Starting System: Diagnosis Ford Fiesta Mk6

Inspection and Verification

Note. Make sure the anti-theft system is functioning correctly before carrying out a logical starting system diagnosis. Address anti-theft system concerns before continuing. Refer to ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS) .

1. Verify the customer concern.
2. Remove the accessory drive belt. Refer to «ACCESSORY DRIVE»(ref-382380) . Verify the crankshaft and each of the components driven by the accessory drive belt rotate and are not seized or damaged.
3. Visually inspect for obvious signs of mechanical or electrical damage. VISUAL INSPECTION CHART Mechanical Electrical Starter motor Starter motor bolts IA key (with Intelligent access) Start/stop button (with IA ) Battery Battery cables High-current Battery Junction Box (BJB) mega fuse 1 (450A) BJB fuse 11(30A) Wiring, terminals or connectors Starter relay PATS Loose or corroded connections
4. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
5. If the cause is not visually evident, connect the scan tool to the Data Link Connector (DLC).
6. If the scan tool does not communicate with the VCM : check the VCM connection to the vehicle. check the scan tool connection to the VCM . refer to «MODULE COMMUNICATIONS NETWORK»(ref-382388) , No Power To The Scan Tool, to diagnose no power to the scan tool.
7. For vehicles without Intelligent Access, if the scan tool does not communicate with the vehicle: verify the ignition key is in the ON position. verify the scan tool operation with a known good vehicle. refer to «MODULE COMMUNICATIONS NETWORK»(ref-382388) to diagnose no response from the PCM.
8. For vehicles with Intelligent Access, if the scan tool does not communicate with the vehicle: verify the ignition is in the ON mode. the air bag warning indicator prove-out (other indicators may NOT prove ignition is ON) confirms ignition ON. If ignition does not turn ON, refer to «STEERING COLUMN SWITCHES»(ref-382407) to diagnose no power in RUN. verify the scan tool operation with a known good vehicle. refer to «MODULE COMMUNICATIONS NETWORK»(ref-382388) , to diagnose no response from the PCM.
9. Carry out the network test. If the scan tool responds with no communication for one or more modules, refer to «MODULE COMMUNICATIONS NETWORK»(ref-382388) . If the network test passes, proceed with module self-test diagnostics.
10. Carry out the self-test diagnostics for the Transmission Control Module (TCM) (if equipped), RFA module (if equipped) and the PCM.
11. If the DTCs retrieved are related to the concern, go to «DTC CHARTS»(ref-382410-S29289507722011012300000) .
12. If no DTCs related to the concern are retrieved, go to «SYMPTOM CHART»(ref-382410-S06616860332011012300000) .

