Front Suspension: Component Locations Ford Explorer V

Suspension Front 4 illustrations ~206 words

Special Tool(s)

Illustration Name Number TKITNumber C-Frame And Screw 211-023 (T74P-3044-A1)

Scheme 23

Scheme 23: Special Tool(s)

Scheme 24

Scheme 24: Removal
  1. Remove the brake disc. REFER to «FRONT DISC BRAKE SYSTEM»(ref-517543) .
  2. Using 211-023 (T74P-3044-A1), remove the wheel stud.

Illustration Name Number TKITNumber Remover, Drive Pinion Bearing Cone 205-D002 (D79L-4621-A)

Illustration Name Number TKIT Number Remover, Front Wheel Hub 205-D070 (D93P-1175-B)

Scheme 25

Scheme 25: Special Tool(s)

Scheme 26

Scheme 26: Removal
  1. Remove the wheel and tire. REFER to «WHEEL AND TIRE»(ref-517542) .
  2. Remove the wheel hub nut.
  3. Remove the brake disc. REFER to «FRONT DISC BRAKE SYSTEM»(ref-517543) .
  4. Remove and discard the tie-rod end nut, then separate the tie rod end stud from the wheel knuckle.
  5. Remove the wheel speed sensor bolt and the wheel speed sensor from the wheel knuckle. Position the wheel speed sensor aside.
  6. Using a crowfoot wrench, remove and discard the lower ball joint nut.
  7. Push the lower arm downward until the ball joint is clear of the wheel knuckle.
  8. Using 205-D070 (D93P-1175-B), press the halfshaft from the wheel bearing and hub. Support the halfshaft in a level position.
  9. Remove and discard the 2 lower strut-to-wheel knuckle nuts and bolts.
  10. Remove the wheel knuckle. If necessary, remove the wheel hub and bearing. REFER to «Wheel Bearing and Wheel Hub»(ref-517541-S40142391832012121200000) .
