TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Pivot arm nut | 17 |
| Pivot shaft nut | 10 |
| Rear wiper motor grommet nut | 10 |
| Rear wiper motor nuts | 6 |
| Windshield wiper assembly mounting bolts | 15 |
| Windshield wiper motor mounting arm bolt | 15 |
| Windshield wiper motor mounting bolts | 15 |
| Windshield washer reservoir bolts | 5 |
TORQUE SPECIFICATIONS
The wipers and washers system consists of the following components
- Windshield wiper blades
- Windshield wiper pivot arms
- Windshield wiper motor assembly
- Windshield wiper motor
- Windshield washer pump
- Windshield washer reservoir
- Rear window wiper blade
- Rear window wiper pivot arm
- Rear window wiper motor assembly
Note. The smart junction box (SJB) may also be identified as the generic electronic module (GEM).
If equipped with automatic headlamps, the SJB will illuminate the exterior lamps, including the parking lamps, when the front wipers are on for more than 10 seconds.
Special Tools Illustration Tool Name Tool Number Vehicle Communication Module (VCM) and Integrated Diagnostic System (IDS) software with appropriate hardware, or equivalent scan tool 73III Automotive Meter 105-R00057 or equivalent Flex Probe Kit 105-R025B or equivalent SABRE Premium Battery and Electrical System Tester 010-00736 or equivalent