DTC Chart

PCM DTC CHART

TRANSMISSION CONTROL MODULE (TCM) DTC CHART

REMOTE FUNCTION ACTUATOR (RFA) MODULE DTC CHART

Symptom Chart

ENGINE STARTING SYSTEM SYMPTOM CHART

Pinpoint Test A: The Engine Does Not Crank - Without Intelligent Access

Refer to appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. A1 CHECK THE BATTERY Check the battery condition and state of charge. Refer to Diagnosis and Testing in «BATTERY, MOUNTING AND CABLES»(ref-382392) Is the battery OK? Yes: Go to A2 . No: CHARGE or INSTALL a new battery as necessary. Refer to «BATTERY, MOUNTING AND CABLES»(ref-382392) . TEST the system for normal operation.
2. A2 RETRIEVE DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: PCM - Self-Test. Enter the following diagnostic mode on the scan tool: IPC - Self-Test. Enter the following diagnostic mode on the scan tool: TCM - Self-Test. Were DTCs retrieved on-demand during self-test? Yes: For IPC DTCs, refer to «INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES»(ref-382387) . For all TCM DTCs, refer to «AUTOMATIC SHIFTING MANUAL TRANSMISSION/TRANSAXLE»(ref-382366) . For PCM DTC P0617:12, go to «PINPOINT TEST C»(ref-382410-S02013508102011012300000) . For PCM DTC P0850:00, go to A4 . For DTC P0851:00, go to A7 . For all other PCM DTCs, refer to «ELECTRONIC ENGINE CONTROLS»(ref-382403) . No: For automatic transaxle, go to A3 . For manual transaxle, go to A9 .
3. A3 CHECK THE PCM TRANSMISSION P/N RANGE SWITCH (TRP/N) PID Enter the following diagnostic mode on the scan tool: DataLogger - PCM. While observing the TRP/N PID, place the gear selector in NEUTRAL and then PARK Does the PID indicate YES with the gear selector in NEUTRAL or PARK? Yes: Go to A10 . No: Go to A4 .
4. A4 CHECK THE P/N_SW/CLUTCH 2 CIRCUIT FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect: PCM C175B. Disconnect: TCM C1750A. Ignition ON. Measure the voltage between PCM C175B-7, circuit CE903 (BU/OG), harness side and ground. Is any voltage present? Yes: REPAIR circuit CE903 (BU/OG). CLEAR the DTCs. REPEAT the self-test. TEST the system for normal operation. No: Go to A5 .
5. A5 CHECK THE P/N_SW/CLUTCH 2 CIRCUIT FOR AN OPEN Ignition OFF. Measure the resistance between PCM C175B-7, circuit CE903 (BU/OG), harness side and TCM C1750A-39, circuit CE903 (BU/OG), harness side. Is the resistance less than 5 ohms? Yes: Go to A6 . No: REPAIR circuit CE903 (BU/OG). CLEAR the DTCs. REPEAT the self-test. TEST the system for normal operation.
6. A6 CHECK THE TCM PARK NEUTRAL STARTER ENABLE OUTPUT FAULT DETECTED (TR_CRANK_F) AND PCM TRANSMISSION P/N RANGE SWITCH (TRP/N) PIDS Connect: PCM C175B. Connect: TCM C1750A. Ignition ON. Enter the following diagnostic mode on the scan tool: DataLogger - TCM . While observing the TR_CRANK_F PID, place the gear selector in PARK and then NEUTRAL. Enter the following diagnostic mode on the scan tool: DataLogger - PCM. While observing the TRP/N PID, place the gear selector in PARK and then NEUTRAL. Do both PIDs agree with the gear selector position? Yes: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test. TEST the system for normal operation. No: If the concern is with TRP/N PID, INSTALL a new PCM. Refer to «ELECTRONIC ENGINE CONTROLS»(ref-382403) . TEST the system for normal operation. If the concern is with TR_CRANK_F PID, INSTALL a new TCM . Refer to «AUTOMATIC SHIFTING MANUAL TRANSMISSION/TRANSAXLE»(ref-382366) . TEST the system for normal operation.
7. A7 CHECK THE PARK/NEUTRAL SWITCH INPUT CIRCUIT LOW DTC FOR A FAULT STATUS CHANGE (SHORT TO GROUND INDICATED) Ignition OFF. Disconnect: TCM C1750A. Ignition ON. Enter the following diagnostic mode on the scan tool: PCM - Self-Test. Was DTC P0851:00 retrieved on-demand during self-test? Yes: Go to A8 . No: INSTALL a new TCM . Refer to «AUTOMATIC SHIFTING MANUAL TRANSMISSION/TRANSAXLE»(ref-382366) . CLEAR the DTCs. REPEAT the self-test. TEST the system for normal operation.
