Speaker System Ford Five Hundred I

Entertainment Systems 4 illustrations ~175 words

Speakers

Scheme 41

Scheme 41: Door Speaker
Scheme 41: Door Speaker

Removal and Installation

  1. Remove the door trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/five-hundred/i-2004-2007/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
  2. Remove the 4 screws and the door speaker. Disconnect the electrical connector.
  3. To install, reverse the removal procedure.

Scheme 42

Scheme 42: Parcel Shelf Speaker
Scheme 42: Parcel Shelf Speaker
  1. Remove the parcel shelf. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/five-hundred/i-2004-2007/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
  2. Remove the 4 screws and the parcel shelf speaker. Disconnect the electrical connector.
  3. To install, reverse the removal procedure.

Scheme 43

Scheme 43: Subwoofer Speaker
Scheme 43: Subwoofer Speaker
  1. Remove the RH rear quarter trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/five-hundred/i-2004-2007/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
  2. Remove the speaker cushion.
  3. Remove the 4 screws and the subwoofer speaker. Disconnect the electrical connector.
  4. To install, reverse the removal procedure.

Scheme 44

Scheme 44: Speaker Enclosure
Scheme 44: Speaker Enclosure
  1. Remove the RH rear quarter trim panel. For additional information, refer to «INTERIOR TRIM AND ORNAMENTATION»(/ford/five-hundred/i-2004-2007/remont/exteriorinterior-trim/#interior-trim-and-ornamentation) .
  2. Remove the 4 nuts and the speaker enclosure. Disconnect the electrical connector.
  3. To install, reverse the removal procedure.
