Entertainment System: Other Ford Explorer III

Possible Causes

1. battery junction box (BJB) fuse 6 (60A)
2. central junction box (CJB) fuse(s): 3 (20A) 28 (5A)
3. circuit 1001 (WH/YE) short to ground or open
4. circuit 1002 (BK/PK) short to ground or open
5. circuit 1203 (BK/LB) open
6. circuit 1205 (BK) open
7. audio unit

Scheme 24

Scheme 25

1. antenna
2. antenna cable(s)
3. radio frequency interference suppression equipment
4. audio unit

Scheme 26

Scheme 27

1. speaker(s)
2. high resistance or short to ground in speaker circuits
3. audio unit

Scheme 28

Scheme 29

Possible Cause

1. audio unit

Scheme 30

1. central junction box (CJB) fuse 3 (20A)
2. circuit 37 (YE) open or short to ground
3. circuit 167 (BN/OG) open or short to ground
4. circuit 168 (RD/BK) open or short to ground
5. circuit 172 (LB/RD) open or short to ground
6. circuit 1204 (BK/OG) open
7. subwoofer amplifier
8. subwoofer
9. audio unit

Scheme 31

Scheme 32

Scheme 33

Scheme 34

1. circuit 37 (YE) open
2. circuit 168 (RD/BK) short to power
3. subwoofer amplifier

Scheme 35

1. circuit 583 (YE) open or short to ground
2. circuit 848 (DG/OG) open or short to ground
3. steering wheel audio controls ground circuit open
4. steering wheel audio controls
5. steering wheel control switch harness
6. audio unit
7. PCM

Scheme 36

Scheme 37

Scheme 38

Scheme 39

1. circuit 679 (GY/BK) open
2. audio unit

Scheme 40

1. central junction box (CJB) fuse 3 (20A)
2. circuit 235 (RD/BK)
3. circuit 832 (LB/PK)
4. circuit 833 (TN)
5. circuit 1001 (WH/YE)
6. circuit 1068 (LG/BK)
7. circuit 1203 (BK/LB)
8. circuit 1205 (BK)
9. DVD Unit

Scheme 41

Scheme 42

1. central junction box (CJB) fuse 3 (20A)
2. circuit 1559 (RD)
3. circuit 1560 (WH)
4. circuit 1561 (OG)
5. circuit 1562 (YE)
6. DVD Unit
7. Audio Unit

Scheme 43

Scheme 44

Scheme 45

1. Remove the antenna mast.
2. Remove the RH front fender splash shield. For additional information, refer to Section «BODY SYSTEM - EXTERIOR»(ref-194068) .
3. View 1 of 2. Disconnect the components in the order indicated in the following illustration and table.
4. View 2 of 2. Remove the components in the order indicated in the following illustration and table.
5. To install, reverse the removal procedure.

Scheme 46

1. Disconnect the battery. For additional information, refer to «BATTERY AND CHARGING SYSTEM»(ref-194056) .
2. Remove the components in the order indicated in the following illustration and table.
3. To install, reverse the removal procedure.

Scheme 47

1. Disconnect the battery. For additional information, refer to «BATTERY AND CHARGING SYSTEM»(ref-194056) .
2. Remove the LH rear quarter trim panel. For additional information, refer to «BODY SYSTEM - INTERIOR»(ref-194071) .
3. Remove the components in the order indicated in the following illustration and table.
4. To install, reverse the removal procedure.

Scheme 48

1. Disconnect the battery. For additional information, refer to «BATTERY AND CHARGING SYSTEM»(ref-194056) .
2. Remove the LH rear quarter trim panel. For additional information, refer to «BODY SYSTEM - INTERIOR»(ref-194071) .
3. Remove the components in the order indicated in the following illustration and table.
4. To install, reverse the removal procedure.

Scheme 49

1. Remove the driver airbag module. For additional information, refer to «AIR BAG RESTRAINT SYSTEMS»(ref-160412) .
2. Remove the components in the order indicated in the following illustration and table.
3. To install, reverse the removal procedure.