8. A8 CHECK THE P/N_SWITCH CLUTCH 2 CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect: PCM C175B. Measure the resistance between PCM C175B-7, circuit CE903 (BU/OG), harness side and ground. Is the resistance greater than 10,000 ohms? Yes: INSTALL a new PCM. Refer to «ELECTRONIC ENGINE CONTROLS»(ref-382403) . TEST the system for normal operation. No: REPAIR circuit CE903 (BU/OG). CLEAR the DTCs. REPEAT the self-test. TEST the system for normal operation.
9. A9 CHECK THE PCM CLUTCH PEDAL AT OR NEAR BOTTOM OF TRAVEL (CPP_BOT) PID Enter the following diagnostic mode on the scan tool: DataLogger - PCM. While observing the CPP_BOT PID, fully disengage the clutch. Does the PID change from NO to YES? Yes: Go to A10 . No: Go to A23 .
10. A10 CHECK THE PCM STARTER MOTOR RELAY ENABLE (STRT_RLY) PID Enter the following diagnostic mode on the scan tool: DataLogger - PCM. NOTE: For manual transaxle, fully disengage the clutch. Monitor the STRT_RLY PID while holding the key in the START position. Does the PID change from DISENGAGED to ENGAGED? Yes: Go to A11 . No: Go to A21 .
11. A11 CHECK THE STARTER MOTOR RELAY Swap the starter relay with a known good relay and attempt to crank the engine. Does the engine crank? Yes: INSTALL a new starter relay. TEST the system for normal operation. No: Go to A12 .
12. A12 CHECK THE VOLTAGE TO THE STARTER MOTOR RELAY Ignition OFF. Disconnect: Starter Motor Relay. Measure the voltage between Battery Junction Box (BJB) starter relay cavity pin 3, circuit SBB11 (BU/RD), harness side and ground. Is the voltage greater than 10 volts? Yes: Go to A13 . No: VERIFY BJB fuse 11 (30A) is OK. If OK, repair circuit SBB11 (BU/RD) for an open. If not OK, refer to the appropriate SYSTEM WIRING DIAGRAMS article to identify the possible causes of the circuit short. Test the system for normal operation.
13. A13 CHECK THE STARTER MOTOR Ignition OFF. With the transaxle in PARK or NEUTRAL, connect one end of a fused jumper wire to BJB starter relay cavity 3, circuit SBB11 (BU/RD) and momentarily connect the other end of the fused jumper wire to BJB starter relay cavity 5, circuit CDC26 (GY/OG). Did the starter engage and the engine crank? Yes: Go to A19 . No: Go to A14 .
14. A14 CHECK THE BATTERY GROUND CABLE Measure the voltage between the positive battery post and the battery ground cable connection at the engine. Is the voltage greater than 10 volts? Yes: Go to A15 . No: CARRY OUT the Starter Motor - Ground Circuit Test. Refer to «COMPONENT TEST»(ref-382410-S26493517572011012300000) in this information. TEST the system for normal operation.
15. A15 CHECK THE STARTER MOTOR GROUND Measure the voltage between the positive battery post and the starter motor case. Is the voltage greater than 10 volts? Yes: Go to A16 . No: CLEAN the starter motor mounting flange and make sure the starter motor is correctly mounted. TEST the system for normal operation.
16. A16 CHECK THE VOLTAGE TO THE STARTER MOTOR Measure the voltage between starter solenoid C197A, circuit SBF01 (RD) and ground. Is the voltage greater than 10 volts? Yes: Go to A17 . No: INSTALL a new positive battery cable. Refer to «BATTERY, MOUNTING AND CABLES»(ref-382392) . TEST the system for normal operation.
17. A17 CHECK THE STARTER MOTOR Connect one end of a fused jumper wire to starter solenoid C197A, circuit SBF01 (RD) and momentarily connect the other end of the fused jumper wire to starter solenoid C197B, circuit CDC26 (GY/OG). Did the starter engage and the engine crank? Yes: Go to A18 . No: INSTALL a new starter motor. Refer to «STARTER MOTOR»(ref-382410-S15729305252011012300000) in this information. TEST the system for normal operation.
