Wiper Blade and Pivot Arm Adjustment - Windshield
- Cycle and park the windshield wipers.
- Verify the distance between the center of the (1) RH windshield wiper blade and the (3) bottom of the windshield glass to be sure the distance is within specification.
- Verify the distance between the center of the (2) LH windshield wiper blade and the (3) bottom of the windshield glass to be sure the distance is within specification.
- If the distance is not within specification, remove the windshield wiper pivot arm and reposition to specification.
Scheme 29
Scheme 29: Wiper and Washer System - Exploded View, Front
| Item | Part Number | Description |
|---|
| 1 | 17526 RH/ 17527 LH | Windshield wiper pivot arm (2 required) |
| 2 | 02223 RH/ 02222 LH | Cowl panel grille |
| 3 | 14A464 | Windshield wiper motor electrical connector |
| 4 | 13A506 | Wiper motor electrical harness retainer clip |
| 5 | 17500A | Windshield wiper assembly mounting bolts (3 required) |
| 6 | 17A535A | Windshield wiper motor assembly |
| 7 | 17500A | Windshield wiper motor mounting arm bolt |
| 8 | W503875S | Windshield wiper motor mounting bolts (3 required) |
| 9 | 17A535 | Windshield wiper motor |
- For additional information, refer to the appropriate procedures.
