Engine Controls - Electronic Engine Controls: Other Ford Flex I

Removal & Installation 6 illustrations ~204 words

Material

ItemSpecification
Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP (US); Motorcraft® SAE 5W-20 Super Premium Motor Oil CXO-5W20-LSP12 (Canada); or equivalentWSS-M2C930-A

MATERIAL SPECIFICATIONS

Scheme 27

Scheme 27
Scheme 27
ItemPart NumberDescription
114A464RH Camshaft Position (CMP) sensor electrical connector
2W503279RH CMP sensor bolt
36B288RH CMP sensor
414A464LH CMP sensor electrical connector
5W503279LH CMP sensor bolt
66B288LH CMP sensor

PARTS DESCRIPTION CHART

ItemSpecification
Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP (US); Motorcraft® SAE 5W-20 Super Premium Motor Oil CXO-5W20-LSP12 (Canada); or equivalentWSS-M2C930-A

MATERIAL SPECIFICATIONS

Note. Lower radiator hose removed for clarity.

Scheme 28

Scheme 28
Scheme 28
ItemPart NumberDescription
114A464RH Camshaft Position (CMP) sensor electrical connector
2W503275RH CMP sensor bolt
36B288RH CMP sensor
414A464LH CMP sensor electrical connector
5W503275LH CMP sensor bolt
66B288LH CMP sensor

PARTS DESCRIPTION CHART

Both sensors

  1. Remove the Air Cleaner (ACL) outlet pipe and the ACL. For additional information, Refer to «INTAKE AIR DISTRIBUTION & FILTERING»(ref-372794) . RH sensor
  2. Position the RH turbocharger intake tube aside. For additional information, refer to Intake Air System Components - Exploded View in «INTAKE AIR DISTRIBUTION & FILTERING»(ref-372794) . LH sensor
  3. Position the LH turbocharger intake tube aside. For additional information, refer to Intake Air System Components - Exploded View in «INTAKE AIR DISTRIBUTION & FILTERING»(ref-372794) . Both sensors
  4. Disconnect the Camshaft Position (CMP) sensor electrical connector.
  5. Remove the bolt and the CMP sensor. To install, tighten to 10 Nm (89 lb-in).
  6. NOTE: Lubricate the CMP sensor O-ring seal with clean engine oil. To install, reverse the removal procedure.
ItemSpecification
High Temperature Nickel Anti-Seize Lubricant XL-2ESE-M12A4-A
Penetrating and Lock Lubricant (US); Penetrating Fluid (Canada) XL-1 (US); CXC-51-A (Canada)

MATERIAL SPECIFICATIONS

ItemSpecification
High Temperature Nickel Anti-Seize Lubricant XL-2ESE-M12A4-A
Penetrating and Lock Lubricant (US); Penetrating Fluid (Canada) XL-1 (US); CXC-51-A (Canada)

MATERIAL SPECIFICATIONS

ItemSpecification
Motorcraft® Specialty Green Engine Coolant VC-10-A2 (US); CVC-10-A (Canada)WSS-M97B55-A

MATERIAL SPECIFICATIONS

Note. LH cylinder head removed from art for clarity.

Scheme 29

Scheme 29
Scheme 29
ItemPart NumberDescription
19N271Coolant tube
28565O-ring seal
314A464Knock Sensor (KS) electrical connector
4W704749KS bolts
512A699KS

PARTS DESCRIPTION CHART

Knock Sensor (KS) - 3.5L GTDI

Note. LH cylinder head removed from art for clarity.

Scheme 30

Scheme 30: Knock Sensor (KS) - 3.5L GTDI
Scheme 30: Knock Sensor (KS) - 3.5L GTDI
ItemPart NumberDescription
114A464Knock Sensor (KS) electrical connector
2W704749KS bolts
312A699KS

PARTS DESCRIPTION CHART

ItemSpecification
Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP (US); Motorcraft® SAE 5W-20 Super Premium Motor Oil CXO-5W20-LSP12 (Canada); or equivalentWSS-M2C930-A

MATERIAL SPECIFICATIONS

Scheme 31

Scheme 31
Scheme 31
ItemPart NumberDescription
114A464Turbocharger Boost Pressure (TCBP)/Charge Air Cooler Temperature (CACT) sensor electrical connector
29F479TCBP / CACT sensor
3W506843TCBP / CACT sensor screws

PARTS DESCRIPTION CHART

ItemSpecification
Motorcraft® SAE 5W-20 Premium Synthetic Blend Motor Oil XO-5W20-QSP (US); Motorcraft® SAE 5W-20 Super Premium Motor Oil CXO-5W20-LSP12 (Canada); or equivalentWSS-M2C930-A

MATERIAL SPECIFICATIONS

Scheme 32

Scheme 32
Scheme 32
ItemPart NumberDescription
1W505565Manifold Absolute Pressure (MAP)/Intake Air Temperature 2 (IAT2) sensor screws
29F479MAP/IAT2 sensor
314A464MAP/IAT2 sensor electrical connector

PARTS DESCRIPTION CHART