18. A18 CHECK FOR START INPUT AT THE STARTER Connect: Starter Relay. Disconnect: Starter Solenoid C197B. Measure the voltage between the starter solenoid C197B-1, circuit CDC26 (GY/OG) and ground, while holding the key in the START position. Is the voltage greater than 10 volts? Yes: CLEAN the starter solenoid "S" terminal and connector. CHECK the wiring and the starter motor for a loose or intermittent connection. TEST the system for normal operation. No: REPAIR circuit CDC26 (GY/OG) for an open. TEST the system for normal operation.
19. A19 CHECK THE PCM START CIRCUITS FOR A SHORT TO GROUND Ignition OFF. Disconnect: PCM C175B. Disconnect: Starter Relay. Disconnect: IPC C220. Measure the resistance between PCM C175B, harness side and ground, using the following chart. PCM CONNECTOR REFERENCE CHART PCM Connector Circuit C175B-24 CDC12 (YE) C175B-22 CDC54 (WH/GN) Are the resistances greater than 10,000 ohms? Yes: Go to A20 . No: REPAIR the affected circuit for a short to ground. TEST the system for normal operation.
20. A20 CHECK THE PCM START CIRCUITS FOR AN OPEN Measure the resistance between PCM C175B, harness side and BJB starter relay cavity, using the following chart. PCM CONNECTOR REFERENCE CHART PCM Connector Circuit BJB C175B-24 CDC12 (YE) BJB starter relay cavity 2 C175B-22 CDC54 (WH/GN) BJB starter relay cavity 1 Are the resistances less than 5 ohms? Yes: INSTALL a new PCM. Refer to «ELECTRONIC ENGINE CONTROLS»(ref-382403) . TEST the system for normal operation. No: REPAIR the affected circuit for an open. TEST the system for normal operation.
21. A21 CHECK THE START CIRCUIT FOR VOLTAGE AT THE PCM Disconnect: PCM C175B. Measure the voltage between PCM C175B-9, circuit CDC35 (BU/WH) and ground, while holding the key in the START position. Is the voltage greater than 10 volts? Yes: INSTALL a new PCM. Refer to «ELECTRONIC ENGINE CONTROLS»(ref-382403) . TEST the system for normal operation. No: Go to A22 .
22. A22 CHECK THE IGNITION SWITCH Carry out the Ignition Switch Component Test. Refer to appropriate SYSTEM WIRING DIAGRAMS article for component testing. Did the ignition switch pass the component test? Yes: REPAIR circuit CDC35 (BU/WH) for an open. TEST the system for normal operation. No: INSTALL a new ignition switch. Refer to «STEERING COLUMN SWITCHES»(ref-382407) . TEST the system for normal operation.
23. A23 CHECK THE CPP SWITCH CIRCUIT FOR AN OPEN Ignition OFF. Disconnect: CPP Switch C257. Disconnect: PCM C175B. Measure the resistance between CPP switch C257-1, circuit CE903 (BU/OG), harness side and PCM C175B-7, circuit CE903 (BU/OG), harness side. Is the resistance less than 5 ohms? Yes: Go to A24 . No: REPAIR circuit CE903 (BU/OG) for an open. TEST the system for normal operation.
24. A24 CHECK THE CPP GROUND CIRCUIT FOR AN OPEN Measure the resistance between CPP switch C257-2, circuit GD187 (BK/GN), harness side and ground. Is the resistance less than 5 ohms? Yes: Go to A25 . No: REPAIR circuit GD187 (BK/GN) for an open. TEST the system for normal operation.
25. A25 CHECK THE CPP SWITCH Connect: CPP Switch C257. Measure the resistance between PCM C175B-7, circuit CE903 (BU/OG), harness side and ground while depressing the clutch pedal. Is the resistance less than 5 ohms? Yes: INSTALL a new PCM. Refer to «ELECTRONIC ENGINE CONTROLS»(ref-382403) . TEST the system for normal operation. No: INSTALL a new CPP switch. Refer to «ELECTRONIC ENGINE CONTROLS»(ref-382403) . TEST the system for normal operation.

