation tube |
| 2 | Crankcase ventilation tube-to-PCV valve quick connect coupling (part of 6C658) | |
| 3 | 14A464 | PCV valve electrical connector (early build only) |
| 4 | 6A485 | Crankcase vent oil separator |
| 5 | 14A163 | Wire harness pin-type retainer |
| 6 | W701775 | Crankcase vent oil separator bolt (3 required) |
| 7 | 6582 | RH valve cover |
PARTS DESCRIPTION CHART