Pinpoint Test B: The Engine Does Not Crank - With Intelligent Access (IA)

Refer to appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

1. B1 CHECK THE BATTERY Check the battery condition and state of charge. Refer to Diagnosis and Testing in «BATTERY, MOUNTING AND CABLES»(ref-382392) . Is the battery OK? Yes: Go to B2 . No: CHARGE or INSTALL a new battery as necessary. Refer to «BATTERY, MOUNTING AND CABLES»(ref-382392) . TEST the system for normal operation.
2. B2 CHECK FOR KEY NOT DETECTED NOTE: There are certain areas inside the vehicle where the IA key may not be detected and the message center displays KEY NOT DETECTED. If the IA key is in the far outside edges of the interior (like in a door map pocket or above a sun visor) it might not be detected. Move the IA key to a different location and try to crank the vehicle again. Check the Front Control/Display Interface Module (FCDIM) while pressing the start/stop switch. Is KEY NOT DETECTED displayed? Yes: Refer to «ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS)»(ref-382409) to diagnose KEY NOT DETECTED is displayed. No: Go to B3 .
3. B3 CHECK THE IPC OPERATION Observe the Instrument Panel Cluster (IPC) operation while pressing the start/stop switch. Do some indicators in the IPC illuminate? Yes: Go to B5 . No: Go to B4 .
4. B4 CHECK FOR COMMUNICATION WITH THE SCAN TOOL Refer to Inspection and Verification in «MODULE COMMUNICATIONS NETWORK»(ref-382388) , and follow the procedure to establish a session with the vehicle. Does the RFA module pass the network test? Yes: Refer to «STEERING COLUMN SWITCHES»(ref-382407) to diagnose no power in RUN. No: Refer to «MODULE COMMUNICATIONS NETWORK»(ref-382388) to diagnose no communication with the RFA module or PCM.
5. B5 RETRIEVED DTCs Ignition ON. Enter the following diagnostic mode on the scan tool: PCM - Self-Test. Enter the following diagnostic mode on the scan tool: RFA module - Self-Test. Enter the following diagnostic mode on the scan tool: TCM - Self-Test. Enter the following diagnostic mode on the scan tool: PCM - Self-Test. Were DTCs retrieved on-demand during self-test? Yes: For RFA module DTC P1708:62, go to B33 . For RFA module DTC P0615:12, go to «PINPOINT TEST C»(ref-382410-S02013508102011012300000) . For all other RFA module DTCs, refer to «ANTI-THEFT - PASSIVE ANTI-THEFT SYSTEM (PATS)»(ref-382409) . For PCM DTC P0617:12, go to «PINPOINT TEST C»(ref-382410-S02013508102011012300000) . For PCM DTC P0850:00, go to B10 . For DTC P0851:00, go to B13 . For all other PCM DTCs, refer to «ELECTRONIC ENGINE CONTROLS»(ref-382403) . For all TCM DTCs, refer to «AUTOMATIC SHIFTING MANUAL TRANSMISSION/TRANSAXLE»(ref-382366) . No: For automatic transaxle, go to B6 . For manual transaxle, go to B15 .
6. B6 CHECK THE RFA MODULE BRAKE SWITCH (BRAKE_SW) PID Enter the following diagnostic mode on the scan tool: DataLogger - RFA module. While observing the BRAKE_SW PID, apply the brake pedal. Does the PID change from OFF to ON? Yes: Go to B9 . No: Go to B7 .
7. B7 CHECK THE CRUISE CONTROL DEACTIVATION CIRCUIT TO THE RFA MODULE FOR A SHORT TO GROUND Ignition OFF. Disconnect: IPC C220. Disconnect: RFA module C3503B. Disconnect: Cruise Control Deactivation Switch C278. Measure the resistance between RFA module C3503B-21, circuit CCA29 (GN/BU), harness side and ground. Is the resistance greater than 10,000 ohms? Yes: Go to B8 . No: REPAIR circuit CCA29 (GN/BU). TEST the system for normal operation.
8. B8 CHECK THE BRAKE SWITCH Connect: Cruise Control Deactivation Switch C278. Measure the resistance between RFA module C3503B-21, circuit CCA29 (GN/BU) and ground while applying the brake pedal. Is the resistance greater than 10,000 ohms? Yes: INSTALL a new RFA module. Refer to «MULTIFUNCTION ELECTRONIC MODULES»(ref-382389) . TEST the system for normal operation. No: INSTALL a new cruise control deactivation switch. Refer to «CRUISE CONTROL»(ref-382399) . TEST the system for normal operation.
9. B9 CHECK THE PCM TRANSMISSION P/N SWITCH (TRN/P) PID Enter the following diagnostic mode on the scan tool: DataLogger - PCM. While observing the TRP/N PID, place the gear selector in NEUTRAL and then PARK. Does the PID indicate YES with the gear selector in NEUTRAL or PARK? Yes: Go to B16 . No: Go to B10 .
10. B10 CHECK THE P/N_SW/CLUTCH 2 CIRCUIT FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect: PCM C175B. Disconnect: TCM C1750A. Ignition ON. Measure the voltage between PCM C175B-7, circuit CE903 (BU/OG), harness side and ground. Is any voltage present? Yes: REPAIR circuit CE903 (BU/OG). CLEAR the DTCs. REPEAT the self-test. TEST the system for normal operation. No: Go to B11 .
11. B11 CHECK THE P/N_SW/CLUTCH 2 CIRCUIT FOR AN OPEN Ignition OFF. Measure the resistance between PCM C175B-7, circuit CE903 (BU/OG), harness side and TCM C1750A-39, circuit CE903 (BU/OG), harness side. Is the resistance less than 5 ohms? Yes: Go to B12 . No: REPAIR circuit CE903 (BU/OG). CLEAR the DTCs. REPEAT the self-test. TEST the system for normal operation.
12. B12 CHECK THE TCM PARK NEUTRAL STARTER ENABLE OUTPUT FAULT DETECTED (TR_CRANK_F) AND PCM TRANSMISSION P/N RANGE SWITCH (TRP/N) PIDS Connect: PCM C175B. Connect: TCM C1750A. Ignition ON. Enter the following diagnostic mode on the scan tool: DataLogger - TCM . While observing the TR_CRANK_F PID, place the gear selector in PARK and then NEUTRAL. Enter the following diagnostic mode on the scan tool: DataLogger - PCM. While observing the TRP/N PID, place the gear selector in PARK and then NEUTRAL. Do the PIDs agree with the gear selector position? Yes: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test. TEST the system for normal operation. No: If the concern is with TRP/N PID, INSTALL a new PCM. Refer to «ELECTRONIC ENGINE CONTROLS»(ref-382403) . TEST the system for correct operation. If the concern is with TR_CRANK_F PID, INSTALL a new TCM . Refer to «AUTOMATIC SHIFTING MANUAL TRANSMISSION/TRANSAXLE»(ref-382366) . TEST the system for normal operation.
13. B13 CHECK THE PARK/NEUTRAL SWITCH INPUT CIRCUIT LOW DTC FOR A FAULT STATUS CHANGE (SHORT TO GROUND INDICATED) Ignition OFF. Disconnect: TCM C1750A. Ignition ON. Enter the following diagnostic mode on the scan tool: PCM - Self-Test. Was DTC P0851:00 retrieved on-demand during self-test? Yes: Go to B14 . No: INSTALL a new TCM . Refer to «AUTOMATIC SHIFTING MANUAL TRANSMISSION/TRANSAXLE»(ref-382366) . CLEAR the DTCs. REPEAT the self-test. TEST the system for normal operation.
14. B14 CHECK THE P/N_SW/CLUTCH 2 CIRCUIT FOR A SHORT TO GROUND Ignition OFF. Disconnect: PCM C175B. Measure the resistance between PCM C175B-7, circuit CE903 (BU/OG), harness side and ground. Is the resistance greater than 10,000 ohms? Yes: INSTALL a new PCM. Refer to «ELECTRONIC ENGINE CONTROLS»(ref-382403) . TEST the system for normal operation. No: REPAIR circuit CE903 (BU/OG). CLEAR the DTCs. REPEAT the self-test. TEST the system for normal operation.
15. B15 CHECK THE PCM CLUTCH PEDAL AT OR NEAR BOTTOM OF TRAVEL (CPP_BOT) PID Enter the following diagnostic mode on the scan tool: DataLogger - PCM. While observing the CPP_BOT PID, fully disengage the clutch. Does the PID change from NO to YES? Yes: Go to B16 . No: Go to B30 .
16. B16 CHECK THE PCM STARTER MOTOR RELAY ENABLE (STRT_RLY) PID Enter the following diagnostic mode on the scan tool: DataLogger - PCM. NOTE: For manual transaxle, fully disengage the clutch. Monitor the STRT_RLY PID while pressing the start/stop switch and the brake or clutch pedal. Does the PID change from DISENGAGED to ENGAGED? Yes: Go to B17 . No: Refer to «STEERING COLUMN SWITCHES»(ref-382407) to diagnose the no power in start concern.
17. B17 CHECK THE STARTER MOTOR RELAY Swap the starter relay with a known good relay and attempt to crank the engine. Does the engine crank? Yes: INSTALL a new starter relay. TEST the system for normal operation. No: Go to B18 .
18. B18 CHECK THE VOLTAGE TO THE STARTER MOTOR RELAY Ignition OFF. Disconnect: Starter Motor Relay. Measure the voltage between Battery Junction Box (BJB) starter relay cavity 3, circuit SBB11 (BU/RD), harness side and ground. Is the voltage greater than 10 volts? Yes: Go to B19 . No: VERIFY BJB fuse 11 (30A) is OK. If OK, REPAIR circuit SBB11 (BU/RD) for an open. If not OK, refer to the appropriate SYSTEM WIRING DIAGRAMS article to identify the possible causes of the circuit short. TEST the system for normal operation.
19. B19 CHECK THE STARTER MOTOR Ignition OFF. With the transaxle in PARK or Neutral, connect one end of a fused jumper wire to BJB starter relay cavity 3, circuit SBB11 (BU/RD) and momentarily connect the other end of the fused jumper wire to BJB starter relay cavity 5, circuit CDC26 (GY/OG). Did the starter engage and the engine crank? Yes: Go to B25 . No: Go to B20 .
20. B20 CHECK THE BATTERY GROUND CABLE Measure the voltage between the positive battery post and the battery ground cable connection at the engine. Is the voltage greater than 10 volts? Yes: Go to B21 . No: CARRY OUT the Starter Motor - Ground Circuit Test. Refer to «COMPONENT TEST»(ref-382410-S26493517572011012300000) in this information. TEST the system for normal operation.
21. B21 CHECK THE STARTER MOTOR GROUND Measure the voltage between the positive battery post and the starter motor case. Is the voltage greater than 10 volts? Yes: Go to B22 . No: CLEAN the starter motor mounting flange and make sure the starter motor is correctly mounted. TEST the system for normal operation.
22. B22 CHECK THE VOLTAGE TO THE STARTER MOTOR Measure the voltage between starter solenoid C197A-1, circuit SBF01 (RD) and ground. Is the voltage greater than 10 volts? Yes: Go to B23 . No: INSTALL a new positive battery cable. Refer to «BATTERY, MOUNTING AND CABLES»(ref-382392) . TEST the system for normal operation.
23. B23 CHECK THE STARTER MOTOR Connect one end of a fused jumper wire to starter solenoid C197A-1, circuit SBF01 (RD) and momentarily connect the other end of the fused jumper wire to starter solenoid C197B, circuit CDC26 (GY/OG). Did the starter engage and the engine crank? Yes: Go to B24 . No: INSTALL a new starter motor. Refer to «STARTER MOTOR»(ref-382410-S15729305252011012300000) in this information. TEST the system for normal operation.
24. B24 CHECK FOR START INPUT AT THE STARTER Connect: Starter Motor Relay. Disconnect: Starter Solenoid C197B. Measure the voltage between the starter solenoid C197B-1, circuit CDC26 (GY/OG) and ground, while pressing the start/stop switch and the brake or clutch pedal. Is the voltage greater than 10 volts? Yes: CLEAN the starter solenoid "S" terminal and connector. CHECK the wiring and the starter motor for a loose or intermittent connection. TEST the system for normal operation. No: REPAIR circuit CDC26 (GY/OG) for an open. TEST the system for normal operation.
25. B25 CHECK THE RFA MODULE STARTER REQUEST CIRCUIT FOR VOLTAGE Measure the voltage between BJB starter relay cavity 1, circuit CDC54 (WH/GN), harness side and ground while pressing the start/stop switch and the brake or clutch pedal. Is the voltage greater than 10 volts? Yes: Go to B28 . No: Go to B26 .
26. B26 CHECK THE RFA MODULE STARTER REQUEST CIRCUIT FOR A SHORT TO GROUND Disconnect: IPC C220. Disconnect: RFA C3503C. Measure the resistance between BJB starter relay cavity 1, circuit CDC54 (WH/GN), harness side and ground. Is the resistance greater than 10,000 ohms? Yes: Go to B27 . No: REPAIR circuit CDC54 (WH/GN). TEST the system for normal operation.
27. B27 CHECK THE RFA MODULE STARTER REQUEST CIRCUIT FOR AN OPEN Measure the resistance between BJB starter relay cavity 1, circuit CDC54 (WH/GN), harness side and RFA module C3503C-6. Is the resistance less than 0.5 ohm? Yes: INSTALL a new RFA module. Refer to «MULTIFUNCTION ELECTRONIC MODULES»(ref-382389) . TEST the system for normal operation. No: REPAIR circuit CDC54 (WH/GN). TEST the system for normal operation.
28. B28 CHECK THE PCM STARTER CONTROL CIRCUIT Connect a 12-volt test light between BJB starter relay cavity 1, circuit CDC54 (WH/GN) and BJB starter relay cavity 2, circuit CDC12 (YE), then press the brake or clutch pedal and press the start/start switch. Does the test light illuminate? Yes: INSTALL a new starter relay. TEST the system for normal operation. No: Go to B29 .
29. B29 CHECK THE STARTER CONTROL CIRCUIT FOR AN OPEN Disconnect: PCM C175B. Measure the resistance between BJB starter relay cavity 2, circuit CDC12 (YE), harness side and PCM C175B-24, circuit CDC12 (YE), harness side. Is the resistance less than 5 ohms? Yes: INSTALL a new PCM. Refer to «ELECTRONIC ENGINE CONTROLS»(ref-382403) . TEST the system for normal operation. No: REPAIR circuit CDC12 (YE). TEST the system for normal operation.
30. B30 CHECK THE P/N_SW/CLUTCH 2 CIRCUIT FOR AN OPEN OR SHORT TO GROUND Ignition OFF. Disconnect: CPP Switch C257. Disconnect: RFA Module C3503B. Disconnect: PCM C175B. Measure the resistance between: CPP switch C257-1, circuit CE903 (BU/OG), harness side and PCM C175B-7, circuit CE903 (BU/OG), harness side. PCM C175B-7, circuit CE903 (BU/OG), harness side and ground. Is the resistance greater than 10,000 ohms between the PCM and ground; and less than 5 ohms between the PCM and CPP switch? Yes: Go to B31 . No: REPAIR circuit CE903 (BU-OG). CLEAR the DTCs. REPEAT the self-test. TEST the system for normal operation.
31. B31 CHECK THE CPP GROUND CIRCUIT FOR AN OPEN Measure the resistance between CPP switch C257-2, circuit GD187 (BK/GN), harness side and ground. Is the resistance less than 5 ohms? Yes: Go to B32 . No: REPAIR circuit GD187 (BK/GN) for an open. CLEAR DTCs. REPEAT the self-test. TEST the system for normal operation.
32. B32 CHECK THE CPP SWITCH Connect: CPP Switch C257. Measure the resistance between PCM C175B-7, circuit CE903 (BU/OG), harness side and ground while pressing the clutch pedal. Is the resistance less than 5 ohms? Yes: INSTALL a new PCM. Refer to «ELECTRONIC ENGINE CONTROLS»(ref-382403) . TEST the system for normal operation. No: INSTALL a new CPP switch. Refer to «ELECTRONIC ENGINE CONTROLS»(ref-382403) . CLEAR the DTCs. REPEAT the self-test. TEST the system for normal operation.
33. B33 CHECK THE P/N_SW/CLUTCH 2 CIRCUIT FOR A SHORT TO VOLTAGE Ignition OFF. Disconnect: CPP Switch C257. Disconnect: RFA Module C3503B. Disconnect: PCM C175B. Ignition ON. Measure the voltage between PCM C175B-7, circuit CE903 (BU/OG), harness side and ground. Is any voltage present? Yes: REPAIR circuit CE903 (BU-OG). CLEAR the DTCs. REPEAT the self-test. TEST the system for normal operation. No: Go to B34 .
34. B34 CHECK THE P/N_SW/CLUTCH 2 INPUT CIRCUIT FOR AN OPEN BETWEEN THE PCM AND RFA MODULE Ignition OFF. Measure the resistance between RFA module C3503B-17, circuit CE903 (BU/OG), harness side and PCM C175B-7, circuit CE903 (BU/OG), harness side. Is the resistance less than 5 ohms? Yes: Go to B35 . No: REPAIR circuit CE903 (BU/OG). CLEAR the DTCs. REPEAT the self-test. TEST the system for normal operation.
35. B35 CHECK THE IPC CLUTCH SWITCH (CLUTCH_INPUT) AND RFA MODULE CLUTCH SWITCH (CLUTCH_SW) PIDs Ignition OFF. Connect: CPP Switch C257. Connect: RFA Module C3503B. Connect: PCM C175B. Ignition ON. Enter the following diagnostic mode on the scan tool: DataLogger- IPC Module. While observing the CLUTCH_INPUT PID, fully engage and disengage the clutch. Enter the following diagnostic mode on the scan tool: DataLogger- RFA module. While observing the CLUTCH _SW PID, fully engage and disengage the clutch. Do both PIDs agree with the clutch pedal position? Yes: The system is operating correctly at this time. The concern may have been caused by a loose or corroded connector. CLEAR the DTCs. REPEAT the self-test. TEST the system for normal operation. No: If the concern is with CPP_BOT PID, INSTALL a new PCM. Refer to «ELECTRONIC ENGINE CONTROLS»(ref-382403) . If the concern is with CLUTCH _SW PID, INSTALL a new RFA module. Refer to «MULTIFUNCTION ELECTRONIC MODULES»(ref-382389) . TEST the system for normal operation.

Pinpoint Test C: DTC P0615:12 or P0617:12

Refer to appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

Note. Use the correct probe adapter(s) when making measurements. Failure to use the correct probe adapter(s) may damage the connector.

Pinpoint Test D: Unusual Starter Noise

Refer to appropriate SYSTEM WIRING DIAGRAMS article for schematic and connector information.

Starter Motor - Ground Circuit Test

A no or slow crank condition can be caused by excessive resistance in the ground or return portion of the cranking circuit. Check the voltage drop in the ground circuit as follows

Scheme 41

1. Connect the Fluke 77-IV Digital Multimeter positive lead to the starter motor housing (make sure the connection is clean and free of rust or grease). Connect the negative lead to the negative (-) battery terminal.
2. Engage the remote starter switch and crank the engine. Read and record the voltage reading. The reading should be 0.5 volt or less.
3. If the voltage is greater than 0.5 volt, clean the negative cable connections at the battery, the body ground connections and the starter ground connections. Retest.
4. If the voltage is greater than 0.5 volt, install a new negative battery cable. If the voltage reading is less than 0.5 volt and the engine still does not crank or cranks slowly, install a new starter motor.

Scheme 42

STARTER MOTOR PART REFERENCE CHART
